Bontrager TRIP 2 Manuel utilisateur
ENGLISH
Trip™2, 2L, 3 and 5W
Owner’s Manual.
Thank you for buying a Bontrager Trip™
computer. We hope this computer gives
you miles (or kilometers) of pleasure.
Your Trip computer may not include all of the features discussed in this manual. This
manual covers Trip 2, 2L, 3 and 5W models.
Please read this manual carefully. If you do not understand the information, or you
have a question that this manual does not cover, consult your Authorized Bontrager
Dealer or visit www.bontrager.com.
WELCOME.
Safety When Riding
When riding your bicycle, do not stare at the computer for a long time (Figure 1).
Failure to pay attention to the road ahead of you, obstacles, and trafc could result
in a loss of control, serious injury, or death. Stay alert!
Make sure wires cannot contact the tire, rim, or spokes. Contact with wires could
damage the computer or cause you to lose control and fall.
Terms Used
Hold Press a button continuously for about two
seconds.
Push a button once, briey.
Set all values in the memory to 0 (zero) and erase
all settings.
Set Trip values (only) in the memory to 0 (zero).
Press several times to scroll through a list of values
or display elements.
Press
Reset
Trip Restart
Scroll
Figure 1. Do Not Stare at Computer for Long Periods of Time.
Display Elements and Abbreviations
The Trip can be used on two bicycles with different wheel sizes while still
calculating data correctly for each wheel size. You must rst set the wheel sizes
and choose the appropriate bike setting before riding.
Figure 2. Display Elements and Buttons.
Trip Data (can be reset to 0 without
affecting Odometer (ODO) total)
• Trip Distance (TRP)
• Average Speed (AVG) and Maximum Speed (MAX)
• Ride Time (TME)
Abbreviation
AVG
CLK
CUR
MAX
ODO
TME
TRP
CAD
Abbreviations and Screen Terms
Meaning
Average Speed
Clock
Current Speed
Maximum Speed
Odometer
Ride Time
Trip Distance
Cadence
SPEED
∙Current
TIME
∙Clock (CLK)
∙Ride Time (TME)
DISTANCE
∙Trip (TRP)
∙Odometer (ODO)
WHEEL SELECTION
∙Wheel 1 or Wheel 2
PACER
TEMPERATURE
CADENCE (CAD)
∙Trip 3 ONLY
BACKLIGHT
∙Trip 5W ONLY
SPEED
∙Average (AVG)
∙Maximum (MAX)
To Program Your Trip
This procedure programs your Trip cycle computer for the rst time or after a
Reset. If you would like to program individual features or advanced settings, see
the sections Additional Information & Features and Advanced Settings.
Install the battery (or push the Reset button—see Figure 12 at end of
manual).
The wheel size appears on the display.
To change the wheel size, press .
To select, press .
To scroll between units of measurement, Miles per Hour (MPH) or
Kilometers per Hour (KMH), press .
To select, press .
To change to ˚F or ˚C, press .
1.
2.
3.
4. 5. 6.
1. 2. 3.
4.
5.
6.
Easy Setup
After you install the battery, you can program the wheel size and units.
Install the Battery
To prolong the life of the battery, it is not installed at the factory. (See Figures 10
and 11 at the end of the manual for further help installing the battery.)
To select, press .
The Trip returns to CLK.
7.
Scroll to CLK.
Hold for 2 seconds.
To change to 12hr or 24hr clock, press .
1.
2.
3.
7. 8.
4. 5. 6.
To select, press .
To change the ashing digit for hours, press .
To select, press .
4.
5.
6.
To Set the Clock
7.
(for 2 seconds)
To change the ashing digit for minutes, press .
To select, press .
The Trip returns to CLK.
7.
8.
7. 8.
Additional Information
& Features
Automatic Sleep Mode
If the Trip’s sensors do not send a signal to the computer head for 10 minutes,
the Trip switches to Sleep Mode to prolong battery life (Figure 3).
To Remove the Computer from the
Computer Base
Press rmly on the computer (not on the base) in a rearward direction (Figure 4).
Figure 3. Display in Sleep Mode.
Figure 4. Removing the Computer from the Base.
(and)
Trip Restart resets the following Trip data to zero:
• Trip Distance (TRP)
• Speed AVG and MAX
• Ride Time (TME)
Trip Restart (Set the Trip Data to Zero)
To Restart
Hold and at the same time for two seconds (Figure 5).
The trip data restarts at ‘0’.
Figure 5. Restart the Trip Data.
(for 2 seconds)
Backlight (Trip 5W only)
The Trip 5W has a backlit display. The backlight provides a light source
behind the display so that the numbers are more visible. To save battery
life, the backlight automatically switches to Off after ve seconds.
To Switch the Backlight to On
While viewing any display hold for two seconds (Figure 6).
Figure 6. Switch the Backlight On.
(for 2 seconds)
Cadence is a measurement of how fast you are pedaling, counted as the
number of complete revolutions per minute (RPM) of the crankset.
Cadence (Trip 3 only)
To see Cadence 1.
Scroll to CAD.1.
