Broadata LINKBRIDGE LBC-PSW52 Manuel utilisateur
LINKBRIDGE™ PRESENTATION SCALING SWITCH
with 5 Inputs and Two Mirrored Outputs
BCI reserves the right to make changes to the products described herein without
prior notice or consent. No liability is assumed as a result of their use or application.
All rights reserved.
©2019 Broadata Communications, Inc.
LBC-PSW52
USER MANUAL
HDBaseT 18G/4K Multi-Format Presentation Switch w/ 5 Inputs and 2 Mirrored Outputs User Manual (LBC-PSW52)
SAFETY INSTRUCTIONS AND COMPLIANCE DECLARATION
PLEASE OBSERVE THE FOLLOWING SAFETY PRECAUTIONS
SURGE PROTECTION DEVICE RECOMMENDED
This product contains sensitive electrical components that may be damaged by
electrical spikes,surges,electric shock,lightning strikes, etc. Use of surge proctection
system is highly recommended in order to protect and extend the life of your
equipment.
DC POWER CONNECTION
HDBaseT 18G/4K Multi-Format Presentation Switch w/ 5 Inputs and 2 Mirrored Outputs User Manual (LBC-PSW52)
3
Do not use this device near water/liquids. This device should not be exposed to dripping and
splashing or liquids.
Clean only with dry cloth.
Do not use solvents such as paint thinners and acetone to clean external casing. Such
agents will remove any labels on the device.
Do not block any ventilation openings.
Do not install near any sources of intense heat such as radiation, boilers, or other equipment
that produce heat
Not intended for use/storage in close proximity of critical medical supplies such as those that
might come into direct contact with patients or medical sta.
Protect the power cord from being pinched or damaged at receptacles and the point of exit
from the device.
Only use attachment /accessories specified by manufacturer. If you have any questions
about the compatibility of an accessory, contact your dealer.
In case liquid spillage on device, unplug mains power cord and contact your dealer. Continu-
ous use in this case may result in fire or electric shock.
To reduce the risk of electric shock, do not touch connectors with wet hand.
Only power with the marked voltage on the device. Any other voltage can cause fire or elec-
tric shock.
Do not use the device if an abnormality occurs. If any smoke or odor becomes apparent, un-
plug the power cord and contact your dealer. Do not try to repair the device yourself.
Avoid using physically damaged devices. If your device metal housing is seriously physically
damaged, the internal components may function abnormally. Contact your dealer.
Do not install the device in an area heavy with dust or constant high humidity. Operating the
device in this case may result in fire or electric shock.
Only use supplied power supply. For a list of other compatible power supplies, contact your
dealer.
Install this device in a secure location where it cannot be easily pushed or knocked over.
TABLE OF CONTENTS
HDBaseT 18G/4K Multi-Format Presentation Switch w/ 5 Inputs and 2 Mirrored Outputs User Manual (LBC-PSW52)
PRODUCT DESCRIPTION
OPERATION CONTROL AND FUNCTIONS
FRONT/REAR PANEL
CONNECTOR PIN OUT ASSIGNMENT
WEB GUI CONFIGURATION
API COMMANDS RS232 & TELNET
OSD MENU
SPECIFICATIONS
MAINTENANCE AND TROUBLESHOOTING
SERVICE PROCEDURE
REPLACEMENT POLICY
RETURN AND REPAIR SERVICE
LIMITED WARRANTY
5
7
7
11
12
19
26
35
38
39
39
39
40
1.0
2.0
2.1
3.0
4.0
5.0
5.1
6.0
7.0
8.0
9.0
10.0
5
PRODUCT DESCRIPTION
HDBaseT 18G/4K Multi-Format Presentation Switch w/ 5 Inputs and 2 Mirrored Outputs User Manual (LBC-PSW52)
The LinkBridge™ HDBaseT Presentation Scaling Switch is a compact and robust switch that
oers compact video and audio extension with the ability to scale 5 video inputs to 2 mirrored
outputs. The Scaling Switch is capable of extending audio/video signals up to 70 meters over
HDBaseT CAT 5e/6 cabling. An easily accessible source selection buttons allows you to select
5 Video Input signals and simultaneously send 2 audio/video output signals for a wide variety
of applications. All while transmitting fully uncompressed Ultra HD and HDTV video resolutions
up to 1080p @ 60Hz.
FEATURES:
• Compact presentation scaling switch oers 5-Video Inputs (2-HDMI, 1-Display Port
and 2-VGA Inputs) to support a wide range of applications
• Source selection oers the simultaneous output of 2-video signals through HDBaseT
and HDMI
• Extends HDMI/DisplayPort/VGA up to 70 meters over CAT 5e/6
• Scaling of any analog/digital video signal, up to 1080p & WUXGA to HDMI and
HDBaseT protocol output
• Supports control via RS-232, Telnet, WebGUI, front panel control buttons or contact
closures
• HDBaseT output supports remote powering
• Supports one microphone input (with phantom power), three unbalanced audio input
and one stereo audio output
• Works with all LinkBridge LBH & LBC Series transmitters and receivers
IDEAL FOR:
• Household entertainment sharing and control
• Lecture room display and control
• Showroom display and control
• Meeting room presentation and control
• Classroom display and control
6PRODUCT DESCRIPTION
HDBaseT 18G/4K Multi-Format Presentation Switch w/ 5 Inputs and 2 Mirrored Outputs User Manual (LBC-PSW52)
PACKAGE CONTENTS
• 1- HDBaseT LinkBridge™ HDBaseT Presentation Scaling Switch1
• 1- 24V/1A DC Power Adapter
• 1- Power Cord
• 1- Remote Control
• 1- Operation Manual
SYSTEM REQUIREMENTS
• Source equipment such as media players, video game consoles, PCs, or set-top
boxes.
• A compatible HDBaseT receiver
• The use of Premium High Speed HDMI cables, and industry standard CAT5,
CAT6a or CAT7 is highly recommended.
7
OPERATION CONTROL AND FUNCTIONS
HDBaseT 18G/4K Multi-Format Presentation Switch w/ 5 Inputs and 2 Mirrored Outputs User Manual (LBC-PSW52)
FRONT PANEL
LBCPSW52
1
“Menu” Button: Press this button to enter On Screen Display (OSD)
menu.
“-“ (Minus) Button: Press button to navigate down on OSD menu.
“+” (Plus) Button: Press button to navigate up on OSD menu.
“Lock” Button: Press this button to lock front panel.
LEDs: This LED for selected source indication. The LED
for the selected source will illuminate for indicating
active source.
IR Window: Receiving IR signal from remote control unit which
comes with scaler box.
“Enter” Button: Press this button to confirm the selection on On Screen
Display (OSD) menu.
“Select” Button: Press this button for source selection. The active source
will be indicator on LEDs at front panel.
1
2
3
4
3
5
24
LOCK
+
-
ENTER
MENU
SELECT
HDMI
1
DPHDMI
2
1
PC
2
PC LOCK
6
7
56 7
8OPERATION CONTROL AND FUNCTIONS
HDBaseT 18G/4K Multi-Format Presentation Switch w/ 5 Inputs and 2 Mirrored Outputs User Manual (LBC-PSW52)
REAR PANEL
LBCPSW52
13
2456 7 8 9
PC 1LINE INMIC INSERVIC IE R OUT IR IN RS232 COM PORT
LINE OUT
CAT5e/6/7 OUTHDMI OUTHDMI 2HDMI D1 ISPLAY PORT
INPUT CONTROL
C12345
CONTROL
OFF
ON
PHANTOM
PC 2PC 1
DC 24V
PC 2
Service: The service slot is for firmware update via USB.
Line Out: Connects with amplifier for audio source broadcasting.
MIC IN: Plug microphone in for audio source output. The phantom
micro phone is well supported.
Phantom On/O: Arrange the slide switch to “on” for condenser micro
phone (5V) or “phantom” for professional 48V phantom
microphone. When slide switch arrange to “o”, the
audio output will be mute.
Line In: To output HDMI embedded audio of HDMI 1, 2 and display port
source to DVD players.
PC1 / PC2: To output HDMI embedded audio of PC1 and PC2 source to
DVD players.
IR Out: Connect with supplied IR blaster cable to sending IR single
which comes from remote control unit to compatible Receivers.
IR In: Connect with supplied IR extender cable to receive the IR
signal from the included IR remote. Ensure that the remote is
within the direct line-of-sight of the IR extender.
RS-232: For sending RS-232 command to compatible Receivers.
1
2
3
4
5
6
7
8
9
9
OPERATION CONTROL AND FUNCTIONS
HDBaseT 18G/4K Multi-Format Presentation Switch w/ 5 Inputs and 2 Mirrored Outputs User Manual (LBC-PSW52)
REAR PANEL
LBCPSW52 CON’T
11
312
456 7 8 9
PC 1LINE INMIC INSERVIC IE R OUT IR IN RS232 COM PORT
LINE OUT
CAT5e/6/7 OUTHDMI OUTHDMI 2HDMI D1 ISPLAY PORT
INPUT CONTROL
C12345
CONTROL
OFF
ON
PHANTOM
PC 2PC 1
DC 24V
PC 2
Com Port: Connect with D-Sub 9 pin cable with PC or laptop for this scaler
box controlled by RS-232 commands.
Control: This port is the link for WebGUI control; connect to an active
Ethernet link with an RJ45 terminated cable. Use BCI’s IP
Discovery program to obtain devices IP address to access
WebGUI Control.
Input Sources:
a. HDMI 1 & HDMI2: Connect to HDMI sources such as Blu-ray/
DVD player for both video and audio signal.
b.DisplayPort: Connect to a PC / Laptop source for video signal input.
c.PC 1 & PC2: Connect to a PC/Laptop source for video signal input with
D-Sub 15pin cable.
Output:
a. CAT5e/6/7 Out: Connects with compatible Receiver for video and/or
audio output.
b. HDMI Out: Connect to an HDMI display or AV Receiver for video
and/or audio output.
DC 24V: Plug the 24V DC power supply into the unit and connect the adap
tor to an AC outlet.
10
11
12
13
14
Pin Number Source
Pin 1 HDMI 1
Pin 2 HDMI 2
Pin 3 DisplayPort
Pin 4 PC1
Pin 5 PC2
15
Input Control: This input control reserving for
direct source input selection.
Connect ground pin (mark as C
on panel) with following pin
number for individual source
selection.
13a
10
13b13c 14a 14b 15
10 OPERATION CONTROL AND FUNCTIONS
HDBaseT 18G/4K Multi-Format Presentation Switch w/ 5 Inputs and 2 Mirrored Outputs User Manual (LBC-PSW52)
PIN DEFINE Tx/Rx
1 N/C
2 TxD
3 RxD
4 N/C
5 GND
6 N/C
7 N/C
8 N/C
9 N/C
HDMI1 : HDMI 1 source input
HDMI2 : HDMI 2 source input
DP: Display Port source input
PC1: PC1 source input
PC2: PC2 source input
EXIT: Exit from On Screen Display (OSD)
MENU: Access to On Screen Display (OSD)
RESET: Return to factory default setting (Ethernet setting remain the same)
AUTO ADJUST: Auto adjust PC picture in central
/ : Navigate down/up of On Screen Display selection items
(-) /(+): Adjust selection items parameter (+) or (-) of On Screen Display or output
volume adjustment
123
45
1
2
3
4
5
11
10 98
7
6
7
8
9
10
11
6
