Bosch MPC-xxxx-C Series Manuel utilisateur
Panel Controller
MPC-xxxx-C | FPA-1200-MPC-C
en User Guide
Panel Controller Table of contents | en 3
Bosch Sicherheitssysteme GmbH User Guide 2017.09 | 7.0 | F.01U.258.929
Table of contents
1For your information 8
1.1 Open Source license agreement 8
1.2 Depiction of steps 8
1.3 Calling up the start menu 9
1.4 Changing language display 9
1.5 Warranty and liability 9
1.6 Copyright 9
2For your safety 10
2.1 Symbols and notes used 10
2.2 Operating the touch screen 10
2.3 Maintenance 10
2.4 Usage in accordance with regulations 11
2.5 Skills required by personnel 11
3All functions at a glance 12
3.1 Calling up the start menu 12
3.2 Bypass/Isolate 12
3.2.1 Bypass 12
3.2.2 Isolate 12
3.3 Diagnostics 13
3.4 Maintenance 14
3.4.1 Walktest 14
3.4.2 Change language 15
3.4.3 Activate Outputs 15
3.4.4 Activate the transmission device 15
3.4.5 Detector removal 15
3.4.6 History Log 15
3.4.7 Change device on V.24 Interface 16
3.5 Configuration 16
3.6 Switching to day or night mode 17
3.7 Further functions 17
3.8 Search Function/Element 18
3.9 Reset 18
4In overview 19
4.1 Operating elements 19
4.2 Display elements 20
4.3 Touch screen 21
4.4 Display support information 23
5Operating principle 24
5.1 Logging on and off 24
5.1.1 Logging in 24
5.1.2 Logging out 25
5.2 Access authorization 25
5.3 Calling up the start menu 25
5.4 Personalized menu 25
5.5 Selecting the menu 26
5.6 Returning to the previous selection 26
5.7 Working with lists 26
5.7.1 Scrolling through lists 27
4en | Table of contents Panel Controller
2017.09 | 7.0 | F.01U.258.929 User Guide Bosch Sicherheitssysteme GmbH
5.7.2 Various states of list fields 27
5.7.3 Selecting element/function 28
5.7.4 Assigning mode 28
5.8 Search Function/Element 29
5.8.1 Search by name 29
5.8.2 Searching by number 29
5.9 Entering numbers and text 29
5.9.1 Changing an entry 31
5.9.2 Deleting all numbers 31
5.10 Changing language display 31
5.10.1 Entering key combination 31
5.11 Switching between status bars 31
5.12 Standby 31
5.13 Logical and physical addressing 31
6Networked panels 33
6.1 Icons on the display 33
6.2 Network addressing 33
6.3 Establishing a remote connection with a networked panel 34
6.4 Terminating a remote connection with a networked panel 34
6.5 Isolating and restricted connection 34
7Networking via Ethernet 36
7.1 IP settings 36
7.2 Ethernet redundancy 37
7.3 Diagnostics 38
8Remote keypad 39
8.1 Operation and display 39
9Alarm 40
9.1 Types of alarm 40
9.2 Entry delays 40
9.3 Day and night mode 41
9.4 Alarm message to the panel 42
9.4.1 Optical and acoustic signals 42
9.4.2 Displaying the detector zones in alarm state 42
9.4.3 Sequence of the alarm messages 43
9.4.4 Information about logical zones in the alarm state 43
9.4.5 The newest message 44
9.4.6 Displaying the individual detectors in a logical zone 44
9.4.7 Information about individual detectors 44
9.4.8 Displaying additional information 45
10 Fire alarm 46
10.1 Optical and acoustic signals 46
10.2 Acknowledging a message 46
10.3 Switching off internal buzzer 46
10.4 Switching external signaling devices on and off 47
10.5 Resetting external signaling devices and transmission devices 47
10.6 Triggering fire verification 47
10.6.1 Alarm verification 47
10.6.2 Starting time to investigate 48
10.6.3 Triggering alarm manually 48
Panel Controller Table of contents | en 5
Bosch Sicherheitssysteme GmbH User Guide 2017.09 | 7.0 | F.01U.258.929
10.7 Resetting alarm message 49
10.8 Bypassing detectors 49
11 Fault message 51
11.1 Calling up fault indication 51
11.2 Trouble message on the panel 51
11.2.1 Acknowledging a message 51
11.2.2 Sequence of the trouble messages 52
11.2.3 Information about malfunctioning element groups 52
11.2.4 The newest message 53
11.2.5 Displaying individual elements of an element group 53
11.2.6 Information about individual elements 53
11.2.7 Displaying additional information 53
11.2.8 Signals 54
11.3 Resetting malfunction message 54
11.4 Isolating an element 55
12 Bypass 56
12.1 Menu overview 56
12.2 Bypassing and un-bypassing elements 56
12.3 Displaying and un-bypassing bypassed element groups 57
12.4 Displaying list of all bypassed elements 57
12.4.1 Using the menu 57
12.4.2 Via the status bar 58
12.5 Bypassing/Un-bypassing buzzer 58
13 Isolate 59
13.1 Menu overview 59
13.2 Isolating and de-isolating elements 59
13.3 Displaying list of all isolated elements 59
13.3.1 Using the menu 60
13.3.2 Via the status bar 60
14 Diagnostics 61
14.1 Menu overview 61
14.2 Element details 61
14.3 Modules 62
14.4 Hardware 62
14.4.1 Address cards 62
14.4.2 Display 62
14.4.3 Serial Interface 64
14.4.4 CAN-Bus 64
14.5 Panel Passport 64
14.6 LED Test on modules 64
14.7 Network services 64
14.7.1 Routing table 64
14.7.2 Consistency check 65
14.7.3 Ethernet ports 65
14.7.4 Send ping command 66
14.7.5 Ethernet redundancy 66
14.7.6 Remote services 67
14.8 Voice alarm systems 68
15 Maintenance 70
6en | Table of contents Panel Controller
2017.09 | 7.0 | F.01U.258.929 User Guide Bosch Sicherheitssysteme GmbH
15.1 Menu overview 70
15.2 Changing language display 70
15.3 Activate Outputs 70
15.4 Activate Transmission Device 71
15.5 Detector removal 71
15.6 Change device on V.24 Interface 71
15.7 Bypassing/Un-bypassing buzzer 72
16 Maintenance – walktest 73
16.1 Walktest groups 73
16.1.1 Adding or deleting elements 73
16.2 Starting and ending walktest 75
16.2.1 Starting the walktest 75
16.2.2 Ending the walktest 75
16.3 Ending walktest for all elements 75
16.4 Displaying tested or untested elements 76
16.5 Assigning tested elements to a walktest group 76
17 Maintenance – history log 77
17.1 Selecting filters 77
17.2 Setting filters 77
17.3 Change Filter 78
17.4 Combining several filters 78
17.5 Status bar functions 78
17.6 Printing out data 79
18 Day and night mode 80
18.1 Switching between day and night mode 80
18.2 Showing details 81
18.3 Changing the time for resetting to night mode 81
19 Configuration 83
19.1 Menu overview 83
19.2 Input / Output Group Set Up 83
19.2.1 Adding or deleting elements 83
19.2.2 Change name 85
19.3 Group setting 85
19.3.1 Adding or removing 85
19.4 Detector sensitivity 85
19.5 Operator 86
19.5.1 Change password 86
19.5.2 Change universal password 86
19.5.3 Set Default Password 87
19.6 Rename elements 87
19.7 Network services 87
19.7.1 Ethernet 87
19.7.2 Change date/time 87
19.7.3 Remote Services 87
19.8 Overview 88
20 Further functions 89
20.1 Menu overview 89
20.2 Change Date / Time 89
20.3 Master password 89
Panel Controller Table of contents | en 7
Bosch Sicherheitssysteme GmbH User Guide 2017.09 | 7.0 | F.01U.258.929
20.3.1 Enter the master password that is valid indefinitely 89
20.3.2 Enter the 24-hour master password 90
20.4 Remote Services 90
20.5 Change password 91
20.6 Performing a fire drill 91
20.7 Alarm Counters 92
21 Reset 93
21.1 Menu overview 93
21.2 Resetting elements 93
22 Search Function/Element 94
22.1 Menu overview 94
22.2 Searching for function and device description 94
22.3 Search element 94
Index 95
8en | For your information Panel Controller
2017.09 | 7.0 | F.01U.258.929 User Guide Bosch Sicherheitssysteme GmbH
1 For your information
Notice!
A language dependent inscription strip (ordering number F.01U.343.398) for insertion into
the main panel controller is attached to this operation guide.
This operation guide contains important information and notes on operating the FPA-5000/
FPA-1200.
Using the step-by-step directions, you can familiarize yourself with the individual functions:
–In overview, page 19 provides an overview of the operating and display elements and the
touch screen.
– In Operating principle, page 24, you will learn how to navigate through the individual
menus and which selection possibilities are available to you.
Each function is described in detail in an individual chapter.
Notice!
In standby mode, the standby screen is displayed. This contains different information
depending on the configuration.
If no longer operated, the panel controller switches to standby mode after 5 minutes and an
alarm event occurs after one hour. The touch screen backlighting switches off. To quit
standby mode, touch any part of the touch screen.
To call up the start menu or change the language display, see Operating principle, page 24.
You will find specific topics in the table of contents. If you are already practiced in the
handling of menus, you can use the overview of all menus in All functions at a glance, page 12.
See also
– In overview, page 19
– Operating principle, page 24
– All functions at a glance, page 12
– In overview, page 19
– Operating principle, page 24
– All functions at a glance, page 12
1.1 Open Source license agreement
Notice!
Bosch Sicherheitssysteme GmbH uses open source software within this product. The
declaration of the components and their respective licenses can be found on http://
www.boschsecurity.com/oss/.
1.2 Depiction of steps
The sequence of steps that you need to execute a function is depicted as follows:
1. In the start menu, select Bypass Block
2. Bypass
In more detailed form:
1. Call up the start menu.
2. Select Bypass Block.
3. Select Bypass.
Panel Controller For your information | en 9
Bosch Sicherheitssysteme GmbH User Guide 2017.09 | 7.0 | F.01U.258.929
1.3 Calling up the start menu
4Press the "home" key.
You can use this key to return from any submenu back to the start menu.
Notice!
The display changes from each menu element to the standby display if no entries are made
within one minute.
1.4 Changing language display
The panel language can be changed quickly with a shortcut; see the following instruction To
change the panel language using the menu, see Changing language display, page 31.
1. Select the "home" key.
2. Then press 1 on the alphanumeric keypad immediately after this.
3. Select OK to confirm the entry or Cancel to cancel the operation.
A list of the existing languages is displayed.
4. Select the language you require.
The displays are displayed in the selected language.
Notice!
After a system reboot following a power cut or battery failure, the default language set in the
FSP‑5000‑RPS is displayed again.
1.5 Warranty and liability
Warranty and liability claims for personal and property damage are excluded if these were
caused by one or several of the following causes:
– Use of the FPA-5000/FPA-1200 fire panel contrary to the regulations
– Improper set-up, installation, start-up, operation or maintenance
– Disregarding of the user manual
– Subsequent constructional changes
– Faulty repairs
– Catastrophes, influence of foreign bodies, and force majeure.
Without the permission of Bosch, no changes or additions to or rebuilding of the panel
including the panel controller may be undertaken.
Rebuilding requires written permission. In case of non-approved constructional changes, any
warranty claims against Bosch are voided.
1.6 Copyright
Bosch Sicherheitssysteme GmbH, Robert-Bosch-Ring 5, 85630 Grasbrunn, Germany retains
the complete copyright to the whole documentation. Without the express written permission
of Bosch, no part of these documents may be duplicated or transmitted in any form.
Bosch reserves the right to make changes to this manual without prior notice.
10 en | For your safety Panel Controller
2017.09 | 7.0 | F.01U.258.929 User Guide Bosch Sicherheitssysteme GmbH
2 For your safety
Before using the device, familiarize yourself with these instructions. If you do not read and
understand these explanations, you will not be able to operate the device faultlessly.
The operating instructions do not do away with the need for training by authorized personnel.
Notice!
The panel controller may only be operated by trained personnel. See skills required by
personnel.
This operation guide does not contain any general or special knowledge about safety issues.
Information on such issues is only given to the extent that it is needed for operation of the
device.
Ensure that you are familiar with all safety-related processes and regulations in your area. This
also includes how to behave in the event of an alarm and the initial steps to take if a fire
breaks out.
The operation guide should always be available on site. It is a statutory part of the system and
must be given to the new owner if the system is ever sold.
Notice!
The personal access code (consisting of user ID and password) must not be made known to
third parties.
2.1 Symbols and notes used
The various chapters only contain whatever safety information and notes are required for
operation of the system. Warning notes and operator guidance notes are displayed in the
appropriate parts of the panel controller display for your benefit.
The following search symbols are used:
!
Caution!
Text fields marked with this symbol contain warnings by which you must abide without fail —
for your own safety as well as that of the people around you
Notice!
Text fields marked with this symbol contain useful information to help you operate the
FPA-5000/FPA-1200 fire panel.
2.2 Operating the touch screen
Do not use any pointed or sharp objects when operating the touch-sensitive display. This
could damage the surface. Touch the touch screen with your finger (nail) or the stick attached
to the left-hand side of the panel controller.
2.3 Maintenance
Clean the touch screen and membrane keypad with a soft cloth only. If necessary, dampen the
cloth lightly with standard monitor cleaning agents. Do not use any aggressive cleaning agents
and ensure that no liquid enters the inside of the device.
Autres manuels pour MPC-xxxx-C Series
1
Ce manuel convient aux modèles suivants
1
Table des matières
Autres manuels Bosch Panneau de contrôle
Bosch
Bosch Ultima 862 Manuel utilisateur
Bosch
Bosch ICP-SOL2-P Manuel utilisateur
Bosch
Bosch Radionics D8024 Guide de démarrage rapide
Bosch
Bosch AMAX panel 2100 Manuel utilisateur
Bosch
Bosch AVENAR FPE-8000-SPC Manuel utilisateur
Bosch
Bosch B9512G Manuel utilisateur
Bosch
Bosch D9412GV2 Manuel utilisateur
Bosch
Bosch Rexroth IndraControl VCP 25 Manuel technique
Bosch
Bosch D9124 Manuel technique
Bosch
Bosch Solution 6+6 Wireless On/Off Manuel utilisateur
Bosch
Bosch D9112B Guide de dépannage
Bosch
Bosch DS3MX-E-U Manuel utilisateur
Bosch
Bosch B9512G Manuel utilisateur
Bosch
Bosch D7212GV2 Comment utiliser
Bosch
Bosch FPA-5000 Manuel utilisateur
Bosch
Bosch D9412GV4 Manuel utilisateur
Bosch
Bosch Solution 880 CC408 Manuel utilisateur
Bosch
Bosch Solution-16 safecom Manuel utilisateur
Bosch
Bosch DS7200V2-EXP Manuel utilisateur
Bosch
Bosch Easy Series Manuel utilisateur
