BlueCarve Spark Plasma CNC Set Up
I am slowly updating the set-up guide with new instructions. I am always making small improvements here and there
so please be patient as some items might seem odd. The basic concept is the same and if there is anything that does
not seem right, just get in touch with me.
Don’t forget to join the awesome BlueCarve Spark Plasma CNC Group on Facebook >>here<<
1. Safety
2. Standard Spark Plasma Set Up
3. SWS 50a Plasma
4. Maintenance
5. Motion Controller Set Up (check MyPlasm Set Up Guide)
1. Safety
Operation of any CNC is relatively safe, but you need to adhere to the following precautions
Safe Operating Procedures can be found here >>CNC Plasma<<
During operation of your BlueCarve CNC you must:
•Never leave your CNC unattended
•Wear appropriate safety glasses/ shields
•Keep body parts a clear distance from the CNC
•Allow free flowing air to the CNC controller
•Take care when handling material pre and post processing
•Anyone in the vicinity must wear suitable safety eyewear when the CNC is in operation
•Restrict access to the room where your CNC is operating
•Only connect power to the plasma power source once vertical torch is attached to the Z axis with the torch
facing vertically down
