360°-Indoor Camera
Instruction Manual
Bosch Smart Home
Start making your home smart! Set up your Indoor Camera in just three steps
▶ Start the Bosch
Bosch Smart
Cameras App
▶ Place the 360°-
Indoor Camera
and power it up
▶ Use the Bosch Smart
Cameras App to
connect and configure
your 360° Indoor
Camera
You need the Bosch Smart Cameras
App to install and configure your
Bosch Smart Home 360°-Indoor
Camera as well as to operate it.
Please also make sure that you have
an internet connection as well as
a WLAN router with a free LAN port.
Make sure that you download the
Bosch Smart Cameras App first!
5
Congratulations with the purchase of your Bosch Smart Home 360°-Indoor
Camera. It will help you to make your home more secure and smarter. Integrated
motion sensors automatically detect motion and record events. With the
Bosch Smart Cameras App you can access the recordings and live images from
anywhere. You will always know whether everything is in order in your home.
Further your privacy is always secure due to the retractable camera lense.
We hope you enjoy your new product,
The Bosch Smart Home Team
Dear customer,
6 7
1.0 Product overview ....................08
1.1 Target application ..................... 10
2.0 In the box .................................12
3.0 Warning notices ......................14
3.1 Safety message explanation ..... 14
3.2 Legal notice................................. 5
3.3 Safety precautions .................... 16
4.0 Indicators and control ............18
4.1 Product overview ...................... 18
5.0 Installation and initial
configuration ...........................20
5.1 Check the Wi-fi availability ........ 21
5.2 Indoor Camera installation........ 22
5.3 Power the Indoor Camera ......... 24
5.4 Configuration of the
Indoor Camera .......................... 26
6.0 Indoor Camera operation.......28
7.0 Error and error resolutions....29
8.0 Product details........................30
8.1 Technical details ....................... 30
8.2 Declaration of conformity ......... 31
8.3 Faults in radio operation ........... 32
8.4 Open-Source-Software............. 32
8.5 Environmental protection
and product disposal ................ 34
9.0 Further informations ..............35
INDEX
8 9
Bosch Smart Home 360°-Indoor
Camera is controlled via Wi-fi and has
the following features:
▶ 360° coverage through motorized
head
▶ Night Vision with automatic
IR illumination
▶ Retractable lens, no lense ensures
your privacy
▶ Pre-installed 8 GB SD-Card
stores about 200 Events
▶ Microphone and speaker
for two-way communication
▶ HD quality video recording
1.0 PRODUCT OVERVIEW
Detailed information on advanced set-up and sharing
you can find at www.bosch-smarthome.com
10 11
1.1 Target application
The product must only be used
together with original Bosch Smart
Home components, and is for indoor
use only.
▶ Please make sure you strictly follow
the safety and installation instruc-
tions in this document as well as in
the Bosch Smart Cameras App
▶ Only use the Indoor Camera accord-
ing the installation instructions and
within the temperature and humidity
limits as described in the Technical
Data section (see p. 30)
▶ Avoid direct sun light and heat
sources like radiators close to the
Indoor Camera
Do not modify the product in any way. Any other use is considered
unintended use. We will not assume liability for any resulting damage.
12 13
2.0 IN THE BOX
An 8 GB SD card is pre-installed but can be exchanged
(video on the card will be lost in case of exchange).
Power cableIndoor Camera 3 country specific adapters
14 15
3.0 WARNING NOTICES
3.1 Safety message explanation
3.2 Legal notice
Notice!
Indicates a situation which, if not avoided, could result to
damage of the equipment or environment, or data loss.
Caution!
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
Privacy
The Bosch Indoor Camera is designed for indoor personal use. Laws in
your country may restrict the observation of areas outside your private
property. Please check your local legislation.
To respect privacy, please avoid placing your Indoor Camera to record
public space including the street as well as private property of your
neighbors. We advise to inform relatives, visitors and home employees
that a Indoor Camera is installed and might be in operation.
Security
By using the Bosch Indoor Camera you agree not to rely on the device
and its services for life safety or critical purposes. Mobile notifications
are provided for informational purposes only. Bosch Smart Home
GmbH cannot be held liable for missing or incorrect notifications or
event registrations.
16 17
3.3 Precautions
Do not open the Indoor Camera. The Indoor Camera does not contain
any user
replaceable parts. If the Indoor Camera stops working please contact
customer service via telephone 00800 843 762 78.
Pleas adhere to manual instructions on intended use.
Please only use the power supply which was delivered with the
Indoor Camera. Please do not paint the Indoor Camera.
Recommended replacement of Indoor Camera after 10 years.
18 19
3
4
2
1
Front Back
4.0 INDICATORS AND CONTROL
4.1 Product overview
Pos. Description Explanation
1Wide angle lens Covers a horizontal viewing
angle of 112 degrees, through rotation 360°
2Mikrophone –
3Speaker mesh Covers loudspeaker
4Motion detector
3 motion detectors have 360 degree
coverage and allow motion sensing outside the
viewing angle of the Indoor Camera
5SD card slot Main storage medium, SD card is pre-installed
(8 GB)
6Power supply
input –
7Light ring Lights up in various colors during installation
and blue in normal operation
8Reset hole Resets all settings, deletes all recordings,
removes camera from system
7
8
65
