BT QUARTET 3100 Manuel utilisateur

This equipment is not designed for making emergency telephone calls when the power fails.

Alternative arrangements should be made for access to emergency services.

This product is intended for connection to analogue public switched telephone networks

and private switchboards in the United Kingdom.

Quartet 3100

Cordless Telephone

User

Guide

Quartet 3 00 User Guide ~ 6th Edition ~ 3rd September ’02 ~ 4388

YOU MUST

SUBSCRIBE TO YOUR

NETWORK PROVIDER’S

*CALLER DISPLAY *CALL WAITIN

AND *CALL MINDER OR 1571 SERVICE

BEFORE THESE FEATURES WILL WORK.

*A QUARTERLY FEE IS PAYABLE

Quartet 3100 User Guide ~ 6th Editio ~ 3rd September ’02 ~ 4388

Please open this page for an

‘at a glance’ guide to your

Quartet 3100

Quartet 3100 User Guide ~ 6th Edition ~ 3rd September ’02 ~ 4388

Please open this page for a

further ‘at a glance’ guide to your

Quartet 3100

Me u

Quartet 3100 User Guide ~ 6th Editio ~ 3rd September ’02 ~ 4388

At a glance

Handset fascias

Can be changed to suit

your personal preference,

see page 11.

Aerial

Should be extended to obtain

the best signal and reception

available, see page 9.

Recall/Call Waiting

button

For use with a

switchboard/PBX and

BT Select Services, see

page 41.

Also allows you to use

the Call Waiting feature,

see page 32.

Up and Down buttons

Use to scroll up and down

through the menu options,

see page 3.

Last number redial/

Pause button

Redials up to 5 of the last

numbers called, or press to

enter a pause in a stored

number, see page 19.

Option buttons

Lets you select options

within each menu that

are shown on the display,

see page 12.

Ke pad

Talk button

Press to make or receive

a call, see page 12-13.

Clear button

Use to delete unwanted

digits or characters and

to exit the menu, see

page 18.

Quartet 3100 User Guide ~ 6th Edition ~ 3rd September ’02 ~ 4388

Power/In use light

Green light comes on when

connected to the power supply

and flashes when in use.

Charging light

Red light comes on to indicate

charging when the handset is

on the base.

Page button

Press to page the

handset, see page 22.

Quartet 3 00 User Guide ~ 6th Edition ~ 3rd September ’02 ~ 4388

MENU STRUCTURE

Base Settings Ringer Volume Off – Low – High

1 – 2 – 3

1571 Off On

Tone – Pulse

Handset Settings

De-Register

Time Setting 00:00

Off – Low – High

1 – 2 – 3

Ringer Melody

Check 1571

(BT Answer)

Dial Mode

Ringer Volume

Ringer Melody

Page Melody

Off On

Key Tones

Handset

De-Registered

De-Register

This Handset?

Registered

Press Page On Base

Until Base Beeps

Quartet 3 00 User Guide ~ 6th Edition ~ 3rd September ’02 ~ 4388

Quick guide to handset display icons

Battery icon – shows the status of the handset battery.

Directory icon

*Telephone icon – flashes to indicate that new calls have been received

in the Calls list.

*BT 1571 icon – indicates that the 1571 voice mail detection feature is

switched on. Flashes to indicate new voice mail messages have been

received.

Keypad lock icon – indicates that the keypad lock feature is switched on.

*You must subscribe to your Network Provider’s Caller Display and 1571 or

Call Minder Service for these features to work.

09:30 1571

Handset 1

*Calls list

counter

*Calls list icon Directory icon

*1571 icon

Backlit display (LCD)

Time

Standby screen

Quartet 3 00 User Guide ~ 6th Edition ~ 3rd September ’02 ~ 4388

Quick guide

Quick guide to most commonly used handset settings and functions

Function

Answer a call/End a call

Make a call

Redial a number from the

redial list

Store a number in the directory

Dial a number in the directory

Adjust the earpiece volume

Secrecy on/off

Transfer call to another handset

View and dial the Calls list

Adjust handset ringer volume

Adjust base ringer volume

Button combination

, , to scroll through to entry, to dial number

displayed.

, , display shows Enter Name, enter name

using keypad, , display shows Enter Number,

enter the number, .

, , to scroll through to entry, press to dial

number displayed.

During a call, press to increase or decrease volume.

During a call, press and release to switch ON.

Press and release again to switch OFF.

During a call, press , enter handset number to

transfer to .

, to scroll through list, to dial entry

displayed press .

or until display shows

Handset Settings

, display

shows

Ringer Volume

, , to select volume required.

or until display shows

Base Settings

, , display

shows

Ringer Volume

, , to select volume required.

New

Sa e

Sec

Tran

Quartet 3 00 User Guide ~ 6th Edition ~ 3rd September ’02 ~ 4388

In this guide

At a glance 1

Menu structure 3

Quick guides 4-5

Introduction 7

Safety information

Setting up 9

Using your Quartet 3100 12

Making and receiving calls 12

Call timer 13

Secrecy/Music on hold 15

50 Name and number directory 16

edial 19

Paging 22

Base Settings 23

Handset Settings 25

BT Select Services 29

Caller Display 29

Calls list 29

Call Waiting 32

1571 Voice mail indication 33

Using Quartet 3000

additional handsets 35

egistering your handset 35

Transferring calls 37

General information 3

Guarantee 38

If you have to return

your product 39

Technical information 39

Batteries 39

Call security 40

Switchboard compatibility 41

Switchboard use 41

Help and advice 42

Index 44

Note

In this user guide, we’ve included

helpful tips and useful notes. They are

shown in a white box like this.

Note

There is a detailed Index at the back of this guide, see page 44.

Quartet 3 00 User Guide ~ 6th Edition ~ 3rd September ’02 ~ 4388

Introduction

HELPLI E

If you have problems with your phone, call the Quartet 3100 Helpline on 0870

6058047.

Your Quartet 3100 is designed for ease

of use and made to the high standards

set by BT.

You can expect your Quartet 3100 to

provide many years of quality service.

Please read the instructions carefully

before use and keep this user guide for

future reference.

For your records

For guarantee purposes proof of

purchase is required, so please keep

your receipt.

Date of purchase:

Place of purchase:

Serial number:

(on the underside of the base unit)

Unpacking your

Quartet 3100

Check that your Quartet 3100 is complete.

If anything is missing, please contact

your place of purchase immediately.

Quartet 3100 handset.

Quartet 3100 base unit.

Power supply unit.

Telephone line cord.

3 handset fascias

(1 already fitted

on the handset)
