Installation Manual and Operating Instructions

Gas Instantaneous Water Heater

WR 11/14/18 .B..

6720648592 (2014/05) ZA

Read installation manual prior to installation of this unit!

Read user manual before putting this unit in operation!

Observe the warnings in the manuals!

The installation room must fulfill the ventilation requirements!

Installation by an authorised person only!

6720648592 (2014/05)

2 | Table of contents

Table of contents

1 Key to symbols and safety instructions . . . . . . . . . . 3

1.1 Key to symbols . . . . . . . . . . . . . . . . . . . . . . . 3

1.2 Safety Instructions . . . . . . . . . . . . . . . . . . . . 3

2 Technical Characteristics and Dimensions . . . . . . . 5

2.1 Declaration of conformity with relevant

EEC regulations . . . . . . . . . . . . . . . . . . . . . . .5

2.2 Explanation of Model Code . . . . . . . . . . . . . . 5

2.3 Accessories (Included with Appliance) . . . . 5

2.4 Description of the heater . . . . . . . . . . . . . . . 5

2.5 Type overview . . . . . . . . . . . . . . . . . . . . . . . . 5

2.6 Special accessories . . . . . . . . . . . . . . . . . . . . 5

2.7 Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . 6

2.8 Electrical diagram . . . . . . . . . . . . . . . . . . . . . 7

2.9 Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.10 Technical characteristics . . . . . . . . . . . . . . . 8

3 Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

3.1 Before starting up the heater . . . . . . . . . . . . 9

3.2 Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

3.3 Turning the heater on and o . . . . . . . . . . . . 9

3.4 Power adjustment . . . . . . . . . . . . . . . . . . . . 10

3.5 Temperature/ow adjustment . . . . . . . . . . 10

3.6 Purge the appliance . . . . . . . . . . . . . . . . . . 10

3.7 Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

4 Regulation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

5 Installation (must be carried out only by

qualied technicians) . . . . . . . . . . . . . . . . . . . . . . . 11

5.1 Important information . . . . . . . . . . . . . . . . . 11

5.2 Selection of the place of installation . . . . . 11

5.3 Heater mounting . . . . . . . . . . . . . . . . . . . . . 12

5.4 Water connection . . . . . . . . . . . . . . . . . . . . 12

5.5 Gas connection . . . . . . . . . . . . . . . . . . . . . . 13

5.6 Inlet/exhaust pipe installation . . . . . . . . . . 13

5.7Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

6 Adjustments (must be carried out only by

qualied technicians) . . . . . . . . . . . . . . . . . . . . . . . 13

6.1 Factory regulations . . . . . . . . . . . . . . . . . . . 13

6.2 Pressure adjustment . . . . . . . . . . . . . . . . . . 14

6.3 Conversion to a dierent type of gas . . . . . 15

7 Maintenance (must be carried out only by

qualied technicians) . . . . . . . . . . . . . . . . . . . . . . . .16

7.1 Periodic maintenance work . . . . . . . . . . . . 16

7.2 Startup after maintenance work . . . . . . . . 16

7.3 Flue gas safety device . . . . . . . . . . . . . . . . . 17

8 Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

9 Environment / disposal . . . . . . . . . . . . . . . . . . . . . . . 19

6720648592 (2014/05)

Key to symbols and safety instructions | 3

1 Key to symbols and safety instructions

1.1 Key to symbols

Warnings

The following keywords are dened and can be used in this

document:

•NOTICEindicates a situation that could result in damage to

property or equipment.

•CAUTIONindicates a situation thatcould result in minor to

medium injury.

•WARNINGindicates a situation thatcould result in severe

injury or death.

•DANGERindicates a situation that will result in severe

injury or death.

Important information

Additional symbols

1.2 Safety Instructions

If there is a smell of gas:

Close the gas valve.

Open windows.

Do not operate any electrical appliances or switches (on/

o).

Extinguish any naked ames.

Phone the gas company or an authorized technician from a

safe distance.

If there is a smell of burnt gases:

Disconnect the appliance.

Open doors and windows.

Inform an installation company.

Burn-back (re in burner tube or chamber)

In the event of a burn-back, where the ame burns back to

the injector, immediately turn o the gas supply at the

control valve on the panel.

After ensuring the ame isextinguished, wait for one

minute and re-light the appliance in the normal manner.

Should the appliance again burn back, close the control

valve and call a service technician.

Do not use the appliance again until the service technician

has declared that it is safe to do so.

Fitting, modications

The tting and modication of the installation of the

appliance must be carried out only by an authorized

technician.

The installation ofthe water heater mayonly be carried out

by a registered installer andthat such installations shall

comply with the requirements of SANS 10087-1.

The pipes carrying burnt gases must not be modied.

Do not close or reduce air circulation holes.

Maintenance

We reccomend to have the system regularly serviced in

order to ensure that it functions reliably and safely.

The installer is responsible for the safety and

environmental compatibility of the installation.

The appliance should be serviced annually.

Only original spareparts must be used.

Explosive and inammable materials

Inammable materials (paper, solvents, ink, etc.) should

not be stored near the appliance.

Combustion air and ambient air

To avoid corrosion, combustionair and ambient air should

be free of aggressive substances (for example halogenated

hydrocarbons containing chlorine and uoride

composites).

Warnings in this document are identied by

a warning triangle printed against a grey

background.

Keywords at the start of a warning indicate

the type and seriousness of the ensuing risk

if measures to prevent the risk are not taken.

This symbol indicates important information

where there is no risk to people or property.

Symbol Explanation

Step in an action sequence

Cross-reference to another part of the document

•List entry

– List entry (second level)

Table 1

6720648592 (2014/05)

4 | Key to symbols and safety instructions

Important information for the user

This appliance may only be installed by a registered LP Gas

installer.

All registered installers are issued with a card carrying their

registration number.

Ask to be shown the card before allowing the installation

work to commence and make anote of the Installer QCC

number. Upon completion of the installation, the installer is

required to explain the operational details of the appliance

together with the safety instructions. You will be asked to

sign acceptance of the installation and be provided with a

completion certicate. You should only sign for acceptance

of the installation whenthe installationis completed to your

satisfaction.Note that your invoice is required in the event

that you wish make a guarantee claim.

Important information for the installer

This appliance may only be installed by a LP gas installer

registered with the Liqueed Petroleum Gas Association of

Southern Africa.

The appliance must be installed in accordance with the

requirements of SANS 10087-1 and any re department

regulations and/or local by lawsapplicable to the area. If in

doubt check with the relevant authority before undertaking

the installation.

Upon completion of the installation you are required to fully

explain and demonstrate to theuser the operational details

and safety practices applicable to the appliance and the

installation.

Client information

Inform the client about the function and operation of the

appliance.

Caution clients against performing modications or repairs

themselves.

Risk of damage dueto operator error

Operator errors can result in injury and damage to property.

Ensure that children never operate this appliance

unsupervised or play with it.

Ensure that only personnel who can operate this appliance

correctly have access to it.

6720648592 (2014/05)

Technical Characteristics and Dimensions | 5

2 Technical Characteristics and Dimensions

2.1 Declaration of conformity with relevant EEC

regulations

This appliance fullls European directive requirements 2009/

142/EC, 2006/95/EC, 2004/108/EC and corresponds to the

specications described in the corresponding EEC certicate

of proof.

2.2 Explanation of Model Code

[W] Gas Water Heater

[R] Proportional power adjustment

[11] Capacity (l/min)

[B] Electronic ignition powered by 1.5 V batteries

[23] Indicator number of natural gas H

[31] Indicator number of LPG

[S...] Country code

The code number indicates the gas group according to EN 437:

2.3 Accessories (Included with Appliance)

•Gas water heater,

•Attachment elements,

•Installation accessories,

•Two 1.5 V batteries type R

•Heater documentation.

2.4 Description of the heater

Operating convenience, as the heater is ready to operate by

simply pressing a switch.

•Heater for wall-mounting,

•Ignition by electronic devicetriggered when the water valve

opens,

•Great savings in comparisonwith conventional heaters,

due to the possibility of power adjustment and no

permanent pilot ame,

•Natural gas/LPG burner,

•Semi-permanent pilot burner which only functions during

the period between the opening of the water valve and the

ignition of the main burner,

•Heat exchanger in copperwithout tin/lead covering,

•Water valve in breglass-reinforced polyamide, 100%

recyclable,

•Automatic adjustment of the water ow by means of a

device which permits a constant ow to be maintained in

spite of variable pressure supplies,

•Gas ow adjustment proportional to the water ow to

maintain a constant high temperature.

•Safety devices:

– Ionisation probe to check for accidental extinction of

the burner ame,

– Flue gas safety device whichturns o the heater in case

of inadequate combusted gas evacuation conditions,

– Temperature limiter which prevents overheating of the

heat exchanger.

2.5 Type overview

The type plate is located at the bottom left of the appliance.

There you will nd details ofappliance output, model number,

approval data and the serial number.

2.6 Special accessories

•Conversion kit from natural gas to butane/propane.

Model WR 11/14/18 B...

Category II2H3+

Type Type B

Table 2

WR 11 B 23

S....

WR 14 B 23

S....

WR 18 B 23

S....

Table 3

Identication

Code

Wobbe Index (Ws)

(15 °C) Gas type

23 12,7-15,2 kWh/m3Natural Gas - Group H

31 20,2-21,3 kWh/m3LPG - Group B/P

Table 4

6720648592 (2014/05)

6 | Technical Characteristics and Dimensions

2.7 Dimensions

Fig. 1

[1] Front cover

[2] Hole for xing to wall

[3] Temperature control

[4] Led indicator for battery charge level

[5] ON/OFF switch

[6] Led indicator for burner status

[7] Output control

[8] Gas connection

[9] Flue socket

[10] Draught diverter with ue gas monitor

[11] Heat exchanger

[12] Automatic gas valve

[13] Igniter unit

[14] Battery compartment

Dimensions (mm) A B C D E F G

H (Ø)

Natural

gas LPG

WR11B 310 580 228 112,5 463 60 25 1/2” 1/2”

WR14B 350 655 228 132,5 510 95 30 1/2” 1/2”

WR18B 425 655 334 132,5 540 65 30 1/2” 1/2”

Table 5 Dimensions

6720648592 (2014/05)

Technical Characteristics and Dimensions | 7

2.8 Electrical diagram

Fig. 2 Electrical diagram

[1] Servo valve (normally open)

[2] Diaphragm valve

[3] Main valve (normally closed)

[4] Ionisation detector

[5] Igniter electrode

[6] Flue gas safety device

[7] Temperature limiter

[8] Igniter unit

[9] LED indicator for battery charge level

[10] LED indicator for burner status

[11] ON/OFF switch

[12] Batteries, 1.5V

[13] Microswitch

2.9 Function

This gas heater is equipped withautomatic electronic ignition

which simplies its operation.

To do so, just turn on the switch (Fig. 5).

After this procedure, automaticignition occurs whenever a hot

water tap is opened. First, the pilot burner is lit and

approximately four seconds afterwards the main burner. The

pilot burner ame is then extinguished after a short period of

time.

This is a way of saving a greatamount of energy as the pilot

burner only operates for the minimum necessary time to ignite

the main burner, in contrastto conventional systems which

operate permanently.

If this happens:

Close and open the hot watertap to repeat the ignition

process until all the air has been purged.

Air in the gas supply pipe when the heater is

started up may cause ignition to fail.

6720648592 (2014/05)

8 | Technical Characteristics and Dimensions

2.10 Technical characteristics

Technical characteristics Symbol Units WR11 WR14 WR18

Power and ow

nPrewoplufesulanimoN Btu/h 65570 80595 104165

nimPrewoplufesumuminiM Btu/h 23905 23905 23905

Useful power (adjustment range) Btu/h 23905-

65570

23905 -

80595

23905 -

104165

nQwolflamrehtlanimoN Btu/h 74450 92210 117825

nimQwolflamrehtmuminiM Btu/h 27660 27660 27660

Gas data1)

1) Hi 15 °C - 1013 mbar - dry: Natural gas 34.02 MJ/m

3(9.5 kWh/m

LPG: Butane 45.65 MJ/kg (12.7 kWh/kg) - Propane 46.34 MJ/kg (12.9 kWh/kg)

Supply pressure

02GHsaglarutaN kPa 2 2 2

03G)enaporP/enatuB(GPL kPa 2,8 2,8 2,8

Consumption

02GHsaglarutaN m3/h2,2 2,77 3,5

03G)enaporP/enatuB(GPL Kg/h 1,75 2,2 2,79

Number of injectors 12 14 18

Water data

Maximum permissible pressure

2) Considering the water dilution eectthis value must not be exceeded.

pw psi 170 170 170

Temperature selector in fully clockwise position

Temperature rise °C 50 50 50

Flow range l/min 2 - 5,5 2,0 - 7 2,0 - 8,8

nimwperusserpgnitarepomuminiM psi 1,5 1,5 3,0

Minimum pressure for maximum water ow psi 3,6 5,0 7,2

Temperature selector in fully anti-clockwise position

Temperature rise °C 25 25 25

Flow range l/min 4 - 11 4 - 14 4 - 17,6

Minimum pressure for maximum water ow psi 8,7 14,5 19

Combustion products

3) For nominal caloric power.

Minimum low pressure mbar 0,015 0,015 0,015

Flow g/s 13 17 22

Temperature °C 160 170 180

Table 6

6720648592 (2014/05)

Use | 9

3 Use

3.1 Before starting up the heater

Check if the gas indicated on the rating plate is the same as

the one used at the location.

Open the gas valve.

Open the water valve.

3.2 Batteries

Battery insertion

Insert the two 1.5 V R20 batteries.

Fig. 3 Inserting the batteries

Replacing the batteries

The batteries must be changed ifthe red LED starts ashing.

Fig. 4 Replacing the batteries

Precautions when using the batteries

•Do not dispose of batteries asdomestic waste. Take them

to appropriate collecting places for recycling.

•Do not insert at batteries.

•Only use the type of batteries indicated.

3.3 Turning the heater on and o

Turning on

Press the switch , position .

Fig. 5

Green light on = Main burner on

Open all water and gas blocking devices.

Purge the pipes.

CAUTION:

The front panel in the burner and pilot burner

area may reach high temperatures, with risk of

burning in case of contact

CAUTION:

Initial startup must be performed by a

qualied technician who will provide the

client with all the necessary information

for optimum operation of the gas heater.

6720680412-01.1av

6720680412-02.1av

6720648592 (2014/05)

10 | Use

Fig. 6

Turning o

Press the switch , position .

3.4 Power adjustment

Lower water temperature.

Less power.

Fig. 7

Higher water temperature.

More power.

Fig. 8

3.5 Temperature/ow adjustment

Turn anti-clockwise

Increases ow and decreases water temperature.

Fig. 9

Turn clockwise.

Decreases ow and increases water temperature.

Regulating the temperature tothe minimum required value

reduces energy consumption as well as the possibility of

limescale deposits inthe heat exchanger.

3.6 Purge the appliance

If there is a risk of freezing, proceed as follows:

Remove the retaining clip from threaded bushing (Fig. 10,

[1]).

Remove threaded bushing (Fig. 10,[2]) from water valve.

6720680412-03.1av

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Bosch Chauffe-eau

Bosch

Bosch GWH 1000 Manuel utilisateur

Bosch

Bosch Tronic 1000 Manuel utilisateur

Bosch

Bosch OptiFlow Professional GWH12 1 CTD E23 Manuel utilisateur

Bosch

Bosch Greentherm T9800 SEC 160/199 Instructions d'utilisation

Bosch

Bosch T5600S 12 D 23 Instructions d'utilisation et d'installation

Bosch

Bosch 425HN Manuel de référence

Bosch

Bosch GWH 715 ES Instructions d'utilisation

Bosch

Bosch Compress 3000 DW FOO Manuel utilisateur

Bosch

Bosch Tronic 5000 T Manuel utilisateur

Bosch

Bosch 330-PN-N Manuel utilisateur

Bosch

Bosch Tronic 3000 C Pro US12 Manuel utilisateur

Bosch

Bosch GWH 2400 ES NG Manuel utilisateur

Bosch

Bosch 520PN Instructions d'utilisation

Bosch

Bosch AquaStar 125FX LP Manuel utilisateur

Bosch

Bosch Tronic 1000T ES 035-4 M 0 WIV-B Manuel d'utilisation

Bosch

Bosch TR4000R 6 ET Manuel utilisateur

Bosch

Bosch TRONIC 3000C Pro US7 Document technique

Bosch

Bosch Comfort Plus TR 4000 Manuel utilisateur

Bosch

Bosch GWH 425 PN Instructions d'utilisation

Bosch

Bosch 940ES Manuel utilisateur

Bosch

Bosch AQ 125BO LP Manuel utilisateur

Bosch

Bosch Integra 500 Series Manuel de référence

Bosch

Bosch Tronic Store Compact 1500 TOR Manuel utilisateur

Bosch

Bosch C 1210 ESC Manuel de référence

Manuels Chauffe-eau populaires d'autres marques

Kenmore

Kenmore 153.582400 Manuel utilisateur

Applimo

Applimo Edel AIR Manuel utilisateur

STIEBEL ELTRON

STIEBEL ELTRON Eltronom SHU 5 S Manuel utilisateur

clage

clage E-Mini Series Manuel utilisateur

Toyotomi

Toyotomi Oil Miser OM-180 Manuel utilisateur

Bradford White

Bradford White EF Series Manuel utilisateur

Eccotemp

Eccotemp 40-H Manuel utilisateur

Dimplex

Dimplex ECSd125-580 Mode d’emploi

Dux

Dux 32FCR6N Manuel utilisateur

Toyotomi

Toyotomi Oil Miser OM-148 (Type D) Guide de dépannage

Noritz

Noritz N-132M Manuel d'instructions

TESY

TESY GCV7/4S 10047 Fiche technique

A.O. Smith

A.O. Smith Gphe 50 Manuel utilisateur

Koryo

Koryo KWHZF15Y Manuel utilisateur

Pentair

Pentair PSC-14-4-02 Manuel utilisateur

GE 40M06AAG Instructions de montage

Thermor

Thermor AEROMAX SPLIT 2 Manuel utilisateur

American Hometec

American Hometec AHQ-B03X Manuel utilisateur
