Broadcast Tools DAS 8.4 Plus Manuel utilisateur

Installation and Operation Manual

Due to the dynamic nature of product design, the information contained in this

document is subject to change without notice. Broadcast Tools, Inc., assumes no

responsibility for errors and/or omissions contained in this document. Revisions

of this information or new editions may be issued to incorporate such changes.

Broadcast Tools® is a registered trademark of Broadcast Tools, Inc.

No part of this document may be reproduced or distributed without permission.

Visit www.broadcasttools.com for important product update information.

Firmware Version 1.9

Manual Update: 07/07/2011

DAS 8.4 Plus

Eight Input, Four Output AES/EBU Digital Audio Routing Switcher

INC

e-mail: [email protected] voice: 360.854.9559 fax: 866.783.1742

DAS 8.4 Plus Installation and Operation Manual

Table of Contents

Section Title Page #

Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Who to Contact for Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Product Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Installation Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Setting Operation “Dip” Switches:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Power-Up Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Macro Feature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Mounting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Power Supply Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Connecting Inputs/Outputs/Relays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Input Channel Expansion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Remote Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Serial Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Multicast Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Connecting the RS-232 Serial Port. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Serial Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Set-up Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Output Port Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

“PIP” Connector Digital Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Schematic and Component Layout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Appendix

Installation Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Appendix

WEBSITE:

Visit our web site for

product updates and

additional information.

TABLE OF CONTENTS

e-mail: [email protected] voice: 360.854.9559 fax: 866.783.1742

DAS 8.4 Plus Installation and Operation Manual

INTRODUCTION

Thank you for your purchase of a Broadcast Tools® DAS 8.4 Plus, Eight Input, Four

Output Digital Audio Routing Switcher (referred to as the DAS 8.4 Plus throughout

this manual). We’re confident that this product will give you many years of depend-

able service. This manual is intended to give you all the information needed to

install and operate the Broadcast Tools® DAS 8.4 Plus.

SAFETY INFORMATION

Only qualified personnel should install Broadcast Tools® products. Incorrect or

inappropriate use and/or installation could result in a hazardous condition.

Broadcast Tools, Inc., is unable to support NON-Broadcast Tools software, hardware or

NON-Broadcast Tools computer/hardware/software problems. If you experience these

problems, please research your hardware/software instruction manuals or contact the man-

ufacturers technical support department.

WHO TO CONTACT FOR HELP

If you have any questions regarding your product or you need assistance, please con-

tact your distributor from whom you purchased this equipment.

If you would like more information about Broadcast Tools® products, you may

reach us at:

Broadcast Tools, Inc.

131 State Street

Sedro-Woolley, WA 98284-1540 USA

Voice: 360.854.9559

Fax: 866.783.1742

Internet Home Page: www.broadcasttools.com

E-mail: [email protected]

THANK YOU FOR CHOOSING

BROADCAST TOOLS® BRAND PRODUCTS!

CAUTION!

Broadcast Tools®

Products, as with any

electronic device, can

fail without warning.

Do not use this product

in applications where a

life threatening condition

could result due to failure.

NOTE:

This manual should be

read thoroughly before

installation and operation.

WEBSITE:

Visit our web site for

product updates and

additional information.

Broadcast Tools is a Veteran Owned Business

Designed, Assembled and Supported in WA State, USA

e-mail: [email protected] voice: 360.854.9559 fax: 866.783.1742

DAS 8.4 Plus Installation and Operation Manual

DESCRIPTION

Product Description

The Broadcast Tools DAS 8.4 Plus provides AES/EBU digital audio

routing/switching of any one of eight AES/EBU inputs to any/or all four AES/EBU

outputs. The DAS 8.4 Plus may be used in Multicast applications, where an AES

enabled EAS device assigned to input eight is routed to all four outputs via a con-

tact closure or serial command. When the alert/test is completed, the DAS 8.4 Plus

will return to its previous I/O configuration. The DAS 8.4 Plus may be controlled

via front panel switches, contact closures, 5-volt TTL/CMOS logic and/or the multi-

drop RS-232 serial port. The front panel is equipped with input and output selection

pushbuttons, output assignment LED’s, sample rate LED indicators and a headphone

amplifier with a front panel T/R/S/ jack and level control. Additional features: 96

KHz AES receiver, a 24-bit D/A converter with analog balanced stereo output, head-

phone amplifier and 16 x 16 GPIO port. Installation is simplified with plug-in

euroblock screw terminals. 1-RU chassis

Additional Features

• Routing type switching, any one input may be assigned to any/or all outputs.

• Multicast function and remote control port

• Logic functions via microprocessor and non-volatile memory

• Internal digital/analog audio activity/silence sensor monitors any one of four

output channels selectable with the front panel monitor switch. The unit is

equipped with four front panel sample-rate LED indictors, SS, AES/EBU

Digital Error and stereo 10-LED meters; adjustable analog Silence Sensor/AES

Digital error alarm delay and restore duration. Analog silence sensor sensitivi-

ty is factory set at -30db.

• Front panel input selection switches are provided for each input channel with

separate output indicator LEDs.

• Power-up selection of inputs to outputs, mute or last source selected.

• Eight user configured macros.

• Most configuration options via rear panel dipswitches.

• 16 input GPI port (Remote Control or PIP) with LED indicator.

• 16 open collector channel status outputs or programmable via burst commands.

• Remote control of front panel functions and status.

• Multi-drop RS-232 serial port with data activity LED.

• Multiple units may be looped-thru to expand outputs.

• Plug-in euroblock screw terminals for ALL connections.

• Multi-voltage power supply (220v CE, optional).

e-mail: [email protected] voice: 360.854.9559 fax: 866.783.1742

DAS 8.4 Plus Installation and Operation Manual

DESCRIPTION

Front Panel:

The DAS 8.4 Plus is a 1 - RU device (19”w x 1.75”h x 10”d). The front panel

supports 15 selection switches and 43 LED indicators.

Rear Panel:

Installation is simplified with plug-in euroblock terminals. The DAS 8.4 Plus

may be pre-wired and installed in minutes. The multi-drop RS-232 modular con-

nection and a 7-pin DIN power connector are provided for the supplied multi-volt-

age power supply.

Switches:

Fifteen pushbutton switches (The “PGM” switch is hidden) that may be used to

mute or select input and output channels. Eight macros may also be programmed

and selected.

LED Indicators:

The DAS 8.4 Plus’s 43 front panel LED indicators provide operational display

of the following information:

• Four indicators per input channel display which output channel the input is con-

nected.

• Sample rate display of 32, 44.1, 48 and 96Khz

“PIP” Parallel Input Port active, indicating any change with the 16 input ports

• Monitored Output channel being monitored.

• Macro select LED indicator

• Silence sensor alarm LED

• AES/EBU sample rate led indicator

• AES/EBU digital “error” led indicator.

• Stereo, 10 LED meter.

• Unit power and serial data activity.

Controls:

AES Inputs:

Each of the eight AES inputs is supplied with an adjustable termination for 75

ohm, 110 ohm or no termination.

AES Outputs:

The DAS 8.4 Plus provides four selectable AES outputs.

WEBSITE:

Visit our web site for

product updates and

additional information.

e-mail: [email protected] voice: 360.854.9559 fax: 866.783.1742

DAS 8.4 Plus Installation and Operation Manual

DESCRIPTION

AES/EBU Digital, Analog Audio and Activity Sensor.

The DAS 8.4 Plus contains an 8 - 96kHz AES receiver and 24-bit D/A convert-

er. The AES receiver may monitor any one of the four AES outputs with the front

panel monitor selector switch. The AES receiver provides data integrity information

to the microcontroller, which is used to indicate a data error. The D/A converter fur-

nishes a stereo feed to the balanced analog audio output amplifier, headphone ampli-

fier and level control, along with the stereo 10-LED meter and silence sensor cir-

cuitry. The factory default time delay and restore delay is set at 10 seconds, with a

fixed signal threshold of -30dB. Upon silence detection for the user-selected time,

the serial “SS/DIG Error” status is sent. When audio returns and the restore time

delay has expired, the serial “SS/DIG Error” status is sent. The “SS/DIG Error” may

be programmed for:

• Number of seconds of silence that must be present before an alarm state is

reached.

• Number of seconds of audio presence after an alarm state before the

“SS/AES/EBU “DIG Error” led illuminates.

PIP Input:

The Parallel Input Port (GPI) provides 16 pulse-stretched parallel 5-volt

TTL/CMOS compatible inputs. The inputs are pulled high to 5 volts through a

20KΩresistor and are activated by pulling the input to ground for a minimum of

40ms. These inputs supply status to any serial polling device (when the unit ID is

set to 0, no polling of inputs is required). For all PIP inputs a pulse of specified min-

imum input duration (000 to 2.55 Seconds) causes the status to go true until the end

of the input pulse. The pulse width may vary between the specified value and 10 ms

less than that value. This allows the polling computer more time to detect an input

change.

“Open Collector” Status Outputs, 16 Port Output Control

The DAS 8.4 Plus provides sixteen open collector status outputs. The status out-

puts may be configured to operate in one of three modes:

• The status outputs follow the first eight-associated channel.

• The status outputs a one-second pulse when the first eight-associated channel is

selected.

• RS-232 serial burst mode control

e-mail: [email protected] voice: 360.854.9559 fax: 866.783.1742

DAS 8.4 Plus Installation and Operation Manual

DESCRIPTION

Serial Communication:

The DAS 8.4 Plus’s serial communication is configured for multi-drop RS-232,

allowing up to 8 - DAS 8.4 Plus’s on the same computers serial port. Burst mode

allows a computer or ASCII terminal to control and interrogate the unit. This section

defines all burst mode commands. Each burst mode commands starts with an aster-

isk (“*”). Next is a single decimal digit that corresponds to the unit (ID) address 0-

7. Following that are one or more ASCII characters specifying the command. No

carriage-return or line-feed is required to terminate the command except for those

few commands of variable length, if the maximum length is not sent. If acknowl-

edgements are enabled, successful commands are responded to with “RRR” while

errors get an “EEE” response. The syntax of each command is given below. The

syntax shows the command exactly as it should be sent, except that lower case char-

acters represent values that should be substituted:

User Programming:

The DAS 8.4 Plus programming is stored in non-volatile memory.

Configurations are set with selection dipswitches and computer commands.

Inspection:

Please examine your DAS 8.4 Plus carefully for any damage that may have been

sustained during shipping. If any is noted, please notify the shipper immediately and

retain the packaging for inspection by the shipper. The package contains the DAS

8.4 Plus, Multi-voltage “Lump-n-Line power supply, plug-in euroblock screw ter-

minal mating plugs, Installation manual, reversed modular serial cable and the 9-pin

D-Sub (S 9) adapter.

Setting Operation “DIP” Switches:

The DAS 8.4 Plus is equipped with an 8-position “PGM” DIP Switch. The DIP

Switch specifies 3-bit unit ID, baud rate, power-up modes, remote control and other

features listed below. The dipswitch (SW16) is located on the rear panel.

DIP (SW16) Switch Functions

Switch Default

Number Setting Function

1 OFF Add 1 to Address (base address is 0)

2 OFF Add 2 to Address (base address is 0)

3 OFF Add 4 to Address (base address is 0)

4 OFF Baud Rate: OFF = 9600, ON = 38400

5 OFF Open Collector Operation Mode

6 OFF Open Collector Operation Mode

7 OFF Power up mode (Off = User programmable)

8 OFF PIP/Remote Control (Off = Remote Control)

WEBSITE:

Visit our web site for

product updates and

additional information.

e-mail: [email protected] voice: 360.854.9559 fax: 866.783.1742

DAS 8.4 Plus Installation and Operation Manual

INSTALLATION

Installation Guidelines

Address (ID) DIP Switches

SW16-1 SW16-2 SW16-3 ID

OFF OFF OFF ID = 0

ON OFF OFF ID = 1

OFF ON OFF ID = 2

ON ON OFF ID = 3

OFF OFF ON ID = 4

ON OFF ON ID = 5

OFF ON ON ID = 6

ON ON ON ID = 7

Baud Rate DIP Switch

SW16-4 Function

OFF 9600 baud

ON 38400 baud

Open collector DIP Switch

SW16-5 Function

OFF Follow (See SW16-6)

ON Pulse (See SW16-6)

Open Collector Operation Switch

SW16-6 Function

OFF Enable SW16-5

ON OC’s software control

Power up/Last source DIP Switch

SW16-7 Function

OFF User Programmable

ON Last Source(s) selected

PIP/Remote Mode DIP Switch

SW16-8 Function

OFF Remote Control

ON PIP inputs enabled

Front Panel Switches

Switch(es) Function

01-08 Channel Inputs

OUTPUT 1,2,3,4 Output selector

MUTE Mutes selected channel

MACRO Selects up to 8 Macro’s

MONITOR Selects the four output channels to monitor

e-mail: [email protected] voice: 360.854.9559 fax: 866.783.1742

DAS 8.4 Plus Installation and Operation Manual

INSTALLATION

Result

Selected input channel is connected to

output 1. To mute the active channel,

simultaneously hold down the mute

switch and press the desired input chan-

nel button.

Hold down the Output 2 button, then

push the desired input channel button

Selected input channel is connected to

output 2. To mute the active channel,

simultaneously hold down the mute

switch and press the desired input chan-

nel button.

Hold down the Output 3 button, then

push the desired input channel button

Selected input channel is connected to

output 3. To mute the active channel,

simultaneously hold down the mute

switch and press the desired input chan-

nel button.

Hold down the Output 4 button, then

push the desired input channel button

Selected input channel is connected to

output 4. To mute the active channel,

simultaneously hold down the mute

switch and press the desired input chan-

nel button.

Operation

Action

Hold down the Output 1 button, then

push the desired input channel button

Hold down the Output 2 button, then

push the desired input channel button

Hold down the Output 3 button, then

push the desired input channel button

Hold down the Output 4 button, then

push the desired input channel button

NOTE: To mute any/or all output

channels assigned to an input, hold

down the mute button and press the

desired input button.

WEBSITE:

Visit our web site for

product updates and

additional information.

e-mail: [email protected] voice: 360.854.9559 fax: 866.783.1742

DAS 8.4 Plus Installation and Operation Manual

INSTALLATION

Power-Up Feature, user programmable:

To select a channel configuration at power-up:

1 - Verify that dipswitch SW16-7 is OFF.

2 - Select the desired input and output channel configuration.

3 - Press and hold the “MACRO” button.

4 - Press the “OUTPUT 1” button.

5 - The macro led will flash for 2 seconds.

6 - Release both switches.

7 - Your power up configuration is saved.

Power-Up Feature, last source selected:

1 - Verify that dipswitch SW16-7 is ON.

2 - The DAS 8.4 Plus will power up with whatever channel configuration was

present at power off.

Storing a Macro:

1 - Select the desired input and output channel configuration.

2 - Press and hold both the “MACRO” and “OUTPUT 2 buttons.

3 - Press the desired input channel button.

Example: Pressing channel 1 would store it as Macro 1.

Recalling a Macro:

1 - Press and hold the “MACRO” button.

2 - Press the desired stored macro’s using the input channel buttons.

Multicast Mode:

Verify that dipswitch SW16-8 is OFF. Connect the output of your AES enabled

EAS unit to AES input eight. Connect the sustained relay contacts of your EAS unit

between ground and remote control input 16 on the DAS 8.4 Plus. When the EAS

unit trips, the DAS 8.4 PLUS will switch AES input eight to all four AES outputs.

The four led’s associated with input eight will start to flash in sequence. When the

alert/test is completed, the relay contact of the EAS unit should open and the DAS

8.4 Plus will return to its previous I/O configuration. NOTE: You may also put the

DAS 8.4 Plus into Multicast mode via serial commands listed on page 16.

Note: To convert your EAS unit from analog audio to AES digital audio, check out

either of the Broadcast Tools Analog to Digital converters: ADCS-III or ADC-1

Mounting:

The DAS 8.4 Plus is designed to be rack mounted in a standard 19” rack, (1-RU).

It should be mounted in an area that is accessible from the rear and preferably away

from sources of heat. We recommend before permanently installing the DAS 8.4

Plus that you bench test and become familiar with the operation of the unit.

Table des matières

Autres manuels Broadcast Tools Changer

Broadcast Tools

Broadcast Tools SS 2.1 BNC Manuel utilisateur

Broadcast Tools

Broadcast Tools SS 16.2 Manuel utilisateur

Broadcast Tools

Broadcast Tools 38511 Manuel utilisateur

Broadcast Tools

Broadcast Tools AES Switcher Sentinel 4 XLR Manuel utilisateur

Broadcast Tools

Broadcast Tools Universal 4.1 MLR Manuel utilisateur

Broadcast Tools

Broadcast Tools AES Switcher Sentinel 4 Manuel utilisateur

Broadcast Tools

Broadcast Tools SS 2.1 MLR/TERM Manuel utilisateur

Broadcast Tools

Broadcast Tools ROS-16 Manuel utilisateur

Broadcast Tools

Broadcast Tools SS 2.1 MLR/RJ Manuel utilisateur

Broadcast Tools

Broadcast Tools ROS Manuel utilisateur

Broadcast Tools

Broadcast Tools 8 x 2A Manuel utilisateur

Broadcast Tools

Broadcast Tools DMS-III Manuel utilisateur

Broadcast Tools

Broadcast Tools AES Switcher Sentinel 2+1 Manuel utilisateur

Broadcast Tools

Broadcast Tools Audio Sentinel 4 Web Manuel utilisateur

Broadcast Tools

Broadcast Tools SS 8.1 MLR Manuel utilisateur

Broadcast Tools

Broadcast Tools RM-3 Manuel utilisateur

Broadcast Tools

Broadcast Tools ACS 8.2 Plus Manuel utilisateur

Broadcast Tools

Broadcast Tools SS 8.1 MLR Manuel utilisateur

Broadcast Tools

Broadcast Tools SS 4.1 III Manuel utilisateur

Broadcast Tools

Broadcast Tools Universal 4.1 MLR/Serial Manuel utilisateur

Broadcast Tools

Broadcast Tools SS 4.2 Manuel utilisateur

Broadcast Tools

Broadcast Tools SS 4.1 Plus Manuel utilisateur

Broadcast Tools

Broadcast Tools Sentinel 3 Manuel utilisateur

Broadcast Tools

Broadcast Tools SS 8.1 II Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
