BORGUSI CTM5104 Manuel utilisateur
BORGUSI
USER’S MANUAL
MOTORIZED TREADMILL
Model: CTM5104
Read all instructions carefully before using this
treadmill. Retain this user’s manual for the
future reference.
TABLE OF CONTENTS
SAFETY PRECAUTIONS ---------------------------------------------------------- 1
GROUNDING METHODS -------------------------------------------------------- 2
TECHNICAL PARAMETERS ------------------------------------------------------- 2
ASSEMBLY INSTRUCTIONS -------------------------------------------------- 3 - 6
FOLDING INSTRUCTIONS ------------------------------------------------------- 7
OPERATION GUIDE ------------------------------------------------------- 8 - 12
TREADMILL MAINTENANCE ----------------------------------------------- 13 - 14
TROUBLE SHOOTING GUIDE---------------------------------------------------- 15
EXERCISE INSTRUCTIONS-------------------------------------------------- 16 - 17
WARM UP INSTRUCTIONS ------------------------------------------------------ 18
EXPLODED PARTS DIAGRAM --------------------------------------------------- 19
PARTS LIST ---------------------------------------------------------------- 20 - 21
- 1 -
SAFETY PRECAUTIONS
Warning: We suggest that you should consult with your physician or health professional before
starting your workout, especially for the age up to 35 old or health problem-related people. We take
no responsibility for any injury or damage if you don’t follow our specifications. The treadmill should
be carefully assembled and covered with the motor shield, then connected to the power.
Attention:
1. Ensuring the safety key is attached to the clothing or belts before using the treadmill.
2. Please do not insert any items into any part of the treadmill, which would damage the treadmill.
3. Position the treadmill on a clean level surface. Do not place the treadmill on the thick carpet as it
may interfere with proper ventilation. Do not place the treadmill near water or outdoors.
4. Never start the treadmill while you are standing on the walking belt. After turning the power on
and adjusting the speed control, there may be a pause before the walking belt begins to move,
always stand on the foot rails on the sides of the frame until the belt moves.
5. Wear appropriate clothing when exercising on the treadmill. Do not wear long, loose clothing that
may be caught on the treadmill. Always wear running or aerobic shoes with rubber soles.
6. Keep the children and pets away from the treadmill while starting the workout.
7. Wait for about 40 minutes to exercise after eating.
8. The treadmill is suitable for adults, juveniles need to be accompanied by adults while exercising.
9. You must hold on to the handrails until you become comfortable and familiar with the treadmill
when first start the workout.
10. Treadmill is indoor-using equipment, not outdoor-using for avoiding damage. Keep the
store-place clean and flat, drying. Prohibiting other purposes of using, only for workout.
11. Please purchase the power-line from the distributor or contact us directly, for the power-line is
only equipped for the treadmill.
12. If the treadmill suddenly increases the speed due to an electronic failure or the speed is inadver-
tently increased, the treadmill will come to a sudden stop when the safety key is disengaged from
the console.
13. Do not connect the line to the middle of cable; do not lengthen the cable or change the cable
plug; do not put any heavy thing on the cable or put the cable near the heat source; forbid using the
socket with several holes, these may cause fire or people may be hurt by the power.
14. Cut off the power when the treadmill is not used. When the power is cut off, do not pull the power
line to keep the wire in good condition. Insert the plug to the socket with the safety ground circuit,
for the power-line is professional equipment. You must contact the professional people directly
while the line is damaged.
15. This treadmill only for home-using. Affordable max weight: 265 LB.
16. Safety area behind the treadmill: 1000*2000 MM.
- 2 -
TECHNICAL PARAMETERS
GROUNDING METHODS
BUILT UP
SIZE (MM)
FOLDABLE
SIZE (MM)
RUNNING SURFACE
SIZE (MM)
NET WEIGHT (LB)
1 LCD WINDOW
As the rating label
showing
As the rating label
showing
0.6-10
265
POWER
MAXIMUM OUTPUT
POWER
SPEED RANGE (MPH)
MAX AFFORDABLE
WEIGHT(LB)
Speed, Time, Distance, Calories, Incline, Pulse, Fat
1531*763*1289
965*763*1295
500*1200
126.5
This treadmill must be grounded. If it malfunctions or breakdown, grounding provides a path of
least resistance for electric current to reduce the risk of electric shock. This treadmill is equipped
with a cord having an equipment-grounding conductor and a grounding plug. The plug must be
plugged into an appropriate outlet that is properly installed and grounded in accordance with all
local codes and ordinances.
DANGER – Improper connection of the equipment-grounding conductor can result in a risk of elec-
tric shock. Check with a qualified electrician or serviceman if you are in doubt as to whether the
treadmill is properly grounded. Do not modify the plug provided with the treadmill – if it will not fit
the outlet, have a proper outlet installed by a qualified electrician. This treadmill is for use on a
nominal 100-120 volt circuit and has a grounding plug that looks like the plug illustrated in sketch
A in the following figure. Make that the treadmill is connected to an outlet having the same configu-
ration as the plug. No adapter should be used with this treadmill. (The below picture is just for refe-
rence, the actual plug and jack is depend on the importing country)
- 3 -
Assembly Parts Checklist：
When you open the carton, and you will find the below parts in the carton.
TOOLS:
5# Allen Wrench 5mm 1PC
6# Allen Wrench 5mm 1PC
Wrench with screwdriver S13-14-15 1PC
Notice: Do not get through power before complete assembly.
ASSEMBLY INSTRUCTIONS
1
11
70
62
10
88
55
No.
Main frame
6# Allen wrench
Bolt
Bolt
5# Allen wrench
Lock washer
Oil bottle
6 mm
M8*42
M8*16
5 mm
8
S13-14-15
ST4.2*19
Description Spec. Spec.
1
1
2
4
1
6
1
Qty.
32
27
28
12
49
74
No.
Safety key
Left base cover
Right base cover
Wrench with screwdriver
Power cord
Bolt
Description
1
1
1
1
1
4
Qty.
- 4 -
STEP 1:
STEP 2:
STEP 3:
Open the carton, take out the above
spare parts, put the Main frame (1) on the
level ground.
Hold on the computer frame and use the
5# Allen wrench (10), the Bolt (62) and
the Lock washer (88), fix the computer
frame onto the left and right upright.
Push up the computer and L&R upright
frame.
- 5 -
STEP 4:
STEP 5:
1. Use the 5# Allen wrench (10), the Bolt
(70) and the Lock washer (88) to pass
through the base and the right upright
frame, and lightly lock them on the base.
2. Use the 5# Allen wrench (10), the Bolt
(62) and the Lock washer (88) to lightly
lock the right upright frame on the base.
3. The left side is the same as the right
side, as in the left view.
Note: Keep your hands on the upright
frame during the locking process to avoid
injury from falling down.
1. Put the Right base cover (28) to the
Main frame (1), then use the Wrench with
screwdriver (12) and the Bolt (74) to lock
the Right base cover (28) onto the Main
frame (1).
2. Left side is the same as the right side.
- 6 -
STEP 6:
2. Plug the Power cord (49) into the
power cord socket of the Main frame (1).
(Unplug the power cord when the tread-
mill is not in use)
Note: After confirming that all installations are completed according to the above requirements, all
screws must be tightened uniformly, and the power can be turned on after checking that there are
no omissions. Please refer to the following related instructions carefully for the operation and the
use of the treadmill.
1. Put the Safety key (32) on the compu-
ter.
- 7 -
FOLDING INSTRUCTIONS
Pulling up:
Pulling down:
Pull up the base frame at position (A) till
hearing the sound that the air pressure
bar (B) is locked into the round tube.
Notice: Please unplug the safety insert
when folding.
Support place (A) with hand, kick the
place of the air pressure bar (B), then the
base frame will fall down automatically.
Notice: Please keep anybody and any pet
away from the treadmill when falling
down.
- 8 -
OPERATION GUIDE
2. LCD WINDOW DISPLAY DETAILS
PROG: Show programs, “---” is displayed in manual mode.
TIME: Show running time.
SPEED: Show speed. During the start-up process, a 3-second countdown is displayed: 3, 2, 1.
INCLINE/PULSE: Show incline/heartbeat data. When the INCL character is lit, the corresponding
window displays the incline; when the PULSE character is lit, the corresponding window displays
the heartbeat data.
CAL/DIST: Show calories/distance. When the CAL character is lit, the corresponding window
displays the calories; when the DIST character is lit, the corresponding window displays the
distance. Heat and mileage are displayed alternately every 5 seconds.
3. BUTTON FUNCTION
3.1. PROG button: Press this button to choose the program from manual mode “P1-P15”-“FAT”.
3.2. MODE button:
3.2.1. When the treadmill is in the standby state, press this button to choose the mode: manual
mode, time count down mode, distance count down mode, calories count down mode.
1. DISPLAY WINDOW
