Breville 800GR Manuel utilisateur
800GR
the BBQ Grill™
Instruction Booklet
800GR_IB_A12_FA.indd 3 24/02/12 7:44 PM
CONGRATULATIONS
on the purchase of your new Breville
the BBQ Grill™
800GR_IB_A12_FA.indd 2 24/02/12 7:44 PM
3
CONTENTS
4 Breville recommends safety first
6 Know your
Breville the BBQ Grill™
8 Operating your
Breville the BBQ Grill™
15 Care & cleaning
18 Recipes
800GR_IB_A12_FA.indd 3 24/02/12 7:44 PM
4
BREVILLE RECOMMENDS SAFETY FIRST
At Breville we are very safety conscious. We design and manufacture consumer products
with the safety of you, our valued customer, foremost in mind. In addition we ask that you
exercise a degree of care when using any electrical appliance and adhere to the
following precautions.
READ ALL INSTRUCTIONS
BEFORE USE AND SAVE FOR
FUTURE REFERENCE
• Carefully read all instructions before
operating and save for future reference.
• Remove and safely discard any
packaging material and promotional
stickers before using the grill for the
first time. To eliminate a choking hazard
for young children, remove and safely
discard the protective cover fitted to the
power plug of the appliance.
• Do not place the grill near the edge of a
bench or table during operation. Ensure
the surface is level, clean and free of
water, etc.
• Do not place the grill on or near a hot
gas or electric burner, or where it could
touch a heated oven. Use the grill well
away from walls.
• Provide adequate space above and on all
sides for air circulation around the grill.
• Do not place the grill on any surface
that may be affected by heat. The use of
a heat resistant mat is recommended on
these surfaces.
• Always ensure the grill is properly
assembled before use.
• Do not touch hot surfaces. Use the
handle to lift and open the top plate.
Take care when using the adjustable
grilling height control.
• Do not leave the grill unattended when
in use.
• Do not place anything on top of the grill
when the lid is closed, when in use and
when stored.
• Always switch the grill off, then switch
off at the power outlet, then unplug and
allow to cool, if appliance is not
in use, before cleaning, before
attempting to move the appliance,
disassembling, assembling and when
storing the appliance.
• Keep the exterior housing and the
non-stick cooking plates clean.
Follow the cleaning instructions
provided in this book.
IMPORTANT SAFEGUARDS
800GR_IB_A12_FA.indd 4 24/02/12 7:44 PM
5
BREVILLE RECOMMENDS SAFETY FIRST
5
IMPORTANT SAFEGUARDS FOR
ALL ELECTRICAL APPLIANCES
• Fully unwind the power cord before use.
• Do not let the power cord hang over
the edge of a bench or table, touch hot
surfaces or become knotted.
• To protect against electric shock do not
immerse the power cord, power plug or
appliance in water or any other liquid.
• The appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning
use of the appliance by a person
responsible for their safety.
• Children should be supervised to ensure
that they do not play with the appliance.
• It is recommended to regularly inspect
the appliance. To avoid a hazard do not
use the appliance if power cord, power
plug or appliance becomes damaged in
any way. Return the entire appliance to
the nearest authorised Breville Service
Centre for examination and/or repair.
• Any maintenance other than cleaning
should be performed at an authorised
Breville Service Centre.
• This appliance is for household use only.
Do not use this appliance for anything
other than its intended use. Do not use
in moving vehicles or boats. Do not use
outdoors. Misuse may cause injury.
• The installation of a residual current
device (safety switch) is recommended
to provide additional safety protection
when using electrical appliances. It
is advisable that a safety switch with
a rated residual operating current
not exceeding 30mA be installed in
the electrical circuit supplying the
appliance. See your electrician for
professional advice.
WARNING
Fully unwind the cord from the cord
storage facility before use.
SAVE THESE
INSTRUCTIONS
800GR_IB_A12_FA.indd 5 24/02/12 7:44 PM
KNOW
your Breville the BBQ Grill™
800GR_IB_A12_FA.indd 6 24/02/12 7:44 PM
7
KNOW YOUR BREVILLE THE BBQ GRILL™
A. Grill lock dial
B. Stainless steel body
C. 2400 watts of power
D. Levelling handle
E. Unique floating hinged top plate
F. Quantanium™ non-stick ribbed
top plate
G. Quantanium™ non-stick flat
bottom plate
BCE A
F
G
H
I K L M
H. Removable drip tray
I. ON/OFF switch
J. Red heating light
K. Bottom plate tilt dial
L. 15 minute timer dial
M. Variable temperature control dial
N. Adjustable grilling height
D
N
J
800GR_IB_A12_FA.indd 7 24/02/12 7:44 PM
OPERATING
your Breville the BBQ Grill™
800GR_IB_A12_FA.indd 8 24/02/12 7:44 PM
9
OPERATING YOUR BREVILLE THE BBQ GRILL™
BEFORE FIRST USE
Remove and safely discard any promotional
materials and packaging materials before
use. Check that the cooking plates are clean
and free of dust. If necessary, wipe over with
a damp cloth.
When using the grill for the first time
you may notice a fine smoke haze This is
caused by the first heating of some of the
components. There is no need for concern.
TO USE AS AN OPEN GRILL
1. Insert the plug into a 230/240V power
outlet and switch the power ON Switch
the ON/OFF button to ON. The red
heating light will illuminate.
2. Ensure the removable drip tray is
correctly inserted and positioned back
into the appliance.
3. Ensure the top plate is in the closed
position for more efficient preheating.
4. Turn the base plate tilt dial to the
FLAT position.
5. Turn the variable temperature control
dial to SEAR for fast preheating.
6. Allow the grill to preheat until the red
heating light goes out.
7. The grill must be closed to release the
lock. Turn the grill lock dial on the side
of the grill to horizontal position and use
the handle to pull the top plate into the
open position.
NOTE
It is important that the base plate is in
the fat position when using as an
open grill.
NOTE
Grill Lock will automatically reset
when returned to the CLOSED
position.
8. Place meat or foods to be cooked on
either or both of the cooking plates.
Refer to grilling recipes or guide for
cooking times.
9. When the food is cooked, remove using
a plastic spatula.
800GR_IB_A12_FA.indd 9 24/02/12 7:44 PM
10
OPERATING YOUR BREVILLE THE BBQ GRILL™
NOTE
Use the 15 minute timer dial to select
a pre-heating or cooking time between
1–15 minutes. The dial will need to be
rotated clockwise completely before
selecting the desired time. When the
selected time has elapsed, a bell will
ring once. The grill will not turn off, it
will remain heating.
TO USE AS A CLOSED GRILL
1. Insert the plug into a 230/240V power
outlet and switch the power ON. Switch
the ON/OFF button to ON. The red
heating light will illuminate.
2. Ensure the removable drip tray is
correctly inserted and positioned back
into the appliance.
3. Ensure the top plate is in the closed
position for more efficient preheating.
4. Turn the base plate tilt dial to the
ANGLE or FLAT position.
5. Turn the variable temperature control
dial to SEAR for fast preheating.
6. Allow the grill to preheat until the red
heating light goes out.
7. Use the handle to pull the top plate into
the 90° position.
8. Place meat or foods to be cooked on the
base cooking plate. Refer to Grilling
recipes or Guide for cooking times.
NOTE
The grill can be used to cook foods in
the open or closed position.
9. Use the handle to close the top plate.
The top plate has a floating hinge
system that is designed to press down
evenly on the food. The grilling height
control on the right hand side of the top
plate is used to adjust for the thickness
of the food. The levelling handle on the
right hand side of the top of the grill
may be used to even out the top plate.
The top plate must be fully lowered to
achieve grill marks onto the food.
NOTE
The red heating light will cycle
on and off during the cooking
process indicating that the correct
temperature is being maintained.
800GR_IB_A12_FA.indd 10 24/02/12 7:44 PM
