This Quick Start Guide applies to QmC NEMA 1 IP40 Meter/Controller

Quick Start Guide

Coriolis Mass Flow

Quantim®Coriolis Mass Flow Controllers

& Meters

(QmC)

Flow

Step 1: Location/Orientation

The instrument may be located anywhere in the process line,

as long as the following conditions are met:

• Beforeoperation,youmustbeabletostopowthrough

themeter.Duringthezeroingprocedure,owmustbe

stoppedcompletely,andtheowmetersensortubemust

befullofprocessuidtoachieveanaccuratezero.

• Duringoperation,theowsensortubemustbefullof

processuid.

• Ambient temperature must remain between 0° and 60°C

(32°F and 140°F).

• The instrument (cable connections, wiring compartments

and/orconduitopenings)shouldbeaccessibleforservice.

Horizontal Down Mounting

Preferred mounting orientation

for most LIQUID applications:

• Sensor tube DOWN

• Horizontal pipeline

Horizontal Up Mounting

Preered mounting for

most GAS applications:

• Sensor tube UP

• Horizontal pipeline

Vertical Mounting

Orientation for LIQUID

applications where entrapped

gas may occur:

• Flag mount

• Vertical pipeline

1-1

1-2

1-3

Step 2: Mounting the Quantim

Mount the device in the

proper orientation and

location for your process.

2-2

2-1

After mounting the

device connect the

process lines. Carefully

tighten the process lines, using

two (2) wrenches to prevent

rotation of the inlet/outlet tting.

Flow

2.5mm DIAGNOSTIC PORT

DSUB 15 PIN

ZERO BUTTON

ACCESS PORT

LED STATUS LIGHT

Step 3: Electrical Connections

NEMA 1 / IP40 Meter/Controller

D-Connector Functions Legends:

• = Feature Available

N/A = Not Available

NOTE: Chassis ground is available through the D-Connector back

shell.

D-Connector for QmC NEMA 1 / IP40

Pin Out Connections

3-A1

3-A2

Pin Function Controller Meter

1 Setpoint Common * N/A

2 0-5(10) Volt Flow Output * *

3 (TTL) Open Collector Alarm Output * *

4 (0)4-20 mA Flow Output * *

5 Power Supply (14-27 V) * *

6 Not Connected N/A N/A

7 (0)4-20 mA Setpoint Input * N/A

8 0-5(10) Volt Setpoint Input * N/A

9 Power Common * *

10 Signal Out Common * *

11 Not Connected N/A N/A

12 ValveOverrideInput * N/A

13 Density or Tempertaure output,

Current or Voltage

* *

14 RS-485, B(-) Input/Output * *

15 RS-485, A(+) Input/Output * *

Receipt of Equipment

Whentheequipmentisreceived,theoutsidepackingcaseshould

be checked for damage incurred during shipment. If the packing

caseisdamaged,thelocalcarriershouldbenotiedatonce

regarding his liability. A report should be submitted to the nearest

BrooksInstrumentlocationlistedontheGlobalServiceNetwork

page on our website: brooksinstrument.com/service-support

Removetheenvelopecontainingthepackinglist.Carefullyremove

the instrument from the packing case. Make sure spare parts are

not discarded with the packing materials. Inspect for damaged or

missing parts.

Return Shipment

Priortoreturninganyinstrumenttothefactoryforanyreason,visit

our website for instructions on how to obtain a Return Materials

Authorization Number (RMA #) and complete a Decontamination

Statement to accompany it: brooksinstrument.com/service-support

All instruments returned to Brooks also require a Material Safety

DataSheet(MSDS)fortheuid(s)usedintheinstrument.Failure

toprovidethisinformationwilldelayprocessingoftheinstrument.

Instrumentmusthavebeenpurgedinaccordancewiththe

following:

Equipment Receipt and Return Procedures

Aftertheowmeterorowcontrollerhasbeeninstalledinthe

system it is ready for operation.

Meter: Themeterwillprovideaowsignalproportionaltothe

fullscaleowofthedeviceasindicatedonthedevicelabel.

Controller: Youmustprovideasetpoint/commandsignaltothe

controller. The controller will read the setpoint signal and will

automaticallyadjustthevalvetotheappropriatepositionto

achievethedesiredowandwillprovideaowsignal

proportionaltothefullscaleowofthedeviceasindicatedon

thedevicelabel.

Step 4: Zeroing Procedure

To assure measurement accuracy, the instrument must be

zeroed to the operational installation conditions:

• Apply power to instrument for approximately 45 minutes to

reachastablethermalconditionpriortoapplyingow.

• Flowtheprocessuidintotheinstrumentandallowsu󰀩cient

time for the sensor to reach normal operating temperature.

• Closetheshuto󰀨valvedownstreamtoeliminateanypressure

 di󰀨erentialacrosstheinstrument.

• AfterconrmingaNOowcondition,pressthezeroingbutton

for at least 3 seconds

• Zeroing button is located on the side of the instrument’s

housing.

• The zeroing process takes approximately 60 seconds. Status

lightwillashred.

• A solid Green LED means a successful zero.

• A solid Red LED means an unsuccessful zero.

Note: If solid Red LED is indicated, recycle power and repeat

zeroingprocedureorcontactTechnicalServicesatBrooks

Instrument

Step 5: Operation

P/N: 541B236AAG/A

Reference: 834z986

Brooks and Quantim are trademarks of Brooks Instrument, LLC.

All other trademarks are property of their respective owners.
