BT DIVERSE 4010 CLASSIC Manuel utilisateur

Diverse 4010 Classic ~ 12th Edition ~ 19th September ’01 ~ 4167

Diverse 4010 Classic

Digital Cordless Telephone

User

Guide

*YOU MUST

SUBSCRIBE TO A

CALLER DISPLAY AND

CALL WAITING SERVICE

BEFORE YOUR DIVERSE 4010

CLASSIC WILL DISPLAY THIS

INFORMATION A QUARTERLY

FEE IS PAYABLE

This e uipment is not designed for making emergency telephone calls when the power fails.

Alternative arrangements should be made for access to emergency services.

This product is intended for connection to analogue public switched telephone networks

and private switchboards in the United Kingdom.

The Art of Communication

Diverse 4010 Classic ~ 12th Edition ~ 19th September ’01 ~ 4167

lease open this page for an ‘At a glance’

guide to your Diverse 4010 Classic.

WXYZ

PQRS

8TUV

GHI

3DEF

5JKL

2ABC

6MNO

R䊳

At a glance

Option buttons

Lets you select from

the menu options shown

on the display.

Green phone

For making and

answering calls.

One button

Apart from being the

number one button,

hold down to access

your Voice Mail service

or answering machine.

In use light

Lights up to indicate an

incoming call, an alarm

call or when the handset

is in use.

Star/Bell

Switches the handset

ringer on and off.

Hash/Keyguard

Switches the keypad

guard on and off.

For use with

switchboards and certain

Network Services.

Keypad

Microphone

Display

Displays the status of

your handset.

Extra Directory

Used to store

10 additional names

and numbers.

Red phone

To end a call, return to

idle and turn the power

off and on.

Directory

Used to store and

dial numbers in the

directory.

Diverse 4010 Classic ~ 12th Edition ~ 19th September ’01 ~ 4167

Base

Contact points

Display option buttons

The OPTION buttons allow

you to select options within

each menu that are shown

on the display.

INT MENU-> ->

Idle Screen

Press the left side of the

button for INT or the right

side of the button for MENU.

Press the left side of the

button for and right side of

the button for when going

through the menu options.

andset display

Base underside

Page button

Power socket

Telephone line cord socket

Diverse 4010 Classic ~ 12th Edition ~ 19th September ’01 ~ 4167

In this guide

At a glance 1

Menu structure 4

Quick guide 6

Quick guide to handset

display icons 7

Introduction 8

Unpacking your Diverse 4010 Classic 8

For your records 8

afety information 9

etting up 10

Registering and charging

the handset 11

Using the telephone 15

Making and ending calls 15

Call timer 1

Name and number directory 1

Extra directory 18

Redial 19

Secrecy 20

Paging and Internal calls 20

Alarm clock 22

Caller Display and

other elect ervices 24

Caller Display 24

Calls list 24

Call Waiting 27

Call Divert 28

Withhold number 28

Ring Back 29

Voice Mail 29

Handset settings 31

Keyguard 33

Base station settings 34

Base Station PIN (Personal

Identification Number) 34

Using additional handsets

and bases 36

Registering additional handsets 3

Help 39

General information 41

Guarantee 41

Technical information 42

Switchboard compatibility 42

Setting pauses 44

Index 45

ints and tips boxes

In this user guide, we’ve included

helpful tips and important notes.

They are shown in boxes like this.

Diverse 4010 Classic ~ 12th Edition ~ 19th September ’01 ~ 4167

Menu tructure

1. Sel Services 1-1 Withhold No.

1-2 Call Waiting

1-3 Ringback Off

1-4 Call Divert

2. Alarm Clock Enter alarm call time

3 Audio Set 3-1 /Set Vol set

3-2 Ringer set

3-3 Melody set

4 Base Set 5-1 Audio Set up 5-1-2 Ringer Vol set

5-1-3 Melody set

5-2 Date/Time 5-2-1 Date Set

5-2-2 Clock Set

5-2-3 Clock Mode 5-2-3-1 24

5-2-3-2 12

5-3 System PIN enter

5-4 Base Reset default

5-5 Add Features 5-5-1 Dial Mode 5-5-1-1 Tone

5-5-1-2 Pulse

5-5-1-3 DTMF-EART

5-5-2 tbr 100 MS

120 MS

180 MS

250 MS

300 MS

600 MS

5-5-3 Repeater on/off

5-5-4 Barge In on/off

5 Voice Mail 6-1 Set key 1 6-1-1 Mailbox Input No.

6 Register hs PIN enter

Please note

If your handset is registered to a Diverse 4000 answering machine base, you will

have additional menu’s in No.6 Voice Mail. Please refer to your Diverse 4016 guide

to see what further menus are now available.

Diverse 4010 Classic ~ 12th Edition ~ 19th September ’01 ~ 4167

IMPORTANT

If you make a mistake, you can return to the previous menu by pressing the RED

P ONE button. If you keep pressing the RED P ONE button you will return to the

idle screen.

Menu structure for message handling

1 Ans M 01 / 02 (If handset is registered to an answering machine base)

Press to open list

2 Mailbox Takes you into your network messaging service

Press to open list e.g Call Minder (requires subscription)

3 Calls 02 / 06 3-1 Delete delete entry

Press to open list 3-2 Copy To Dir copy no. to directory

3-3 Time display date/time

3-4 Status indicate new/old

3-4-1 Missed

3-4-2 All

3-5 List Mode

3-6 Delete List

䊳

Menu structure for directory, redial list, extra directory

Opens directory

Opens redial list 1. Edit entry

Opens extra directory 2. New entry

3. Show entry

4. Del entry

Diverse 4010 Classic ~ 12th Edition ~ 19th September ’01 ~ 4167

Hold down

Select one of last 5 numbers

Add number

Call all or

Handset no. (e.g. 2)

Enter the date

Enter time

Enter the alarm time

ALARM CLOCK

OKOK

ALARM CLOCK

OKOKCLOCK SETOK

DATE/TIMEOKBASE SETMENU

OKDATE SET

OKDATE/TIMEOKBASE SETMENU

INT

OKH/SET VOLOKAUDIO SETMENU

SAVEOKOKCOPY TO DIRMENU

Quick guide

Commonly used handset functions and settings

Switch handset on/off

Switch keyguard on/off

Switch handset ringer on/off

Make an external call

To end a call

Redial a number

To store a number in

the directory

Dial from the directory

Dial from the Calls list

andset volume

Make internal call

Transfer call to handset

Set date

Set time

Set the alarm

Cancel the alarm

Diverse 4010 Classic ~ 12th Edition ~ 19th September ’01 ~ 4167

Quick guide to handset

display icons

Redial, lists up to the last 5 dialled number.

Indicates messages in the Calls list.

Flashes to indicate new messages.

For calling other handsets.

Opens the menu.

Shows the status of the handset battery.

Scroll through the menu.

Confirms the function displayed.

Scroll left and right when entering numbers or messages.

Deletes numbers/characters (from left to right).

Do not disturb/No tones.

Handset locked.

Displayed when the Alarm clock is set.

Shows the number of the handset and is displayed in top left hand corner.

eg.

Diverse 4010 Classic ~ 12th Edition ~ 19th September ’01 ~ 4167

Introduction

Unpacking your

Diverse 4010 Classic

If anything is missing, please contact

your place of purchase immediately.

One Diverse 4010

Classic base station

One Diverse 4000

Classic handset

One power supply

for the base station

One telephone

line cord

Two AA rechargeable

batteries

One belt clip

Battery

compartment cover

For guarantee purposes proof of

purchase is required so please keep

your receipt.

Enter your base station PIN code here:

For more information on your base PIN

codes see page 34.

For your records

Date of purchase:

Place of purchase:

INTRODUCTION

WXYZ

PQRS

TUV

GHI

DEF

JKL

ABC

MNO

䊳
