Braun DigiFrame 10.2 Manuel utilisateur

TABLE

CONTENTS

QUICK START………………………………………...…………...…..……………1

DIAGRAM OF THE DIGITAL PHOTO FRAME...………………………………2

KEYPAD BUTTON FUNCTIONS...……..…………………………………………3

REMOTE CONTROL FUNCTIONS………………………………………………..4

DIGITAL PHOTO FRAME NAVIGATION…..……………....…………………...5

OSD MENU FUNCTIONS…………………………………….…………………….6

ADDITIONALPHOTO FRAME FEATURES.....…..………………………………7

ADDITIONAL FEATURES CONTINUED…...……………....…………………...7

USING THE MINI-USB FOR FILE TRANSFER…..…………………….………8

SAVING AND DELETING FILE FROM INTERNAL MEMORY..…….………9

TECHINICAL SPECIFICATIONS…..…………………………………………....10

FREQUENTLY ASKED QUESTIONS….………………………………………...11

IMPORTANT SAFETY INSTRUCTIONS……………………………………….12

CLEANING THE DIGITAL PHOTO FRAME…………………………………..14

Congratulations on yourpurchase ofBRAUN DigiFrame 10.2 with 10.2” LCD

Display. Please read carefullyand follow all warnings and instructions in this

User's Manual and those marked on the productbefore you use the Digital

Photo Frame. Failing to follow warnings can result in personal injury or damage

to the Digital Photo Frame. Pleasekeep this User's Manualin a convenient

location for future reference.Important: Save the original box andall packing

material for future shipping needs.

Quick Start

1. Plug theAC adapter into the DigiFrame 10.2 and plug it into a power

outlet.

2. Insert a memory cardinto one of the slots:

Slot 1 - SecureDigital or MultiMedia Card

Slot 2 - Compact Flash

or Micro Drive

Slot 4 - Memory Stick , Memory Stick PRO , Memory Stick

Duo

, or Memory Stick PRO Duo

Or inserta USBThumbnail Drive into the USB port.

Note:To view a sampleof how thePhoto Frame displays digital photos, simply

turn on the frame without inserting a memory card.

3. Push the power button for a few seconds on the back of theDigital

Photo Frame to turn on the frame.

Diagram of the Digital Photo Frame

Mini USB Port for FileTransfer

USB Port for USB Flash Drives

Memory StickTM ,Memory Stick PRO

TM,

Memory Stick DuoTM,and

MemoryStickPRODuo

TM Slot

Secure Digital and

Multi Media CardTMSlot

Compact Flash and

Micro Drive

TMSlot

AC Power Input

Keypad

Power Button

Adjustable Stand

Keypad Button Functions

On Screen Display Functions

Note:To enter the On Screen Display(OSD), press the Menu button at any

time (except when in Slide Show ).To exit the OSD, simply press the Exit

button.

Button Command

<< Up

Play Select

>> Down

Exit Exit OSD Menu

Menu Enter OSD Menu

Viewing Images Individually

Button Command

<< Go to Previous Image

Play Start Slide Show

>> Go to Next Image

Exit Return to Thumbnail View

Menu Enter OSD Menu

Thumbnail View/ SelectMode Page / Card Select Page

Button Command

<< Left

Play Select

>> Right

Exit Back to previous page

Menu Enter OSD Menu

Remote Control Functions

ON/OFF

DIGITAL PICTURE FRAME

Digital Photo Frame Navigation

Using the Playand Exitbutton, you will be able to advance or go back a Menu

Page within the DigiFrame 1020.

The top Menu Page is the “Select Card” Page.To enter this selection, press

the Exit button twice fromThumbnail View.

Select Card Page

SD / MMC

MS / MS Duo

CF / MD

Built-in Memory

Selecting an option that is highlighted will take you to the next page.

Select Mode Page

Photo Selecting “Photo” will allow you to previewyour photos through

Thumbnail View.

Slideshow This selection will automaticallystart Slide Show.

OSD Menu Functions

All function settings for the BRAUN DigiFrame 1020 can be controlled via the

buttons located on top of the Frame. You can access the On Screen Display

(OSD) at anytime, expectwhen in Slide Show Mode or playing a video,

by pushing the “Menu” button.

OSD Menu Description and Function of Operation

Image Size This function allows you to adjust howthe image fits on the screen.

"Original" retains the original aspect ratio of the image. "Optimal"

optimizes the image to fit the screen

Slide Show Effect This selections allows you to choose the transition style of Slide Show

Slide Show Speed This selection allows you to choose the speed ofthe Slide Show

Slide Show Shuffle This function allows images to be displayed in random order and can

be turned on or off

Save Screen This function allows you to save changed images from the memory

card through the OSD into the internal flash memory

Copy File This allows a file to be copied from amemory card into the internal

flash memory.

Delete File This allows an image to be deleted fromthe internal flash memory.

Rotate This allows a file to be rotated 90 degrees clock-wise

Zoom This allows you to zoom into a picture.

Set Favorite This function allows you to select images to appear more often.

Reset Settings Resets all settings back to default.

Language Changes the OSD menu language: English, Italian, German, French,

Spanish, Portuguese or Dutch

Brightness/ Contrast This function allows you to adjust thebrightness of the screen and

adjust the contrast

Color/ Tint This function allows you to adjust the colorand adjust the tint

Additional Photo Frame Features

Setting Favourite Pictures

Marking an image as a Favourite allows you to see the image more often during

Slide Show. To do so, inThumbnail View highlight a picture and enter the OSD

by pressing the Menu button.Select “Set Favourite” and a small check mark will

appear next to the image.To unmark a picture, repeat the same steps.

Note - Favourite pictures will notbe saved once the frame has been turned off.

Additional Features - Continued

Slide Show Shuffle

Slide Show Shuffle allows you to display your photos in randomorder during

Slide Show. You may turn this feature “on” or “off” in the OSD under “Slide

Show Shuffle”.

Rotate and Zoom

At anytime when you are viewing images individually, you can zoom or rotate a

picture.When viewing an image, push the Menu button to display the OSD.

Scroll down to Rotate orZoom. Bypushing the play button you will be able to

rotate or zoom the image. If you press the Next orPrevious button, the image

will revert back to its original form. You will not be able to zoom and rotate a

picture at the same time.

You can save changes made to the image into the internal memory if you are

changing a file from an inserted memorycard.

Saving Screen to an Image

You can save changed images into the internal memory if you are changing the

file from a inserted memorycard.To do so, after you have either rotated or

zoom to yourpreference,enter the OSDmenu and select Save Changes. Once

you hit select, the changes made to the image will be saved

into the internal flash memory.

Adjusting the Stand

Simply push the button in the back to adjust the angle of the stand.If you wish

to have the unitin portraitorientation, simplyremove the four screws, re-adjust

the stand and place the screws back into place.

Using the Mini-USB for File Transfer

The Digital Photo Frame comes with 128MB of built-in Flash Memory. Make

sure that the Frame is first turned off before connecting a USB cable from a

computer to the Digital Photo Frame and ensure that the power supply is

plugged into the Digital PhotoFrame.

Turn on the Photo Frame. Once the computer has detected the Photo Frame,

you will be able to download compatible image or video files stored in your

computer or delete them from the internalmemoryof the Digital Photo Frame.

Disconnecting theFrame from a PC Computer:

1. Click the “Safely Remove Device” icon on theTask Bar located on the

bottom right corner of the computer Desktop.

2.Adialogue box (“Safely Remove Hardware”) will appear.

3. Select USB Mass Storage Device and click “Stop”.

4. On the next dialoguebox, click “OK”.

5. On the final dialoguebox, click “Close”. Nowyou can safelyremove the

Digital Photo Frame.

The saved images will appear once you have turned off the Frame and turned

it back on.

Note:Attempting to disconnect the Digital Photo Frame without using

the “SafelyRemove Device” procedure may cause the files in the

internal memoryto be unreadable.
