BROTHER

EMBROIDERY

SYSTEMS

Single-head cylinder arm machine

9/12 needles

Automatic color change

Quick-change 270º cap system

Jumbo bobbin

Cam-driven, single presser foot for fast,

quiet operation

Noise reduction feed mechanism

Automatic lubrication system

Automatic top and bottom thread trimmers

Maximum sewing speed of 1,200 spm

Adjustable tubular frame holder

Narrow machine design: machine will fit

through a 32'' door opening (with table

assemblies removed)

Trace mode for verifying location of designs

before sewing

Built-in 3.5'' floppy disk drive enables the

machine to run as an independent stand-alone

unit and able to read all popular embroidery

machine formats

Machine memory of 45 designs (a total of

480,000 stitches)

Back up or move forward through the design

in increments of 1, 10, or 100 stitches or by

color changes

Capable of sewing flat, tubular, and finished

cap items

Memory retention after machine shut-off

World-class engineers and designers staff Brother’s state-of-the-art

Research & Development Center in Japan where they are constantly

designing and refining embroidery technologies to solve embroidery

manufacturing challenges.

Since designing our first industrial sewing machine in 1928, Brother has enjoyed a reputation for

innovation. We incorporated years of industrial sewing machine knowledge and engineering expertise

into our line of computerized embroidery equipment. Case in point: the exclusive automatic oiling

system found on our single head models revolutionized the industrial sewing machine market when

Brother introduced it more than 70 years ago. And, the jumbo bobbin technology, another Brother

first, which has performed to the highest standards of excellence for more than 40 years is found on

all Brother computerized embroidery equipment.

AUTOMATIC LUBRICATION SYSTEM

EASY-TO-USE CONTROL PANEL

Brother’s unique wick oiling system significantly reduces machine maintenance

downtime. Oil is poured into a conveniently located reservoir on the machine, and a

wick that is threaded through the internal workings of the sewing head delivers oil

when and where it is needed, eliminating the time-consuming task of oiling

numerous hard-to-reach locations.

Developed by Brother, the cam-driven presser foot allows the machine to run faster and

quieter. The precise movement of the cam reacts faster than the previous spring-loaded

technology and reduces the noisy pounding of the presser foot on the throat plate. The

single presser foot also facilitates increased machine speed and less maintenance.

JUMBO BOBBIN

Maximize system productivity with fewer bobbin changes with the larger capacity,

jumbo “M” style bobbins. Brother perfected the performance of the jumbo bobbin by

designing the cams and gears inside the sewing head to accommodate the longer

rotation of the larger bobbin.

Start sewing faster with the simple, logical commands found on the control panel. For

example, the hoop feed button moves the pantograph out from under the needles for

trouble-free applique placement and easier loading and unloading of hoops.

MEMORY RETENTION

Resume stitching a partially complete design after the machine has been turned off,

unplugged, or even after power failure. Shut the machine off to work with a customer,

go home for the evening, or even move the machine across town and never lose a

stitch or go off registration — another Brother first.

SINGLE CAM-DRIVEN PRESSER FOOT

INDIVIDUAL CAP FRAME ADJUSTMENT

Adjust the center point of the cap on each head independently while it’s in the frame

and mounted on the machine. Eliminate off-center designs and time-consuming

framing adjustments with this advanced cap frame driver design.

• Machine type: Single-head cylinder arm

• Number of needles: 9/12

• Maximum sewing speed: 1,200 spm

• Network capability: Connect multiple machines to

one computer for networking

• Stitch length: (0.1mm – 12.7mm)

• Rotary hook: Jumbo “M” style bobbin

• Maximum field size for: X-axis “width” Y-axis “height”

PRODUCT SPECIFICATIONS:

Number of units connected

to computer

Display Computer monitor

To 4 units

Computer control type Stand-alone type

N/A

Operation panel display

• Flat: 450mm 300mm

• Tubular: 450mm 300mm

• Border: 450mm 300mm

• Wide area caps: 360mm 85mm

• Power source/consumption: Single phase 120V,

220V, 230V, 240V

• Dimensions:At delivery: 34”(W) x 29”(L) x 55”(H)

• After setup: 41”(W) x 40”(L) x 58”(H)

• Weight: 195 kg. / 430 lbs.

QUICK-CHANGE

TUBULAR FRAME HOLDER

Two-piece tubular frame holder

allows for quick and easy conversion

from small to large tubular frames.

Frame holder can be adjusted to

accommodate a wide range of frame

sizes, from large jacket back frames

to small sock and pocket frames.

QUICK-CHANGE CAP

FRAME (optional)

All-in-one cap driver and frame

assembly allows for quick and easy

conversion from sewing caps to flat

or tubulargoods, again minimizing

machine downtime. Sew designs

from “ear to ear” with the wide-area

270-degree frames.

FLAT FRAME AND

REMOVABLE TABLE TOP

The table provides additional

support when stitching flat goods

such as towels or blankets.

BORDER (SASH)

FRAME (optional)

Frame for sewing unfinished

goods for patches or all-over

embroidery patterns.

100 Somerset Corporate Blvd., Bridgewater, NJ 08807 Industrial Embroidery Machines: 1-800-432-3532, Fax: 1-908-575-3810,

Web site: www.brother.com The PAS Store: 1-877-850-7179, Fax: 1-877-667-8882, Web site: www.brothermall2.com
