BT 3000 Classic Manuel utilisateur
Diverse 3000 ~ Edition 7 ~ 28th February ’01 ~ 3723
Diverse 3000 Classic
handset and charger
Digital cordless telephone
User Guide
This equipment is not designed for making emergency telephone calls when the power fails.
Alternative arrangements should be made for access to emergency services.
This product is intended for registration to any base in the BT Diverse 3000 range.
t may also be registered to other GAP compatible bases, with possible limited
availability of some features.
Diverse 3000 H_set & Charger 22/3/01 1:53 pm Page 1
Diverse 3000 ~ Edition 7 ~ 28th February ’01 ~ 3723
Please open this page for an ‘At a glance’ guide
to your Diverse 3000 Classic Handset and
Charger.
Diverse 3000 foldout 1 22/3/01 2:06 pm Page 2
Diverse 3000 ~ Edition 7 ~ 28th February ’01 ~ 3723
Please open this page for a ‘Further at a glance’
guide to your Diverse 3000 Classic Handset and
Charger.
Diverse 3000 foldout 2 22/3/01 2:06 pm Page 2
Diverse 3000 ~ Edition 7 ~ 28th February ’01 ~ 3723
1
R
INT
12
ABC
3
DEF
4
GHI
5
JKL
6
MNO
7
PQRS
8
TUV
9
WXYZ
#
✱0
Display
Displays the status
of your handset.
Memory
Enables speed
dialling of numbers
stored in the
memory.
Green phone
For making and
answering calls.
Key lock
Lets you lock
(and unlock) the
keypad to prevent
accidentally
pressing buttons.
Intercom
Enables internal
calls and call
transfer between
handsets.
Confirmation (OK)
Lets you confirm
settings.
Redial
Lets you redial the
last five external
numbers you
called.
Delete
Deletes digits
shown on the
display.
Recall
For use with
switchboards and
BT Select Services.
Also, press and
hold down to enter
a Pause in a stored
number.
Keypad
Red phone
Press to end a call.
Power
Press and hold
down to switch off
the handset.
Press and hold
down again to
switch back on.
Set
Lets you access
your phone’s
functions.
Used to store
numbers in the
memory.
At a glance
Diverse 3000 foldout 2 22/3/01 2:06 pm Page 1
Diverse 3000 ~ Edition 7 ~ 28th February ’01 ~ 3723
2
Handset display
Display buttons
These top three
buttons are also
used with icons
on the display
Scroll backwards
Scroll forwards
Confirm – OK.
OK
Charger
Contact points
Charger (back view)
Diverse 3000 foldout 1 22/3/01 2:06 pm Page 1
Diverse 3000 ~ Edition 7 ~ 28th February ’01 ~ 3723
Diverse 3000 H_set & Charger 22/3/01 1:53 pm Page 2
Diverse 3000 ~ Edition 7 ~ 28th February ’01 ~ 3723
3
At a glance 1
Quick Reference
Handset Display 4
Quick Guide 5
Introduction 6
Unpacking your Diverse
3000 Classic handset 6
Safety information 7
Setting up 9
Registering a new
Diverse 3000 Classic
handset with the base
station 10
Using your Diverse 3000
Classic Handset 13
Making and receiving
calls 14
Caller Display/
Call Waiting 15
Call timer 15
Making and transferring
calls between handsets 17
Using the memory to
store and dial numbers 18
Security features 20
Emergency numbers 22
Call barring and
Call enabling 24
In this guide
Hints and tips boxes
In this user guide, we’ve included
helpful tips and useful notes. They
are shown in a white box like this.
Using Caller Display and
Call Waiting 26
Using the Classic handset 27
Additional features 30
Using your
Diverse 3000 Classic
with a switchboard 38
Setting to Tone or
Pulse dialling 38
General information 41
Guarantee 41
Technical information 42
Switchboard compatibility 42
Help 43
Wall mounting 45
Index 46
Diverse 3000 H_set & Charger 22/3/01 1:53 pm Page 3
Diverse 3000 ~ Edition 7 ~ 28th February ’01 ~ 3723
Indicates an active signal with the base station.
Warning – no contact with base station.
Shows status of battery.
You have new callers listed in your Caller Display list.
Off hook.
EXT Connecting to an external caller.
NT Connecting to another handset, registered to the same
base station.
Handset locked.
PPause.
–
–
–Blank space.
Star button
–Hash button
Recall button
PIN Telephone PIN.
----
----
---- Keypad locked.
New answering machine message
JIndicates that the call in your caller display calls list was
answered.
R
#
✱
4
––
–
–
––
–
–
––
–
–
Quick Reference Handset
Display
---
Diverse 3000 H_set & Charger 22/3/01 1:53 pm Page 4
5
Diverse 3000 ~ Edition 7 ~ 28th February ’01 ~ 3723
Switch the handset
on and off
Switch keypad lock
on and off
Answer a call
Make an
external call
End a call
Redial a nu ber
Store a nu ber in
the e ory
Dial a nu ber fro
the Caller Display
calls list
Adjust the
handset volu e
Secrecy
Call another
handset
Transfer a call
Call all handsets
Put an external
caller on hold
while you ake
an internal call
Hold down for 1 second until you hear a long beep.
Hold down for 1 second until you hear a long beep.
to display last 5 numbers
0-9
location
e.g.
microphone off. microphone on.
then the handset number e.g.
3
.
then the handset number e.g.
2
then the handset number e.g.
3.
to end the internal call.
R
INT
✱
INT
INT
INT
R
INT
2
ABC
0
1
2
ABC
#
Quick Guide
Infor ation for the handset settings
Diverse 3000 H_set & Charger 22/3/01 1:53 pm Page 5
Diverse 3000 ~ Edition 7 ~ 28th February ’01 ~ 3723
If anything is missing, please
contact your place of purchase
immediately.
Diverse 3000
Classic handset
Charger
2 x rechargeable
batteries
Power adaptor
Battery
compartment cover
Belt Clip
Screws and
wall plugs
My additional handset PIN is
6
Introduction
Your Diverse 3000 Classic handset and Charger has been designed
for ease of use and ade to the high standards set by BT.
Your Diverse 3000 Classic handset and charger can be used with any
product in the Diverse range, (apart fro the Diverse 1000). Please
refer to your ain user guide for a co plete list of product features.
Unpacking your Diverse 3000
Classic handset
For your records
For guarantee purposes, proof of
purchase is required, so please
keep your receipt.
Date of purchase:
Place of purchase:
Serial number: On underside of unit.
Purchase price:
123
456
789
#
0
Diverse 3000 H_set & Charger 22/3/01 1:53 pm Page 6
