BT QUARTET 1100 Manuel utilisateur

Quartet 1100 User Guide – Edition 4 – 7.8.00

Quartet 1100

User Guide

Cordless Telephone

This equipment is not designed for making emergenc telephone calls when the power fails.

Alternative arrangements should be made for access to emergenc services.

This product is intended for connection to analogue public switched telephone networks

and private switchboards in the United Kingdom.

Quartet 1100 User Guide – Edition 4 – 7.8.00

123

456

▲

▼

M1 M2

Redial

Secrecy

1471

Channel

At a glance

M1/M2 buttons

Allows you to store and

dial one touch numbers.

Aerial

Can be extended.

In Use/Battery Low light

Comes on when the handset

rings, is in use or, if the

handset is on standby,

to indicate the battery

needs recharging.

Channel button

Selects an alternative

radio frequency if

interference occurs

during a call.

Talk button

Press to make or receive

a call.

eypad

Volume control

buttons

Adjusts the handset

ringer and earpiece

speech volume.

Recall button

For use with a

switchboard/PBX and

BT Select Services.

Quickdial button

Allows you to store and

dial up to 10 numbers in

the memory.

Redial button

Redials the last number

called, or press to enter

a pause in a stored

number.

Secrecy

Press to mute the call so

your caller cannot hear you.

1471 button

Lets you hear the

telephone number of

the last person who

called.

Charging contacts

Quartet 1100 User Guide – Edition 4 – 7.8.00

Page

Quartet 1100

Power/In use

Charging

Power/In use light

Comes on when connected

to the power supply and

flashes when in use.

Charging light

Comes on to indicate

charging when the

handset is on the base.

Battery charging contacts

Page button

Press to page the handset.

Mains power socket Telephone line cord socket

Add up to 3 additional

handsets

Use up to 3 additional

handsets with each base.

10 Quickdial memories

Allows you to store up to

10 of your most frequently

used numbers in the memory so they

can be easily dialled.

2 One touch memories

Allows you to store two

important numbers so

they can be dialled at the touch of

a button.

3 Handset ringer melodies

You can choose from three

handset ringer melodies.

Secrecy

You can mute a call and

speak to someone else in

the room without your caller hearing.

You and your caller will hear music

whilst on hold.

Quartet 1100 User Guide – Edition 4 – 7.8.00

Key features

phone

numbers

Secrecy

123

456

▲

▼

M1M2

Redial

Secrecy

1471

Channel

123

456

▲

▼

M1 M2

Redial

Secrecy

1471

Channel

123

456

▲

▼

M1M2

Redial

Secrecy

1471

Channel

Quartet 1100 User Guide – Edition 4 – 7.8.00

In this guide

At a glance 2

Key features 4

Introduction 6

Safety information 7

Setting up 8

sing your Quartet 1100 11

Making and receiving calls 11

Last number redial 12

Secrecy 12

One touch memories 13

Quickdial memories 13

Paging 16

14 1 (Call Return) 16

Call waiting 1

sing Quartet 1000

Additional Handsets 18

Registering your handset 18

Transferring calls 20

General information 21

Guarantee 21

Call security 22

Switchboard compatibility 22

Help and advice 24

Wall mounting 26

Index 27

Handset No

M1 M2

123

456

▲

▼

M1M2

Redial

Secrecy

1471

Channel

Page

Quartet 1100

In Use

Charging

Quartet 1100 User Guide – Edition 4 – 7.8.00

For your records

For warranty purposes proof of

purchase is required, so please keep

your receipt.

Introduction

Date of purchase:

Place of purchase:

Serial number:

(on the underside of the base unit)

HELPLINE

If you have problems with your

phone, call the Quartet 1100

Helpline on 0845 7697146.

Your Quartet 1100 is designed for

ease of use and made to the high

standards set by BT.

You can expect your Quartet 1100 to

provide many years of quality service.

Please read the instructions carefully

before use and keep this user guide

for future reference.

Unpacking your

Quartet 1100

Check that your Quartet 1100 is

complete. If anything is missing,

please contact your place of

purchase immediately.

Quartet 1100 handset.

Quartet 1100 base unit.

Adhesive quickdial

memory label.

Power supply unit.

Telephone line cord.

Wall mounting screws.

Quartet 1100 User Guide – Edition 4 – 7.8.00

Safety information

General

Only use the power supply unit

included with the product. Using

an unauthorised power supply

will invalidate your warranty

and may damage the telephone.

The item number for the power

supply unit is 872264.

Radio signals transmitted

between the handset and base

may cause interference to

some hearing aids.

Do not dismantle the handset

or base station. This could

expose you to high voltages or

other risks. Contact the

helpline for repairs.

Never dispose of batteries in a

fire. There is a serious risk of

explosion and/or the release of

highly toxic chemicals.

Cleaning

Simply clean the handset and

base station with a damp (not

wet) cloth, or an antistatic wipe.

Never use household polish as

this will damage the product.

Never use a dry cloth as this

may cause a static shock.

Environmental

Do not expose to direct

sunlight.

The product may heat up

when the batteries are being

recharged. This is normal.

However, to avoid damage we

recommend that you do not

place the product on

antique/veneered wood.

Do not expose your product to

fire, explosive or other

hazardous conditions.

There is a slight chance that

your phone could be damaged

by an electrical storm. We

recommend that you unplug the

power and telephone line cord

for the duration of the storm.

2Connect the base unit

power supply unit to a

power socket

The power supply unit must remain

plugged in all the time.

Quartet 1100 User Guide – Edition 4 – 7.8.00

Setting up

Follow these steps to set up your Quarter 1100 ready for use.

Plan the location

Situate your Quartet 1100 close

enough to the mains power socket

and telephone socket so that the

cables will reach.

Make sure it is at least 1 metre away

from other electrical products to

avoid interference.

Do not situate the product in the

bathroom or other humid areas.

Your Quartet 1100 works by sending

and receiving radio signals between

the base unit and the handset.

The strength of the signal depends

on where you site the base unit and

how the aerial is deployed.

The higher the base unit is located,

the better. An upstairs room is ideal.

Your product can be wall mounted,

for more information see page 26.

1Plug the power supply

unit cord into the back

of the base unit

Quartet 1100 User Guide – Edition 4 – 7.8.00

Note

Do not connect the telephone line

cord to the phone socket until the

handset is fully charged. This will

prevent the risk of the phone being

answered before the batteries are

charged, which may prevent them

from reaching maximum capacity.

Note

When fully charged and in good

condition, the handset will provide

up to 7 hours talktime or 72 hours

standby.

If the handset battery is running

low, the IN USE/BATTERY LOW

light will flash every 10-15 seconds.

If you are making a call and the

handset battery is running low you

will hear a warning tone every

10-15 seconds.

Place the handset on the base unit

to recharge.

However, the charge capacity of

rechargeable batteries will reduce

with time as they wear out, so

reducing the talk/standby time of

the handset. Eventually they will

need to be replaced. New batteries

can be obtained from the BT shop

or from the Helpline.

To get the longest possible life

from your battery, take the handset

off the base unit for a few hours

each day.

WARNING

Under no circumstances should

non-rechargeable batteries be used.

Only use the approved batteries.

Using unapproved batteries will

invalidate your warranty and may

damage the telephone.

3Charge the handset

When you first use your Quartet 1100,

the rechargeable battery in the

handset needs charging for 24 hours.

Place the handset on the base unit,

ensuring the contacts are touching.

The red CHARGING light will come

on.

The charging light will remain

constantly lit while the handset is

placed on the base unit, even when the

handset batteries are fully charged.

Quartet 1100 User Guide – Edition 4 – 7.8.00

4Plug the telephone line

cord into the bottom of

the base unit and plug

the other end of the line

cord into the BT socket

Your Quartet 1100 is now ready for use.

Helpline

If you have any difficulties setting

up your Quartet 1100 please call

the Helpline on 0845 7697146.
