Blitzz BWK800 Manuel utilisateur

11Mbps 802.11b Wireless AP with 4-Port Router + USB Adapter

Blitzz Connect! Quick and Easy!

Wireless Network Kit

user's manual

model:BWK800

Internet

Wireless Network Kit - User’s Manual

B5-MU-0009-00

Version:1.0, Jan. 2003

or by any means without written permission from Blitzz Technology Inc.

Changes are periodically made to the information in this document. They will

be incorporated in subsequent editions. The supplier may make improvements

and/or changes in the product described in this document at any time.

Wireless Network Kit - User’s Manual

Technical support

Up-to-date information

Your new purchased Blitzz product is updated with the latest technology and

design. However, we keep going to modify and update the product features to

keep you with up-to-date technologies with firmware or software upgrade. You

can visit our web site on http://www.iBlitzz.com to check if there is new

software for your product.

Problem solving

If you have difficulty resolving problemsin installation or have further technical

questions, you can go http://www.iBlitzz.com to look for the latest FAQ or

contact with us by following ways:

Web Site: www.iBlitzz.com

Tech Support: su[email protected]m

24/7 Toll Free: 1-888-iBlitzz (1-888-425-4899)

Sales: s[email protected]

iii

Wireless Network Kit - User’s Manual

Table of contents

CHAPTER 1 INTRODUCTION .............................................1

1.1 PRODUCT OVERVIEW.......................................................................1

1.2 FEATURES AND BENEFITS..................................................................1

1.3 WHAT’S IN THE PACKAGE? ................................................................3

1.4 IMPORTANT RULES FOR SAFE OPERATION................................................4

1.5 WLAN ROUTER - BWA611 .............................................................7

1.6 NOTEBOOK ADAPTER - BWP612......................................................11

1.7 USB ADAPTER - BWU613.............................................................12

CHAPTER 2 BUILD UP YOUR NETWORK – STEP BY STEP.13

2.1 START FROM A SIMPLE NETWORK.......................................................14

2.1.1. Install your network adapter.............................................14

2.1.2. Set up TCP/IP to auto configuration...................................28

2.1.3. Connect to the router ......................................................34

2.1.4. Establish local communication ..........................................39

2.1.5. Connect to the Internet ...................................................40

Appendix A Technical specifications 51

Appendix B Frequent asked questions 55

Appendix C Troubleshooting 58

Appendix D Driver only installation 60

Appendix F Government compliance notices 95

Wireless Network Kit - User’s Manual

Introduction 1

Wireless Network Kit - User’s Manual

Chapter 1 Introduction

1.1 Product overview

The Blitzz wireless network kit includes IEEE 802.11b compliant wireless

Router and network adapter. It offers the easiest way to share files, printers

and high-speed Internet connection.

1.2 Features and benefits

BWA611, BWP612 and BWU613

! Features 11Mbps data rate by incorporating Direct Sequence Spread

Spectrum technology.

! Fully IEEE 802.11b compatible. Allow inter-operation among multiple

vendors. Rate adaptive on 1, 2, 5.5 and 11 Mbps.

! Supports point-to-point and point-to-multipoint access.

! Supports Wired Equivalent Privacy (WEP) up to 128-bit data encryption.

! Wireless connection without the cost of cabling. Greater flexibility to locate

or move networked PCs. Easy to install and friendly to user, just plug and

play!

2 Introduction

Wireless Network Kit - User’s Manual

BWA611 WLAN Router with 4-port switch

! Broadband access sharing via Cable/DSL modem.

! Included 4-Port 10/100Mbps Fast Ethernet switch for fast local data

exchange.

! 10/100Mbps Auto-sensing Ethernet for easy installation. Plug and play!

! Dynamic Host Configuration Protocol client and server (DHCP).

! Point-to-Point Protocol over Ethernet (PPPoE).

! Support Virtual Private Network (VPN) by PPTP and IP-Sec pass thru

! High throughput routing performance.

! Static table routing

! Proxy DNS, Dynamic DNS (DDNS)

! Virtual server, DMZ host, and Multi-DMZ

! Rich packet filtering

! Web-based utility for local or remote management

! Firmware upgradeable for future function improvement

! Load/Save device settings for backup and easy configuration.

Introduction 3

Wireless Network Kit - User’s Manual

1.3 What’s in the package?

! BWA611 Wireless AP Router with

4-Port Switch

! Power adaptor

Ethernet USB

! Ethernet cable

(

USB cable comes

with USB adapter)

! USB adapter or Notebook

adapter

! Software CD, Quick Installation

Guide & User’s Manual

4 Introduction

Wireless Network Kit - User’s Manual

All packages have been checked carefully for their completeness and

functionality before shipped. Please contact the place of purchase if any of the

above listed items are missing or damaged.

If you encountered any difficulty in using this product while all the above

items are complete, please refer to Appendix C for Troubleshooting information

before making the decision to return your Wireless LAN AP Router to your

dealer.

1.4 Important rules for safe

operation

In addition to the careful attention devoted to quality standards on the

manufacture of NetWave products, safety is a major factor in the design of

every product. However, safety is your responsibility, too. This section lists

important information that will help assure your enjoyment and proper use of

the Router and accessory equipment. Please read them carefully before

operation and using NetWave products.

! Read and Follow Instructions - you should read all the safety and

operating instructions before operating the Router.

! Retain Instructions - You should save all the safety and operating

instructions, for your future reference.

! Heed Warning - Comply with all warnings on the products and in the

operating instructions.

! Check Power Sources - Operate this product only from the type of power

source indicated on the product’s marking label. If you are not sure of the

type of power supplied to your home, consult your dealer or local power

company.

! Be Careful of Overloading - Do not overload wall outlets or extension

cords, as this can result in a risk of fire or electric shock. Overloaded AC

outlets, extension cords, frayed power cords, damaged or cracked wire

insulation, and broken plugs are dangerous. They may result in a shock or

Introduction 5

Wireless Network Kit - User’s Manual

fire hazard. Periodically examine the cord, and if its appearance indicates

damage or deteriorated insulation, have it replaced by your service

technician.

! Protect Power Cords - Route power supply cords so that they are not

likely to be walked on or pinched by items placed upon or against them.

Pay particular attention to cords where they are attached to plugs and

convenience receptacles, and examine the point where they exit from the

product.

! Check Ventilation - Slots and openings in the enclosure are provided for

ventilation to ensure reliable operation of the product and to protect it from

overheating. Do not block or cover these openings. Never block these

openings by placing the product on a bed, sofa, rug, or other similar

surface. Never place this product near or over a radiator or heat register, or

any other heat source (including amplifiers). Do not place this product in a

built-in installation, such as a bookcase or equipment rack, unless you

provide proper ventilation.

! Do Not Use Accessories - Do not use attachments, unless they are

recommended by your vendor, as they may cause electrical or fire hazards.

! Use the Recommended Power Adaptor - You must use the Power

Adaptor that comes with your product.

! Do Not Use Near Water - Do not use this product near water. For

example, near a swimming pool, bathtub, washbowl, and the like.

! Do Not place Near High Temperature Source - For example near a

steamer, kitchen range fire, and the like.

! Use Caution in Mounting This Product - Do not place this product on an

unstable surface or support. The product may fall, causing serious injury to

a child or adult, as well as serious damage to the product.

! Use Care in Moving Product-and-Cart Combinations - Quick stops,

excessive, force and uneven surfaces may cause the product-and-cart

combination to overturn.

! Unplug Power Before Cleaning - Do not use liquid cleaner or aerosol

cleaner. Use a damp cloth for cleaning.
