Bosch GCL 2-160 Instructions de montage

Operating / Safety Instructions

Consignes d’utilisation / de sécurité

Instrucciones de funcionamiento y seguridad

GCL 2-160

IMPORTANT:

Read Before Using

IMPORTANT :

Lire avant usage

IMPORTANTE:

Leer antes de usar

English Version

See page 7

Version française

Voir page 34

Versión en español

Ver la página 68

1-877-BOSCH99 (1-877-267-2499) www.boschtools.com

GCL 2-160

-2-

GCL 2-160

1 10 11

GCL 2-160

1 3 4 5

-3-

RM 1

149

GCL 2-160

-4-

B1 C1

H I

-5-

B2 C2

H I

-6-

LR6

Professional

1 608 M00 70J

BT 150

(0 601 096 B10)

1 608 M00 806

1 608 M00 C1S

BM 1 (0 601 015 A11)

BM 3 (1 600 A00 19K)

LR 6 (0 601 069 H10)

LR 7 (0 601 069 J10)

1 600 A00 19K

RM 1 (0 601 092 610)

BP 350

(0 601 015 B10)

RM 2 (0 601 092 710)

1 618 C01 44F

1 618 C01 44K

1 605 438 166

LR7

Professional

-7-

Safety Symbols

The definitions below describe the level of severity for each signal

word. Please read the manual and pay attention to these symbols.

This is the safety alert symbol. It is used

to alert you to potential personal injury

hazards. Obey all safety messages that

follow this symbol to avoid possible injury

or death.

DANGER indicates a hazardous situation

which, if not avoided, will result in death

or serious injury.

WARNING indicates a hazardous

situation which, if not avoided, will result

in death or serious injury.

CAUTION, used with the safety alert

symbol, indicates a hazardous situation

which, if not avoided, will result in minor

or moderate injury.

-8-

Read all instructions. Failure to follow all

instructions listed below may result in hazardous

radiation exposure, electric shock, fire and/or serious injury.

SAVE ALL WARNINGS AND INSTRUCTIONS FOR

FUTURE REFERENCE

The term “tool” in the warnings listed below refers to your mains-

operated (corded) tool or battery-operated (cordless) tool.

The following labels

are on your laser tool

for your convenience

and safety. They

indicate where the

laser light is emitted by the tool. ALWAYS BE AWARE of their

location when using the tool.

DO NOT direct the laser beam at persons or animals

and do not stare into the laser beam yourself.

This tool produces laser class 2 laser radiation and

complies with 21 CFR 1040.10 and 1040.11 except for

deviations pursuant to Laser Notice No. 50, dated June 24, 2007.

This can lead to persons being blinded.

DO NOT remove or deface any warning or caution labels.

Removing labels increases the risk of exposure to laser

radiation.

Use of controls or adjustments or performance of

procedures other than those specified in this manual, may

result in hazardous radiation exposure.

ALWAYS make sure that any bystanders in the vicinity of

use are made aware of the dangers of looking directly into

the laser tool.

General Safety Rules

-9-

DO NOT place the laser tool in a position that may cause

anyone to stare into the laser beam intentionally or

unintentionally. Serious eye injury could result.

ALWAYS position the laser tool securely. Damage to the

laser tool and/or serious injury to the user could result if the

laser tool falls.

ALWAYS use only the accessories that are recommended

by the manufacturer of your laser tool. Use of accessories

that have been designed for use with other laser tools could

result in serious injury or unsatisfactory performance.

DO NOT use this laser tool for any purpose other than

those outlined in this manual. This could result in serious

injury or unsatisfactory performance.

DO NOT leave the laser tool “ON” unattended in any

operating mode.

DO NOT disassemble the laser tool. There are no user

serviceable parts inside. Do not modify the product in any

way. Modifying the laser tool may result in hazardous laser

radiation exposure.

Work area safety

Keep work area clean and well lit. Cluttered or dark areas invite

accidents.

DO NOT operate the laser tool around children or allow children

to operate the laser tool. Serious eye injury could result.

Do not operate the measuring tool in explosive environments,

such as in the presence of ﬂammable liquids, gases or dusts.

Sparks can be created in the measuring tool which may ignite the

dust or fumes.

-10-

Electrical safety

Batteries can explode or leak, cause injury or fire. To reduce this

risk, always follow all instructions and warnings on the battery label and

package.

DO NOT short any battery terminals.

DO NOT charge alkaline batteries.

DO NOT mix old and new batteries.

Replace all of them at the same time with new batteries of the

same brand and type.

DO NOT mix battery chemistries. Dispose of or recycle batteries

per local code.

DO NOT dispose of batteries in fire.

Keep batteries out of reach of children.

Remove batteries if the device will not be used for several

months.

Personal safety

If laser radiation strikes your eye, you must deliberately close

your eyes and immediately turn your head away from the beam.

Do not make any modiﬁcations to the laser equipment.

Do not use the laser viewing glasses as safety goggles. The la-

ser viewing glasses are used for improved visualisation of the laser

beam, but they do not protect against laser radiation.

Do not use the laser viewing glasses as sun glasses or in trafﬁc.

The laser viewing glasses do not afford complete UV protection and

reduce colour perception.
