Home Generator Systems

Illustrated Parts List

Manual No. 206620A Rev. - (03/26/2008)

100 Amp

Automatic Transfer Switch

Model

071039

Item Part # Description

1 NSP ENCLOSURE, 16" x 12" x 6"

2 NSP BACK PANEL

3 195667GS TRANSFER SWITCH, 100A, with

Cover & Handle

4 * PPHMS, #10 - 32 x 1/2"

5 * WASHER, Ext. Tooth, #10

6 192150GS SPACER

7 * PPHMS, #6-32 x 3/8"

8 193159GS DECAL, Reinstall After

9 204009GS CONTROL, Board

10 201685GS SPACER

11 196094GS GROUND LUG

12 * WASHER, Lock 1/4"

13 206543GS DECAL, Utility, 230 VAC

14 * NUT, 1/4" - 20

15 192696GS TERMINAL, Neutral

16 B4857GS FUSE

Item Part # Description

17 192151GS FUSE HOLDER

18 197355GS CLIP, Latching Wire

19 192165GS DECAL, APPVD CB

20 196355GS DECAL, CT Warning

21 197294GS DECAL, Contacts Rating

22 197198GS DECAL, Wire Circuits

23 196522GS DECAL, 100A, ATS

25 205395GS DECAL, Warning Shock

26 190984GS DECAL, Fuse

27 B4986GS DECAL, Ground

Items Not Illustrated

195728GS CURRENT TRANSFORMER

* - Items without part numbers are common fasteners and

are available at local hardware stores.

2BRIGGSandSTRATTON.COM

Exploded View & Illustrated Parts List- Model 071039

Copyright © 2008 Briggs & Stratton Power Products Group, LLC. All rights reserved. No part of this material may be

reproduced or transmitted in any form by any means without the express written permission of Briggs & Stratton Power

Products Group, LLC.
