eKEY control buttons
Press the required button when changing the pitch of a
song. The buttons can vary the pitch in plus/minus six
steps with each button varying the pitch in chromatic
interval with respect to the standard pitch. The selected
pitch is indicated by the change in color of the pressed
button (when play of a song is over, the standard pitch
resumes automatically).
rMIC MASTER VOL control
Adjust the overall microphone input volume level.
tMIC VOL controls (1/A, 2/B, 3.MC)
1 / A: Adjust the input levels of MIC INPUT 1 and MIC
A (on the rear panel).
2 / B: Adjust the input levels of MIC INPUT 2 and MIC
B (on the rear panel).
3.MC: Adjust the input level of MIC INPUT 3.MC.
…In normal use, it is recommended to set the level to
maximum.
yMUSIC VOL control
Adjust the volume of the equipment connected to the
audio input terminals (This control does not change the
BGM volume. To change its volume level, use the BGM
VOL control).
uECHO VOL control
Adjust the entire echo and effect level of MIC INPUTs 1,
2, 3.MC and MICs A and B (rear).
iEFFECT: Effect Mode Indicator
Indicator for any effector is selected.
oV- CHG: Vocal Change Indicator
Indicator as vocal change is selected.
pECHO: Echo Indicator
Indicator as echo is selected.
aREVERB: Reverb Indicator
Indicator as reverb is selected.
sMUSIC Input peak indicator
Indicate Input peak level of MUSIC (Left and Right).
dMIC Input peak indicator
Indicate peak input level of MIC-1/2/A (Left), MIC-3/B
(Right) (Peak position: -3dB)
fLCD Display 1Function indicator
Center Position
2Peak level indicator (Input level)
9 Dots x 2 (L&R)
1Function indicator
Indicate each function or situation as bellow:
Input position, Effectors, Feedback reducer, Voice
Change (V-CHG), and Error massage.
2Peak level indicators
Indicate input level of left and right channel (9 dots/
CH and Center dot).
gSP 1-2 BALANCE
Adjust the balance of output level between SYSTEM1
and SYSTEM2. Please refer to page 12 for more
information.
1. Speakers from SYSTEM1 (BTL mode: L CH)
2. Speakers from SYSTEM2 (BTL mode: R CH)
hECHO SELECT switch
Press this switch to select preferable effectors, and the
selected efffectors will be indicated on LCD display.
Echo ∑REV ∑MIX ∑
jFEEDBACK REDUCER (ON/OFF)
Press this switch to reduce howling (feedback) by
searching howling point and filtering them.
CAUTION:
If feedback reducer could not work sufficiently, check the
MIC, speaker's position and sound level by moving or
changing the position/angle of speaker unit, not to affect
feedback to the MIC.
kV-CHG selector switch
Press this switch when selecting Voice Change
effectors. Indicate LCD of selected Voice Change
effectors.
NOTE:
For more information about i,o,p,a,s,d,h,jand
k, please refer to page 15.
