BT Studio Manuel utilisateur

BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408

User

Guide

BT Studio / Studio Twin

Digital Cordless Telephone

This equipment is not designed for ma ing emergency telephone calls

when the power fails. Alternative arrangements should be made for

access to emergency services.

This product is intended for connection to analogue public switched

telephone networ s and private switchboards in the United Kingdom.

This product is not DECT

GAP compatible. It cannot

be registered to any other

DECT GAP telephone and

it is not possible to register

additional handsets.

Please open this page for an ‘At a glance’

guide to your BT Studio.

BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408

BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408 BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408

1 2

Handset display

Displays the status

of your handset.

Red light

Indicates that the phone

is ringing or in use.

Talk button

Use to make, receive

and end calls.

Int button

Use to make an internal call or

to transfer a call to the BT Studio

additional handset (feature only

available if you have purchased

the BT Studio Twin).

Recall button

For use with a switchboard/PBX

and some BT Select Services.

Also use to exit the Calls list.

Quickdial button

Use to store up to 10 numbers

that can then be dialled at the

touch of two buttons.

Keypad

Delete/Secrecy button

Use to delete digits entered

incorrectly and numbers in the

Calls list. Also used to mute a call

so the caller cannot hear you talk

to someone close by.

Calls list button

Press to enter the Calls list, to

view the last 10 calls/most recent

calls. Also use to scroll up and

down through the Calls list.

Volume button

In idle mode use to adjust

the handset ringer volume.

During a call, use to adjust

the earpiece speech volume.

Redial/ ause button

Press to redial the last number

called. Also, press to dial or

store a pause in a number.

At a glance

Quickdial Redial Volu e

Calls

Del

䊱

䊲

123

456

789

RInt

BT Studio Handset

BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408

Power/

In use

Charging

Additionally if you have purchased the BT Studio Twin

Charging light

Red light comes on when

the batteries are being

recharged.

Charging

light

Red light

comes on

when the

batteries

are being

recharged.

Power/In use light

Green light comes on

to indicate mains power.

Flashes when the line is

in use.

Use to page

a handset(s).

BT Studio Base

BT Studio Charger

Quic dial Redial Volume

Calls

Del





123

456

RInt

BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408

Quick guide to the

handset display icons

Batteries are charged

Batteries are exhausted and require charging

Batteries are being charged

Switches off when batteries are fully charged

Handset is in use

Flashes to indicate an external incoming call

Steady during an external call

Flashes to indicate an internal call

Indicates you are dialling or storing a

number in the Quickdial memory

Secrecy feature is switched on

Steady when viewing the Calls list

Flashes when a new call has been received

in the Calls list

Steady when handset is in range of the base

Flashes when the handset is out of range of

the base

BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408

In this guide

At a glance 1

Introduction 6

Unpacking 7

For your records 8

Safety information 9

Setting up 11

sing the telephone 18

Making and receiving calls 18

Secrecy 19

Last number redial 20

aging 20

Quickdial memory 21

Caller Display 23

Handset settings 25

sing the BT Studio additional

handset 26

Internal calls 26

Transferring calls 27

Help 28

General information 30

Guarantee 30

Technical information 31

Switchboard compatibility 31

Switchboard external line access code 32

Setting pauses 32

Recall 32

Index 33

BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408

Introduction

Your BT Studio is designed for ease of use and made to the

high standards set by BT.

You can expect your BT Studio to provide many years of

quality service. Please read the instructions carefully before

use and keep this user guide for future reference.

DECT

By purchasing the Studio you now own a product which

combines the advantages of cordless operation with the

performance of a high quality corded telephone. It complies

with the Digitally Enhanced Cordless Telecommunications

(DECT) standard and offers unparalleled quality and

features.

This user guide applies to both the Studio and Studio Twin

telephones. Please note the Studio range of telephones are

non GAP compatible. Please refer to page 26 for further

information.

BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408

Unpacking your BT Studio

or BT Studio Twin

Check that your BT Studio is complete. If anything is

missing, please contact your place of purchase immediately.

BT Studio handset

BT Studio base station

Power supply for the base station

Telephone line cord

2 x AAA rechargeable batteries

QuicdialRedialVolume

Calls

Clr





123

456

RInt

Studio

Digital Clarity

DECT

Page

Charging In Use

(Item code 872260)

BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408

Additionally if you have purchased the BT Studio Twin:

BT Studio Twin additional handset

BT Studio Twin charger

Power supply for the charger

2 x AAA rechargeable batteries

For your records

For guarantee purposes proof of purchase is required, so

please keep your receipt.

Date of purchase:

Place of purchase:

Serial number:

(on the underside of the base station)

Helpline

If you have problems with your phone, please call the BT

Studio Helpline on 0 706 05 047.

QuicdialRedialVolume

Calls

Clr





123

456

RInt

(Item code 003313)

BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408

General

Only use the power supply included with the product.

Using an unauthorised power supply will invalidate your

guarantee and may damage the telephone. The item

number for the base station is 872260. The item number

for the charger is 003313 (only applicable if you have

purchased the BT Studio Twin).

For the handset use only approved Nickel Metal

Hydride (NiMH) rechargeable batteries. Never use

other batteries or conventional alkaline batteries. They

could lead to a short circuit or destroy the battery

casing. Recommended batteries should have a power

rating of 550mAh 1.2V. Batteries are available from the

BT Studio Helpline 0 706 05 047.

Do not open the handset or base station. This could

expose you to high voltages or other risks. Contact the

helpline for all repairs.

Radio signals transmitted between the handset and base

may cause interference to hearing aids.

It is recommended that advice from a qualified expert

be sought before using this product in the vicinity of

emergency/intensive care medical equipment.

It is recommended that if you have a pacemaker fitted

you check with a medical expert before using this

product.

Never dispose of batteries in a fire. There is a serious

risk of explosion and/or the release of highly toxic

chemicals.

Safety information
