BRK electronic DS700RF Manuel utilisateur

Save time & money on your installation projects

RF INTERLINK

BASE

MODEL: DS700RF

VISIT US ONLINE

www.brk.co.uk

CONTACT

+44 (0)2476 323232

A Sprue Safety Products Brand

The “RF base” is a system that provides a

wireless interlink between mains powered smoke

and heat alarms; it is quick to install and quick to

link, ensuring greater output and savings.

The base unit has been designed to transmit a

Radio Frequency (RF) signal, when the alarm

attached to it senses smoke or ﬁre. When another

RF base receives this signal the attached smoke

or heat alarm will also sound, eliminating the need

for connection wires between each alarm. This

is also a particularly useful system to use when

refurbishing or extending an existing property.

“Eliminates the need to run

long interconnecting wires

around a building”

SAVE TIME AND MONEY

ON YOUR PROJECTS…

“Minimum disruption during

the installation process”

“RF technology is an

installer’s dream...”

No extra wires.....

No mess..............

No fuss................

PROTECTION WHEN YOU

NEED IT...

cables and

electrical

trunking to

worry about

NO removing

carpets &

ﬂoorboards

The RF base features a unique identiﬁcation (ID)

coding system that prevents individual systems in

a group of properties from interacting with each

other causing nuisance alarms.

No extra wires, means no mess and no fuss.

Time on site is kept to a minimum with very little

disruption to a property. There is no need to lift

ﬂoor boards and carpets or channel out walls

even re-decorating after an installation can

now be avoided. Home owners and tenants will

beneﬁt from minimum disruption during the whole

installation process.

The RF base incorporates the very latest

lithium battery technology. Built in tamper

proof cells provide a minimum of 10 year life

ensuring continuous protection even in the event of

a power cut!

Each base unit is equipped with a radio receiver

and transmitter which can be used with up to 50

smoke and heat alarms.

Ionisation, optical smoke and heat alarms can all be

used on the same system for maximum protection.

INTRODUCING THE

RF INTERLINK BASE...

DESIGNED FOR PROFESSIONALS BY PROFESSIONALS

About Push-Fit

The Push-Fit system has been

speciﬁcally designed to ensure

quick and easy installation of

base unit to the mains feed

supply at initial installation

stage (1st ﬁx) and for quick

and easy connection of alarm

to base unit (2nd ﬁx).

Quick set-up guide

A really simple system to install in 3 easy steps

1. Screw mounting base ﬁrmly to ceiling using

the ﬁxings provided

2. Connect the mains wires to the terminal block

3. Push-ﬁt the alarm into place. No need for

additional connector leads

Bedroom Landing

Bathroom

Living

Room Kitchen

Hall

Attic

RF TECHNOLOGY

AROUND THE HOME...

QUICK SET-UP

INSTALLATION GUIDE...

THE PROFESSIONAL STANDARD FOR OVER 40 YEARS .EST 1967

VISIT US ONLINE

www.brk.co.uk

CONTACT

TEL : +44 (0) 2476 323232

FAX : +44 (0) 2476 693610

EMAIL : [email protected]

A Sprue Safety Products Brand

SPRUE SAFETY PRODUCTS LTD

Unit 6, Carter Court, Davy Way

Waterwells Business Park, Quedgeley

Gloucester, GL2 2DE

United Kingdom

RF INTERLINK BASE

MODEL: DS700RF

The RF base provides a wireless link between smoke & heat alarms. Eliminates the need for connection

wires between each alarm. Can be used with any BRK mains operated smoke and heat alarms in the 650,

670 and 680 series.

Product features:

• 10yr lithium battery

• “Push-t” docking base system

• Automatic ID coding

• Multiple repeater RF signalling

• RF transmitter and receiver in each base unit

• Interlink up to 50 smoke & heat alarms

• Audible & visual LED fault warnings

• 5 year guarantee

5022391064275

15022391064272

Model Number DS700RF

5 years

Guarantee

Approvals Independently tested and compliant

with EMC, electrical Safety and Radio

Regulations to include requirements

of the R&TTE Directive.

EN300220 v2.3.2 (2010.02)

EN301489-1

EN301489-3

EN50130-4

EN60065

Unit weight 128g

Unit dimensions 140mm (Diameter) x 30mm (Height)

Pack dimensions 142mm (H) x 142mm (W) x 35mm (D)

Pack weight 170g

Master pack quantity 10

Master pack dimensions 155mm (H) x 190mm (W) x 280mm (D)

Master pack weight

Pack barcode

Outer barcode

2076g

Radio frequency: 868MHz

Operating temperature 5°C (40°F) to 38°C (100°F)

Sensitivity N/A

Battery type 10yr lithium battery

Technology

Operation AC/DC

Alarm sound level Refer to smoke or heat alarm manual

10% to 85% relative

Operating humidity

Installation positions Ceiling (range 30m open area) 150m min

5°C (40°F) to 38°C (100°F)

Storage temperature

10% to 85% relative

Storage humidity

Description RF base system

Please note that specifications may be subject to change at any time.
