Bosch GLM 100 C Instructions de montage

IMPORTANT: IMPORTANT : IMPORTANTE:

Read Before Using Lire avant usage Leer antes de usar

Operating/Safety Instructions

Consignes d’utilisation/de sécurité

Instrucciones de funcionamiento y seguridad

1-877-BOSCH99 (1-877-267-2499) www.boschtools.com

Call Toll Free for

Consumer Information

& Service Locations

Pour obtenir des informations

et les adresses de nos centers

de service après-vente,

appelez ce numéro gratuit

Llame gratis para

obtener información

para el consumidor y

ubicaciones de servicio

For English Version Version française Versión en español

See page 6 Voir page 43 Ver la página 79

GLM 100 C

-2-

GLM 100 C

Pr of essional

GLM 100 C

10 11 12 13

i k

lmn

-3-

•

• •

max

min

AAAAA

D E

-4-

180º 90º 180º

-5-

180º

90º

180º

90º

-6-

DLA 001

2 610 952 264

R 60

0 601 079 010

DLA 002

2 610 952 265

BS 150

0 601 096 977

General Safety Rules

Read all instructions. Failure to follow all

instructions listed below may result in hazardous

radiation exposure, electric shock, fire and/or serious injury.

SAVE ALL WARNINGS AND INSTRUCTIONS

FOR FUTURE REFERENCE

The term “tool” in the warnings listed below refers to your mains-operated

(corded) tool or battery-operated (cordless) tool.

The following labels are on your laser tool for your convenience and

safety. They indicate where the laser light is emitted by the tool.

ALWAYS BE AWARE of their location when using the tool.

WARNING

-7-

Do not direct the laser beam at persons or animals

and do not stare into the laser beam yourself. This tool

produces laser class 2 laser radiation and complies

with 21 CFR 1040.10 and 1040.11 except for deviations

pursuant to Laser Notice No. 50, dated June 24, 2007.

Working safely with the measuring tool is possible only when the

operating and safety information are read completely and the

instructions contained therin are strictly followed. Never make

warning labels on the Measuring tool unrecognizable.

Never aim the beam at a workpiece with a reflective surface. Bright

shiny reflective sheet steel or similar reflective surfaces are not

recommended for laser use. Reflective surfaces could direct the beam

back towards the operator.

Take care to recognize the accuracy and range of the device.

Measurement may not be accurate if used beyond the rated range of the

device.

Use of controls or adjustments or performance of procedures

other than those specified herein may result in hazardous radiation

exposure.

Safety Rules

-8-

Safe Operating Procedures

Be sure to read and understand all instructions in this manual

before using this product. Failure to follow all instructions may result

in hazardous radiation exposure, electric shock, fire, and/or bodily injury.

Use of controls or adjustments or performance of procedures

other than those specified in this manual, may result in hazardous

radiation exposure.

The use of optical instruments with this product will increase eye

hazard.

IMPORTANT: The following labels are on your measuring tool for

your convenience and safety. They indicate where the laser light

is emitted by the level. ALWAYS BE AWARE of their location when

using the level.

ALWAYS: Make sure that any bystanders in the vicinity of use are

made aware of the dangers of looking directly into the measuring

tool.

DO NOT remove or deface any warning or caution labels. Removing

labels increases the risk of exposure to laser radiation.

DO NOT stare directly at the laser beam or project the laser beam

directly into the eyes of others. Serious eye injury could result.

The use of optical instruments with this product will increase eye

hazards.

Have the measuring tool repaired only through qualified specialist

using original spare parts. This ensures that the safety of the measuring

tool is maintained.

Do not allow children to use the measuring tool without supervision.

They could unintentionally blind other persons.

Do not use the laser viewing glasses as safety goggles. The laser

viewing glasses are used for improved visualization of the laser beam, but

they do not protect against laser radiation.

Do not use the laser viewing glasses as sun glasses or in traffic.

The laser viewing glasses do not afford complete UV protection and reduce

color perception.

-9-

DO NOT place the measuring tool in a position that may cause

anyone to stare into the laser beam intentionally or unintentionally.

Serious eye injury could result.

DO NOT use any optical tools such as, but not limited to, telescopes

or transits to view the laser beam. Serious eye injury could result.

DO NOT operate the measuring tool around children or allow

children to operate the measuring tool. Serious eye injury could result.

ALWAYS turn the measuring tool “OFF” when not in use. Leaving the

measuring tool “ON” increases the risk of someone inadvertently staring

into the laser beam.

DO NOT operate the measuring tool in combustible areas such as

in the presence of flammable liquids, gases or dust.

ALWAYS position the measuring tool securely. Damage to the

measuring tool and/or serious injury to the user could result if the measuring

tool falls.

ALWAYS use only the accessories that are recommended by the

manufacturer of your measuring tool. Use of accessories that have

been designed for use with other measuring tools could result in serious

injury.

DO NOT leave measuring tool “on” unattended in any operation

mode.

Repair and servicing must always be performed by a qualified

repair facility. Repairs performed by unqualified personnel could result

in serious injury.

DO NOT use this measuring tool for any purpose other than those

outlined in this manual. This could result in serious injury.

DO NOT disassemble the measuring tool. There are no user

serviceable parts inside. Disassembling the laser will void all

warranties on the product. Do not modify the product in any way.

Modifying the measuring tool may result in hazardous laser radiation

exposure.

In case of damage and improper use of the battery, vapors may

be emitted. Provide for fresh air and seek medical help in case of

complaints. The vapors can irritate the respiratory system.

-10-

Do not use the measuring tool with

Bluetooth

® in the vicinity of gas

stations, chemical plants, areas where there is danger of explosion

and areas subject to blasting. Do not use the measuring tool with

Bluetooth

® in airplanes. Do not use the measuring tool with

Bluetooth

® in the vicinity of medical devices. Avoid operation in the

direct vicinity of the human body over longer periods of time. When

using the measuring tool with

Bluetooth

®, interference with other devices

and systems, airplanes and medical devices (e.g., cardiac pacemakers,

hearing aids) may occur.

The

Bluetooth

® word mark and logos are registered trademarks owned

by Bluetooth SIG, Inc. and any use of such marks by Robert Bosch Tool

Corporation is under license.

The manufacturer is not responsible for radio interference caused by

unauthorized modifications to this equipment. Such modifications could

void the user’s authority to operate the equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject

to the following two conditions:

1) This device may not cause harmful interference, and

2) This device must accept any interference received, including interference

that may cause undesired operation.

NOTE! This equipment has been tested and found to comply with the limits

for a Class B digital devices, pursuant to Part 15 of the FCC rules. These limits

are designed to provide reasonable protection against harmful interference in

a residential installation. This equipment generates uses and can radiate radio

frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the user is encouraged to

try to correct the interference by one or more of the following measures:

• Reorientorrelocatethereceivingantenna.

• Increasetheseparationbetweentheequipmentandreceiver.

FCC Caution

Bluetooth
