BRK electronic 4010YR Manuel utilisateur

10 Year Lithium Power™

BATTERY OPERATED

Cat. No.

4010

Continuous

Protection for

10 Years

Sealed unit prevents removal of

lithium power cells

• Never needs a

replacement battery

• Tamper-proof design

• Mounts to any surface

• No wiring required

ADVANTAGES

• Sealed batteries can not be removed,

and function only in this detector

• Saves time and money because you never

replace the batteries

• Ideal for multi-unit dwellings such as

public housing, apartments, and dormitories

• Convenient for cathedral ceilings or other

“hard-to-reach” locations

NAED NUMBER: 13107

MASTER PACK: 12

SMOKE DETECTOR

IONIZATION

Research available through the National Fire Protection Agency (NFPA) indicates that as many as one-third

of all residential smoke detectors do not work. The primary cause is due to DEAD or MISSING batteries.

This innovative smoke detector provides 10 YEARS of continuous, worry-free protection.

TECHNICAL SPECIFICATIONS:

• Alarm Circuit - 100% Solid State

• Alarm Horn - 85dB at 10ft

• Smoke Sensitivity - 1.20%/FT+/-0.68%/FT

• Battery - lithium power

• Battery Life - 10 years

• Test Switch - Electronically simulates presence

of smoke and tests all detector functions

• Detector Dimensions - 5" diameter, 2" height

• Detector Weight - 9 oz

DESCRIPTION:

10 Year Lithium Power™, Battery Operated, Ionization Smoke Detector.

Contains long-life lithium power cells designed to operate continuously

for 10 years. Detector is sealed to prevent removal of the lithium power

cells, and contains a full function Test button and a Silencer button. After

10 years of service, the unit sounds a 28 day low power signal which

notifies the occupant that the detector must be deactivated and replaced.

PRODUCT FEATURES ADVANTAGES

10 Year Lithium Power™ Cells Continuous operation for 10 years

with no battery to ever replace

Tamper-Proof Design Sealed unit prevents removal of

lithium power cells

85dB Horn Provides loud, audible warning

Test Button Electronically simulates smoke

condition, causing unit to alarm

Silencer Button Quiets detector during

unwanted alarms

28-Day Low-Power Alarm Alerts end-user to replace

the detector

Fail-Safe Mounting Assures detector is turned on

Activation Switch before mounting

Deactivation Switch Deactivates power cells before

discarding detector

UL Listed Only UL Listed smoke detector with

10 year life

10 Year Limited Warranty 10 years of continuous,

worry-free protection

SAMPLE SPECIFICATION

The smoke detector shall be powered by non-

replaceable lithium power cell source, sealed within the

detector unit and having a 10 year life. The detector

shall have a dual chamber ionization sensor with a

nominal sensitivity of 1.2% as measured in a UL smoke

box. The detector shall have an activation switch

which activates the power cells at time of installation,

and which precludes the unit from being mounted

unless activated. The unit shall provide a “low power”

alarm, at least 28 days before power is depleted, to

warn the occupant that the detector must be replaced.

A built in test switch shall electronically simulate the

presence of smoke, cause the unit to alarm, and test all

detector functions. The detector shall provide a loud,

audible 85dB alarm at 10 ft., and have a silence

button which quiets the detector when depressed. The

detector shall be capable of being surface mounted.

The detector shall meet UL standards and have a

minimum 10 year limited warranty commencing from

the date of purchase. The detector shall be a BRK

Electronics Cat. No. 4010YR or pre-approved equal.

MANUFACTURED BY: DISTRIBUTED BY: FOR TECHNICAL HELP OR REPRESENTATIVE

NEAREST YOU PHONE 1-800-323-9005

CM974

Cat. No.

4010

10 Year Lithium Power™Battery Operated,

Ionization Smoke Detector

BRK®Electronics

3901 Liberty Street Road

Aurora, IL 6050 -8122

Made in USA
