Bosch DCN-DIS Guide de référence

DCN-DIS Discussion Unit (Chairman)

On:

Microphone active

Voice mode

Channel

selector

Volume

control

Microphone

button

Legend

Speaking

Miscellaneous

Listening

Voting

buttons

Chairman present

On:

Loudspeaker

Priority

button

DCN Next Generation | Quick Reference Card | DCN-DIS Discussion Unit (Chairman)

Bosch Security Systems | 2005-09 | 9922 141 70681 © Bosch Security Systems B.V. | Data subject to change without notice

Microphone

To enable the microphone:

Push the microphone button to enable the microphone

of your discussion unit. When the red light around the

microphone button comes on, you can speak.

To disable the microphone:

When the red light around the microphone button is on,

push the microphone button to disable the microphone.

The red light around the microphone button goes off.

Priority function

With the priority button, you can temporarily disable

the microphones of all delegates. At the same time, the

priority button enables your own microphone. The

system has the possibility to:

• Play a chime when you push the priority button.

• Erase the request-to-speak list and the speakers list

when you push the priority button.

When you release the priority button, the system

disables your microphone. When the speakers list is not

erased, the system enables the microphones of the

speakers again.

Voice mode

When your discussion unit is in the Voice mode, the

microphone is always enabled. Push and hold the

microphone button to temporarily disable the

microphone.

Channel selector

With the channel selector, you can select the channel

that is sent to the headphones. The channel selector is

automatically enabled when you connect headphones to

the discussion unit.

Voting

Standard procedure:

1 The chairman or operator starts a voting session.

When the voting session is started, the yellow light

adjacent to voting button 1flashes.

2 Make your vote. You can change your vote until the

chairman or operator stops the voting session.

Note

Some types of discussion units do not have a

channel selector. With these types of discussion

units, you cannot change the audio signal that is

sent to the headphones.

Note

Some types of discussion units do not have

voting buttons. With these types of discussion

units, you cannot make votes.
