Thank you for purchasing a Braun product.

We hope you are completely satisfied with

your new Braun shaver.

If you have any questions, please call:

US residents 1-800-BRAUN-11

1-800-272-8611

Canadian residents 1-800-387-6657

Merci d’avoir fait l’achat d’un produit Braun.

Nous espérons que vous serez pleinement

satisfait de votre nouveau rasoir Braun.

Si vous avez des questions, veuillez appeler

Braun Canada : 1-800-387-6657

Gracias por haber comprado un producto

Braun.

Esperamos que quede completamente

satisfecho con su nueva afeitadora Braun.

Si tiene alguna duda, por favor llame al:

01(800) 508-5800

5649320_580cc_NA_S2 Seite 1 Dienstag, 29. Januar 2008 2:09 14

All manuals and user guides at all-guides.com

off

trim fix on

empty charge

570

start

clea

ning

clean

eco

normal

intensive

full

cartridge

auto select

empty

off

trim fix on

580cc 570cc was Activator 8990-85 NA Explo KURTZ DESIGN 29.01.08

580

0 20 40 60 80 100

51S

5649320_580cc_NA_S3 Seite 1 Dienstag, 29. Januar 2008 2:10 14

All manuals and user guides at all-guides.com

IMPORTANT SAFETY

INSTRUCTIONS

When using an electrical appliance, basic precautions should always be

followed, including the following:

Read all instructions before using this appliance.

DANGER

To reduce the risk of electric shock:

1. Do not reach for an appliance that has fallen into water.

Unplug immediately.

2. Do not use while bathing or in a shower when the appliance is connected to an

electrical outlet.

3. Do not place, store or charge the appliance where it can fall or be pulled

into a tub or sink. Do not place in or drop into water or other liquid.

4. When not using for an extended period of time, unplug this appliance from the

electrical outlet.

5. Unplug this appliance before cleaning.

6. This appliance comes provided with a special cord set with integrated Safety

Extra Low Voltage power supply. Do not exchange or manipulate any part of it.

FOR HOUSEHOLD USE

SAVE THESE INSTRUCTIONS

English

5649320_580cc_NA_S4-34 Seite 4 Dienstag, 29. Januar 2008 2:05 14

All manuals and user guides at all-guides.com

WARNING

To reduce the risk of burns, ﬁre, electric shock, or injury to persons:

1. Close supervision is necessary when this appliance is used by, on, or near

children or invalids.

2. Use this appliance only for its intended use as described in this manual.

Do not use attachments not recommended by the manufacturer.

3. Never operate this appliance if it has a damaged cord or plug, if it is not

working properly, if it has been dropped or damaged, or if the power supply

has been dropped into water. Return the appliance to a service center for

examination and repair.

4. Keep the cord away from heated surfaces.

5. Never drop or insert any object into any opening.

6. Do not use outdoors or operate where aerosol (spray) products are being used

or where oxygen is being administered.

7. Do not use this appliance with a damaged or broken foil, as serious skin

injuries may occur.

8. Always attach plug to appliance ﬁrst, then to outlet. To disconnect, turn all

controls to «off», then remove plug from outlet.

9. When plugging to an electrical outlet outside the USA, use a plug adapter to

match the outlet’s pin conﬁguration.

SAVE THESE INSTRUCTIONS

5649320_580cc_NA_S4-34 Seite 5 Dienstag, 29. Januar 2008 2:05 14

All manuals and user guides at all-guides.com

Your Braun shaver with Clean&Renew™ station

is a system equipped with highly advanced electronic

processors. It ensures great closeness and comfort for

you and optimum care for your shaver:

• The system automatically adapts to any voltage

worldwide.

• The system recognizes when cleaning of your shaver is

required, and automatically recognizes which of the

three cleaning programs is appropriate.

• While the shaver is connected to an electrical outlet,

the system automatically takes care of charging and

discharging in a way that is optimized for the shaver’s

battery capacity and life span.

• The system takes care of lubrication of the shaver’s

cutting parts.

• The system tells you when to replace the shaving foil

and cutter block.

Important

In order to avoid any leakage of the cleaning fluid,

place the Clean&Renew™ station on a flat, stable

surface.

Do not tip, move suddenly or transport the station in

any way if a cleaning cartridge is installed.

Do not place the station in a mirror cabinet, store it

over radiators, or place it on polished or laquered

surfaces. Do not expose to direct sunlight.

The station contains highly flammable liquid. Keep it

away from sources of ignition.

No smoking.

Keep out of reach of children.

Do not refill cartridge.

Use only original Braun refill cartridge.

5649320_580cc_NA_S4-34 Seite 6 Dienstag, 29. Januar 2008 2:05 14

All manuals and user guides at all-guides.com

all-guides.com

Description

1 Special cord set

2 «start cleaning» button

3 Station-to-shaver connecting contacts

4 Station lift button for cartridge exchange

5 Display for cleaning programs

6 Display for cleaning fluid status

7 Station mains socket

8 Cleaning cartridge

9 Shaver foil protection cap

10 Shaver foil

11 Cutter block

12 Foil release buttons

13 Long hair trimmer

14 Shaver-to-station connecting contacts

(shaver backside)

15 Switch

16 Shaver charging lights (green)

17 Shaver low-charge light (red)

18 Replacement light for shaving parts

19 Reset button

20 Pilot light

21 Shaver mains socket

Before shaving

If you wish, you may start shaving right away (if the shaver

is charged, see section «The shaver indicator lights»).

However, we recommend to follow the procedure

described here:

• Using the special cord set (1), connect the socket of the

Clean&Renew™ station (7) to an electrical outlet.

• Press the station lift button (4) to open the housing.

• Hold the cleaning cartridge (8) down on a flat, stable

surface (e.g. table).

• Carefully remove the lid from the cartridge.

• Slide the cartridge into the base of the station as far as

it will go.

• Slowly close the housing by pushing it down until it

locks.

eco

normal

intensive

auto s

full

cartridge

empty

clean

eco

normal

intensive

full

cartridge

auto select

empty

clean

eco

normal

intensive

full

cartridge

auto select

empty

clean

eco

normal

intensive

full

cartridge

auto select

empty

5649320_580cc_NA_S4-34 Seite 7 Dienstag, 29. Januar 2008 2:05 14

All manuals and user guides at all-guides.com

The display for cleaning fluid (6) will show how much

cleaning fluid is in the cartridge:

a) cleaning solution sufficiently available

b) up to 7 cleanings left

c) new cartridge required

Make sure the foil protection cap (9) is removed from the

shaver. Insert the shaver head down into the station (the

contacts (14) on the back of the shaver will correspond to

the contacts (3) in the station). If necessary, the system

will now charge the shaver.

Also, the cleaning status will be automatically analyzed

and one of the four diodes of the cleaning program display

(5) will light up:

a) the shaver is clean

b) eco(nomic), i.e. short cleaning required

c) normal cleaning required

d) intensive cleaning required

If the system has selected one of the three cleaning

programs, it will not start until you push down the «start

cleaning» button (2). This locks the shaver into the station

and starts the cleaning process.

We recommend cleaning after each shave.

While the cleaning is in progress, the respective cleaning

program light will flash. Each cleaning consists of several

cycles (where the cleaning fluid is flushed through the

shaver head) and a heat drying period. The total cleaning

time is 33 to 50 minutes.

Cleaning processes in the Clean&Renew™ should not

be interrupted. While the shaver is drying, the metal

parts of the shaver may be hot. Also, if the shaver is

taken out prematurely and is not dry, its electronics

could be harmed.

When the program is finished, the blue «clean» light will

shine. You can release the shaver by pushing the «start

cleaning» button.

Your shaver is now clean and ready for use.

cartridge

full

empty

cartridge

full

empty

cartridge

full

empty

abc

full

cartridge

auto select

empty

eco

normal

intensive

clean

trim fix on

off

auto select

eco

normal

intensive

clean

auto select

eco

normal

intensive

clean

full

cartridge

auto select

empty

eco

normal

intensive

clean

trim fix on

off

0..20 40 60 80 100

auto select

eco

normal

intensive

clean

5649320_580cc_NA_S4-34 Seite 8 Dienstag, 29. Januar 2008 2:05 14

All manuals and user guides at all-guides.com

Shaving

If the shaver is locked into the Clean&Renew™ station,

push the «start cleaning» button (2) to release the shaver

and take it out.

Switch positions

off = (switch is locked)

Press and push up the switch to operate the shaver

on = Shaving with the pivoting head

(the pivoting cutting system automatically adjusts to

every contour of your face).

fix = Shaving with the pivoting head locked at an angle

(to permit shaving in difficult areas, e.g. under the

nose).

trim=The long hair trimmer is activated

(for trimming sideburns, moustache and beard).

Shaving with the cord

If the shaver is completely discharged and you do not

have the time to recharge in the Clean&Renew™ station,

you may also shave with the shaver connected to an

electrical outlet.

After shaving

Automatic cleaning

After each shave, return the shaver to the Clean&Renew™

station and proceed as described above in the section

«Before shaving». All charging and cleaning needs are

then taken care of. With daily use, a cleaning cartridge

should be sufficient for about 30 cleaning cycles.

The hygienic cleaning solution cartridge contains alcohol

which, once opened, will naturally evaporate slowly into

the surrounding air. Each cartridge, if not used daily,

should be replaced after approximately 8 weeks.

Tips for the perfect shave

• It can take up to 14-21 days for your beard to adjust

to the new shaving system.

• Shave before washing your face or taking a shower,

as skin tends to swell after washing.

• The drier the skin, the closer the shaving results will

be.

• Hold the shaver at right angles (90°) to the skin.

Stretch the skin and shave against the direction of

beard growth.

• To maintain 100% shaving performance, replace

your foil and cutter block at least every 18 months or

when worn.

fix on

trim fix on

full

cartridge

auto select

empty

eco

normal

intensive

clean

trim fix on

off

0..20 60

40 80 100

5649320_580cc_NA_S4-34 Seite 9 Dienstag, 29. Januar 2008 2:05 14

All manuals and user guides at all-guides.com

Quick cleaning

Press the foil release buttons (12) to lift the shaver foil

(do not remove the foil completely). Switch on the shaver

for approx. 5–10 seconds so that the shaved stubbles can

fall out.

Thorough manual cleaning

Manual cleaning is recommended only when the

Clean&Renew™ station is not available, e.g. when travel-

ling.

Never use water to clean the shaver.

Remove the shaver foil and tap it out on a flat surface.

Using the brush, clean the inner area of the pivoting head.

However, do not clean the shaver foil nor the cutter block

with the brush as this may damage them.

If you do not use the Clean&Renew™ station for a longer

period of time, you should apply a drop of light machine

oil onto the shaver foil.

Cleaning the housing

Clean the housing of shaver and station from time to time

with a damp cloth, especially inside the opening of the

station where the shaver rests.

Replacing the cartridge

After having pressed the lift button (4) to open the

housing, wait for a few seconds before removing the used

cartridge.

Before discarding the used cartridge, make sure to close

the openings using the lid of the new cartridge, since the

used cartridge will contain contaminated cleaning

solution.

The shaver indicator lights

Pilot light (20): the shaver is connected to an electrical

outlet.

The red low-charge light (17) flashes when the battery

capacity has dropped below 20%, provided the shaver is

switched on. The remaining capacity will then be sufficient

for 2 to 3 shaves.

fix on off

on off

new

nouveau

old

ancien

0..20 40 60

0...20 40 60 80

100

empty charge

5649320_580cc_NA_S4-34 Seite 10 Dienstag, 29. Januar 2008 2:05 14

All manuals and user guides at all-guides.com

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Braun Rasoir électrique

Braun

Braun SERIES7 5693 Manuel utilisateur

Braun

Braun Silk epil 7 Manuel utilisateur

Braun

Braun 370CC-4 Manuel utilisateur

Braun

Braun cruZer5 Manuel utilisateur

Braun

Braun 93 Series Manuel utilisateur

Braun

Braun NovoScan 3in1 Manuel utilisateur

Braun

Braun shaver Manuel utilisateur

Braun

Braun cruZer 3 2866 Manuel utilisateur

Braun

Braun Gillette Prosonic 720 Manuel utilisateur

Braun

Braun Syncro 7690 Manuel utilisateur

Braun

Braun 370cc Manuel utilisateur

Braun

Braun BT 5090 Manuel utilisateur

Braun

Braun Gillette Prosonic 720 Manuel utilisateur

Braun

Braun BS 5897 Manuel utilisateur

Braun

Braun Silk-epil Xpressive 7381 WD Manuel utilisateur

Braun

Braun SmartControl3 Manuel utilisateur

Braun

Braun BT3421 Manuel utilisateur

Braun

Braun 5697 Manuel utilisateur

Braun

Braun 730s-4 Manuel utilisateur

Braun

Braun Activator 8583 Manuel utilisateur

Braun

Braun 7 series Manuel utilisateur

Braun

Braun Silk épil 5 Manuel utilisateur

Braun

Braun 750cc-6 Manuel utilisateur

Braun

Braun cruZer 5 Head Manuel utilisateur

Manuels Rasoir électrique populaires d'autres marques

Philips

Philips MicroAction 4402LC Manuel utilisateur

Philips

Philips HQ7740 Manuel utilisateur

Philips

Philips Norelco BG2022 Bodygroom Manuel utilisateur

Norelco

Norelco Quadra 7610X Manuel utilisateur

Philips

Philips 7616X Manuel utilisateur

Philips

Philips HQ802 Manuel utilisateur

Philips

Philips HQ7363/17 Manuel utilisateur

Philips

Philips NORELCO S7371 Manuel utilisateur

Daga

Daga MT-400 Manuel

Philips

Philips RQ119x Manuel utilisateur

Remington

Remington BHT100 Manuel utilisateur

Philips

Philips Bodygroom BG2000 Manuel utilisateur

Kompernass

Kompernass KH 5537 Manuel utilisateur

Remington

Remington BHT6100 Manuel utilisateur

Philips

Philips qc5365 Manuel utilisateur

MIA

MIA Aqua Body Manuel utilisateur

Philips

Philips NORELCO AT880 Manuel utilisateur

Matheo

Matheo MLR 15 Manuel utilisateur
