INSTRUCTION MANUAL

[RF EXPOSURE STATEMENT : OVVBS001 / Bonso Electronics Ltd.]

- CAUTION! -

IMPORTANT SAFETY INFORMATION

Your wireless hand-held portable transceiver contains a radio frequency

transmitter. When the PTT button is pushed, the transmitter sends out RF

signals. The device is authorized to operate at a transmit duty factor not

exceeding 50% using alkaline “AAA” size batteries to comply with Federal

Communications Commissions (FCC) RF exposure safety level guidelines for

hand-held wireless devices.

For body-worn operation, this device has been tested for SAR (Specific

Absorbtion Rate) and meets the FCC RF exposure guidelines when used with

the accessories supplied or designated for this device by the manufacturer.

Use of other accessories may not ensure compliance with FCC RF exposure

guidelines. Use the manufacturer-supplied antenna only. Unauthorized

antennas, modifications, or attachments could damage the transmitter and may

violate FCC regulations. To maintain compliance with the FCC’S RF exposure

guidelines, hold the transceiver at least 1 inch (2.5 centimeters) from your face

and speak in a normal voice, with the antenna pointed up and away.

GMRS License :

Use of GRMS radios within the United States requires a FCC GMRS license.

An individual of 18 years of age or older, who is not a representative of a foreign

government is eligible to apply for a GMRS system license. You will need two

forms from the FCC - FCC FORM 159 and FCC Form 605 Main Form and

Schedule F.

You can find the forms online at http://www.fcc.gov/formpage.html or call 1-800-

418-3676.

Document Number ENG_TEL_A001

Bonso Group

Rev # 00

Title : BS001 APPROVAL DOCUMENTS

Application : FCC APPROVAL Release Date : 03 Feb. 2005 Page 27 of 36

Owner’s Manual

For Model BS001 FRS/GMRS Radio

FEATURES

☞22 Channels

☞LCD Backlighting

☞Squelch Tail Clearance

☞Paging/Call

☞Scan

☞VOX

☞Roger Beep

☞Baby monitor

☞Monitor

☞Dual Watch

☞Priority Channel Appointment

☞Manner Mode

☞Low Battery Indicator

Use and Care

1. Do not use alcohol or cleaning solutions to clean the radio.

2. Do not immerse the radio in water.

3. Use a soft damp cloth to clean the radio

4. Dry the radio with dry lint-free cloth should it get wet.

5. Turn off the radio and remove the batteries during long-term storage.

Introduction

The BS-001 represents the state-of-the-art in high-tech engineering. Designed for Family Radio Service

operation, this compact package is big in performance. It is a quality piece of electronic equipment,

skillfully constructed with the finest components. The circuitry is all solid-state and mounted on a rugged

printed circuit board. The BS001 is designed for reliable and trouble-free performance.

Document Number ENG_TEL_A001

Bonso Group

Rev # 00

Title : BS001 APPROVAL DOCUMENTS

Application : FCC APPROVAL Release Date : 03 Feb. 2005 Page 28 of 36

Control Buttons & Indicators

LCD Display

Microphone

Speaker

Manner Indicator

Use to:

- Turn On/Off the Radio

- Enter/Exit the menu

Use to:

- Increase the volume

- Scroll through the menu

Use to:

- Decrease the volume

- Scroll through the menu

Use to:

- Backlight ON

- Monitor ON

Use to:

- Talk on the Radio

- Send a Call Tone

- Save a setting

Use to:

- Scan for active channels

- Lock the keypad

Low Battery Indicator

Key Pad Lock Icon

Transmit (TX) Icon

Receive (RX) Icon

Channel Indicator

Baby Monitor Icon

Manner mode Icon

Dual Watch Icon

Document Number ENG_TEL_A001

Bonso Group

Rev # 00

Title : BS001 APPROVAL DOCUMENTS

Application : FCC APPROVAL Release Date : 03 Feb. 2005 Page 29 of 36

Installing Batteries

The BS001 radio operates with either 4 AAA Alkaline Batteries or optional NiMH battery. The belt clip

should be removed to ease installation or removal. To install the batteries:

1. With the back of the radio facing you, remove the Battery Cover by sliding it down from the unit.

2. Insert 4 AAA batteries observing the polarity as shown, or install the optional battery. Installing the

batteries incorrectly will prevent the unit from operating or can damage the unit.

3. Return the Battery Cover by sliding it up from the unit.

Note: Batteries are not included.

Charging the batteries (Optional NiMH battery Only)

The BS001 is equipped to allow using a rechargeable NiMH battery, which can be recharged by a

Adaptor (not included). Batteries must be charged when the low battery icon flashes on the display.

Note :

1. Only use batteries indicated in the manual.

2. Do not attempt to charge Alkaline batteries or any battery pack other than the one indicated in the

manual. This may cause leakage and damage the unit.

3. For long term storage of the radio, turn the unit OFF and remove the batteries from the radio.

Operation

Power On/Off : 1. Press the button for more than 2 second to turn the radio on.

2. Press the button for over 2 seconds to turn the radio off.

Volume : 1. Press the button to increase the volume.

2. Press the button to decrease the volume during normal operation.

Talking and Listening : To communicate, all radios in your group must be set at the same channel.

1. For maximum clarity, hold the radio 2 to 3 inches from your mouth.

Document Number ENG_TEL_A001

Bonso Group

Rev # 00

Title : BS001 APPROVAL DOCUMENTS

Application : FCC APPROVAL Release Date : 03 Feb. 2005 Page 30 of 36

2. Press and hold PTT button and speak in a normal voice into the microphone. The TX icon

will appear continuously on the LCD Display when transmitting.

3. To receive messages, release the PTT button. The RX icon will appear on the display when

your radio is receiving a transmission.

Call Tone : The BS001 can transmit a call tone for a fixed length of time. To send a call tone, press the

PTT twice rapidly. The TX icon will appear during transmitting a call tone and tone can be

heard on the speaker for confirmation.

SCAN : The BS001 can scan all of the 22 channels to observe for any activity.

To enter the scan mode ;

1. Press the button for one second.

2. Press the button again to exit the scan mode.

Your radio will rapidly scan each of the 22 channels and stop on any active channel. When you press

the PTT button to transmit on an active channel, the scanning function will stop.

To resume scanning, press and hold the button for one second.

Keypad Lock : To avoid accidentally changing the radio operation ;

Press the button for 2 seconds. The icon will appear on the display. When the is on

the menu function the and button will be disabled. When locked, you will be able to

turn the radio off and on, monitor, transmit/receive, and send a call tone.

To unlock, press the for 2 seconds.

User Interface

To access the advanced features of the BS-001, your radio has the following menu functions:

Note : The unit will automatically go to normal mode after 10 seconds of no button activity

during menu setting.

Channel Selection : The BS001 has 22 channels available. To change channels:

1. Press the button until the current channel segment flashes in radio on.

2. Use the or buttons to change the channel.

3. Press the PTT button to save the new channel.

Mode Channel DW

On/Off

1~22

Document Number ENG_TEL_A001

Bonso Group

Rev # 00

Title : BS001 APPROVAL DOCUMENTS

Application : FCC APPROVAL Release Date : 03 Feb. 2005 Page 31 of 36

Roger Beep Tone : Whenever you release the PTT button, a “Roger Beep” tone may be transmitted to

let your friends know you are finished talking. To enable the Roger Beep ;

1. Press the button repeatedly until the “rb” appears on the display.

2. Press the and to set the Roger Beep tone on or off. An “on” or “oF” will

appear on the display during setting.

3. To exit the Menu, press PTT button.

VOX (Voice Operated Transmission) : The BS001 communicator is equipped with a user adjustable

Voice Operated Transmitter (VOX) that can be used for automatic voice transmission. In this

convenient mode, transmission is automatically initiated by speaking into the microphone. There is no

need to push the PTT button. To enable the VOX ;

1. Press the button repeatedly until the “VOX” appears on the display

2. Press the and buttons to set the VOX on or off. An “on” or “oF” will appear on

the display during setting.

3. To exit the Menu, press PTT button.

Dual Watch : The BS001 can select the main channel and assistant channel, then these two channels

can take turns the receipt. To select the DW mode ;

1. Press the button repeatedly until the “DW” appears on the display.

2. Press the and buttons to set the assistant channel.

3. Press the PTT button to save the assistant channel.

Manner Mode : In the silent place, if the call receipt is O.K, it can be sent out short beep and LED will

do blinking. To enable the Manner mode,

1. Press the button repeatedly until the “ ” appears on the display.

2. Press the and buttons to set the Manner mode on or off. An “on” or “oF” will

appear on the display during setting.

3. To exit the Menu, press PTT button.

Priority Channel Appointment : The BS001 can set the channel user want to use. To select the

Priority Channel Appointment function;

1. Press the button repeatedly until the “P” appears on the display.

2. Press the and buttons to set the priority channel.

3. Press the PTT button to save the priority channel.

Baby Monitor Mode : The BS-001 is able to monitoring the baby. To enable the Baby monitor ;

1. Press the button repeatedly until the “ ” appears on the display.

Document Number ENG_TEL_A001

Bonso Group

Rev # 00

Title : BS001 APPROVAL DOCUMENTS

Application : FCC APPROVAL Release Date : 03 Feb. 2005 Page 32 of 36

2. Press the and buttons to set the Baby monitor on or off. An “oF” , “1” or “2”

will appear on the display during setting. The “1” is master (TX /Baby side), “2” is slaver (RX).

3. To exit the Menu, press PTT button.

Monitor Mode : To enable the monitor mode, press the button for 2 seconds. To exit the this

mode , press PTT button or press the button for 2 seconds..

Backlight Display : The BS001’s LCD backlight display automatically lights up for 5 seconds with the

press the button.

Belt Clip :

To install the belt clip:

☞Slide the clip up into the slot on the back of the radio until the

latching mechanism clicks.

To remove the belt clip:

☞Pull the latching tab outward, then gently slide the belt clip

down toward the bottom of the radio.

TROUBLESHOOTING

Problems Solution

No Power - Check the battery installation and/or replace batteries

Cannot Receive

Messages

- Confirm the radios have the same channel settings.

- Make sure that you are with in range of the other transceivers.

- Buildings and other obstructions may interfere with your communication.

Radio is not responding

to button presses

- Make sure key lock is not on. See “Keypad Lock”. (Page 12)

- Radio might need to be reset. Turn power off then on.

Display is dim - Reposition or replace batteries.

Charger not functioning

- Contacts on the bottom of the radio may require cleaning.

- Ensure the outlet the charger is plugged into is functioning properly.

- Check that the batteries are installed in the radio properly.

Document Number ENG_TEL_A001

Bonso Group

Rev # 00

Title : BS001 APPROVAL DOCUMENTS

Application : FCC APPROVAL Release Date : 03 Feb. 2005 Page 33 of 36

Technical Specification

A. Specification

Channels : 22 Channels

Operating Frequency : UHF 462.5625 ~ 467.7125 MHz

Power Source : 4 AAAAlkaline or rechargeable Ni-MH Batteries

Output Power : Typically 0.5 Watts

B. Current Drain :

Receive : 145 mA max

Transmit : 400 mA max

Standby : Average 13 mA

C. Operating Time : Based on 900mAH (Alkaline battery) capacity

Talk Time : 2~2.5 hours

Receive Time : 12 hours

Standby Time : 69 hours

Combined (5-5-90 duty) Time : 23 hours

Channel Frequency Chart

CH. No CH. Freq. (MHz) CH. No CH. Freq. (MHz)

1 462.5625 12 467.6625

2 462.5875 13 467.6875

3 462.6125 14 467.7125

4 462.6375 15 462.5500

5 462.6625 16 462.5750

6 462.6875 17 462.6000

7 462.7125 18 462.6250

8 467.5625 19 462.6500

9 467.5875 20 462.6750

10 467.6125 21 462.7000

11 467.6375 22 462.7250

Note 1. Channels 1 thru 14 transmit on FRS frequencies.

2. Channels 15 thru 22 transmit on GMRS frequencies.

Document Number ENG_TEL_A001

Bonso Group

Rev # 00

Title : BS001 APPROVAL DOCUMENTS

Application : FCC APPROVAL Release Date : 03 Feb. 2005 Page 34 of 36

FCC NOTICE

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communication. However, there is no

guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to correct the interference by one or

more of the following measures :

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit difference from that to which the receiver is

connected.

- Consult the dealer of an experienced radio/TV technician for help.

NOTE : The manufacturer is not responsible for any radio or TV interference caused by unauthorized

modifications to this equipment. Such modifications could void the user's authority to operate the

equipment.

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.

OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS:

(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND

(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,

INCLUDING INTERFERENCE THAT MAY CAUSE UNDERSIRED OPERATION.

Table des matières

Autres manuels Bonso Radio

Bonso

Bonso BS004 Manuel utilisateur

Manuels Radio populaires d'autres marques

EisSound

EisSound KBSound iSelect Manuel utilisateur

Midland

Midland 1001LWX Manuel utilisateur

Konig

Konig HAV-SR41 Manuel utilisateur

Roberts

Roberts exprssion Manuel utilisateur

VDigi

VDigi DD3.0 Manuel utilisateur

Radio Shack

Radio Shack 21-1863 Manuel utilisateur

Roberts

Roberts Stream 207 Manuel utilisateur

Sony

Sony Walkman SRF-M97 Manuel utilisateur

Stanley

Stanley FatMax FMC770 Manuel utilisateur

auna

auna DAB-Radio 10026947 Manuel utilisateur

SOUNDMASTER

SOUNDMASTER UR190 Manuel utilisateur

HYT

HYT TC-320 Manuel utilisateur

auna multimedia

auna multimedia Yellowstone 10026851 Manuel utilisateur

B-Tech

B-Tech GMRS-V2 Manuel utilisateur

Weierwei

Weierwei VEV-V8 Manuel utilisateur

SOUNDMASTER

SOUNDMASTER DAB750 Manuel utilisateur

Telefunken

Telefunken TF-1505 Manuel utilisateur

Makita

Makita LXRM03 Manuel utilisateur
