Installation
P.O. Box 309
Menomonee Falls, WI 53052 USA
800 BRADLEY (800 272 3539)
+1 262 251 6000
bradleycorp.com
P20-237 Rev. A: ECO 20-15-022
© 2020 Bradley
Page 1 of 2 7/1/2020
6A20 Liquid Sanitizer
Dispenser Stand
Diplomat Series Soap/Sanitizer Dispensers
(6A00-11, 6A01-11, 6A02-11)
For questions regarding the operation, installation or maintenance of this product, visit bradleycorp.com
or call 800.BRADLEY (800.272.3539).
Product warranties and parts information may also be found under “Resources” on our website at
bradleycorp.com.
27/1/2020 Bradley • P20-237 Rev. A: ECO 20-15-022
6A20 Liquid Sanitizer Dispenser Stand Installation
Assembly Instructions
1. Remove the backing from the rubber feet
(included) and place the rubber foot in each
corner of the base. Place feet ¹⁄₈" (3 mm)
from the edge of the base.
2. Attach the post to the base using the bolt
and washer (included). Torque the bolt to
23 ft-lb.
¹⁄₈" (3 mm)
¹⁄₈" (3 mm)
Edge of Base
Rubber Foot
Rubber
Foot
Post
#6 Screws
#6 Screws
Base
Back Plate
3. Install two #6 screws (included) into the top
two mounting holes. Leave ¹⁄₈" (3 mm) between
the screw head and back plate for hanging the
dispenser.
4. Remove the tank from the dispenser and hang the
dispenser onto the top 2 screws. Add the bottom
two #6 screw. Hand tighten all four screws.
5. Replace the soap tank and place the assembled
stand in the desired location.
Stand and dispenser are now ready for use.
Steps 3–5 are specifically for Bradley Diplomat
soap dispensers. When mounting a dispenser
other than a Bradley Diplomat dispenser, refer to
the mounting instructions for that dispenser.
