Bongshin BS-7300XL Guide de démarrage rapide
1
7CBH9BHG
DF9:579""""""""""&
H97<B=75@ GD97=:=75H=CB " " )
8=A9BG=CBG"""""""""""""+
:FCBHD5B9@"""""""""""",
F95FD5B9@"""""""""""""" %%
=BGH5@@5H=CB"""""%)
75@=6F5H=CB AC89 5WhiU`
"%*
75@=6F5H=CB AC89 G]ai`Uh]cb
&-
G9H!IDAC89"""""""""""(%
CDH=CB"""""""""""""")$
9ffcfAYggU[Y
5bX HfciV`Y G\cch]b[ " " " **
2
DF9:579
%"=BHFC8I7H=CB
Thank you very much for your purchasing BONGSHIN Digital Weighing
Indicator of BS-7300XL.
This Instruction Manual will lead you to use BS-7300XL with top reliability,
High speed, high accuracy.
BS-7300XL is Digital Weighing Indicator amplifying the analog output from a
load Cell, converting the analog signal to digital data and then displaying
this data
As a weight reading and is designed for flawless performance in your
demanding
Application of input-weighing, output-weighing, accumulating-weighing,
2step control.
Also, an additional option will make Modern Industry demand equipment
that both versatile
And availed to easily connect to other devices
☞ REMARK
- Specification subject to change for improvement without prior notice.
- If changing, the Version No can be increased, but keeps a former
version
As far as possible
3
&"G5:HM7CB8=H=CBG
Please keep the following using conditions certainly
■
EARTH
To avoid an electric error such as a noises in your production line
It should be earthed before installation certainly.
Specially it will be safety to divide the power of Indicator into a load cell.
■
SAFTY CONDITIONS
Don’t use it closed to a explosive gas and an inflammable dust
environments
■
POWER
Use the power under 110/220V 50/60HZ ±10% and divide it into the
power line
■
TEMPERTURE CONDITIONS
Operating Temperature : -10o C ∼ +40o C ( +14o to 104
o F )
Custody Temperature : -40o C ∼ +80o C ( -40o to 176
o F )
■
INSTALLATION LOAD CELL
- Available to use the same load cell of 8pcs ( 350Ω standard )
- A ground should be installed horizontal
-Installing over 2pcs of load cell, please connect each line in parallel
and Insert a variable resistor under 50Ω in EX + line and minimize a
output
Accuracy of load cell.
It may occur a weight error by each accuracy of load cell.
-It may occur a weight error in case of a temperature variation of
load cell
-Please weld(elect spark) at the place installed with load cell and
equipments,
Divide the power into a connector of load cell in inevitable case
- Please connect the below construction of load cell with the above ones using
The earth to the weighing part weighing a material occurring a electro
sparks.
4
'":YUhifYg
-24bit sigma-delta A/D converter for high accuracy Easy
-Full digital calibration
-Simulative(mV/V memory) or live load calibration
-Peak hold and remote auto zero, tare
-High brightness LED display
-
A compact Appearance by DIN regulations ( DIN 193 x 96 Panel system )
-Easy to preset, change, confirm the weight value by the numeral key.
-Weight Memory function even in electro spark case.
-Watch-Dog timer guards for self-diagnostics.
-Set up to 1/20,000 display resolution
-Various specification of weight conversion speed.
(Digital Filter Function)
-Various option and addition for customer’s satisfaction such as serial
communication, RS-422, Analog output, Current LOOP, Printer, BCD
parallel output and so on.
5
H97<B=75@GD97=:=75H=CB
%"5bU`c[=bdih5#87cbjYfg]cb
@cUXWY``YlW]hUh]cb
Jc`hU[Y
DC 10V ±5%, 300㎃
up to 8 x 350ohm load cells
=bdihgYbg]h]j]hm 0.3 μV/D
GmghYa`]bYUf]hm Within 0.01% F.S.
NYfcUX^ighfUb[Y -1㎷ ~ 34㎷
=bdihJc`hU[Y Max. 34㎷ Min. 5㎷
5WWifUWm Zero drift : ±0.2 μV/℃ RTI max.
Span drift : 20ppm/℃ max.
=bdihBc]gY ±0.3 μV p.p or less
=bdih=adYXUbWY 10 ㏁ (Min.)
5#8WcbjYfhYf Sigma-Delta system
5#8]bhYfbU`fYgc`ih]cb Approximately 200,000 counts
5#8YlhYfbU`fYgc`ih]cb 1/20,000 (Max.)
5#8WcbjYfg]cbgdYYX 50 times/sec ~ 2 times/sec
AUl"fYgc`ih]cb 1/20,000
&"8][]hU`DUfh
8]gd`Um 7 Segment LED,
5-Digits, 38mm(Height)
8]gd`UmVY`cknYfc “-”minus signal
A]b"8]j]g]cb x1, x2, x5, x10, x20, x50, x100, x200
8YW]aU`Dc]bh 0, 0.0, 0.00, 0.000, 0.0000
6
'"HYW\b]WU`
57UXUdhYf AC 110/220V ±10%, 50/60Hz
DckYfWcbgiadh]cb 20 VA
8UhUAYacfm 10 year
CdYfUh]b[hYadYfUhifY
-10℃~+40℃ (+14℉ ~ +104℉ )
<ia]X]hm 85% Rh Max.
CjYfU``X]aYbg]cbg 193(W) x 162(D) x 96(H)
KY][\h 2.5 kg
("Cdh]cb
GH5B85F8 Serial Interface : RS-232C
Cdh]cb–% Serial Interface : RS-422, 485
Cdh]cb–& Serial Interface : Current Loop
Cdh]cb–' Analog Output : 0~10V
Cdh]cb–( Analog Output : 4~20mA
Cdh]cb–) Parallel Interface : BCD OUTPUT
7
8=A9BG=CBG
8
:fcbhDUbY`
%"8]gd`Um
Weight is Display.
&"?YmVcUfX
* The Key operating can be permitted or prohibited by dip switch.
* When pushing the key, it sounds "OK".
* Each Key works either a single function or compound functions.
A compound function key will be a command key when it push first
and According to the command key, the fixed value works its function,
The key to finish a input data is ENTER Key.
9
&!%"75@=6F5H=CB@C7?AcXY?Ym:ibWh]cbg
CALB mode : Simulative calibration or Number 1
LOCK mode : Number 1 or Analog output weight value
Set L1 range
CALB mode : Live calibration or Number 1
LOCK mode : Number 2
Set L2 range
CALB mode : ZERO or Number 3
LOCK mode : ZERO or Number 3
Set L3 range
CALB mode : Digital Filter Condition or Number 4
LOCK mode : TARE or Number 4
Set L4 range
CALB mode : Relay Mode Condition or Number 5
LOCK mode : HOLD Value Reset or Number 5
CALB mode : Minimum Grade Setting or Number 6
LOCK mode : NET/GROSS Conversion or Number 6
CALB mode : Motion Detect Condition Setting or Number 7
LOCK mode : Relay Range Setting or Number 7
