Blaupunkt IClock 10 Manuel utilisateur

iClock 10

Uhrenradio mit iPod/iPhone Dock

iClock 10

SAFETY INFORMATION

INSTRUCTION

Thanks a lot for choosing our new generation of multi-functional mini music

station.

This mini music station is designed with multi function, perfect sound, high

liability and exquisite appearance, which brings you super happy when enjoy

your music with it.

Please refer to the belows to learn more about iClock 10：

IPHONE/IPOD play

Incoming call alert function

Time synchronization function between main unit and iPhone/iPod

AUX external input

FM radio（87.5-108MHz）

Clock

Alarm Clock

Sleep

Snooze

1. All the safety and operating instructions should be read before the

product is operated.

2. Retain Instructions - The safety and operating instructions should

be retained for future reference.

3. All warnings on the product and in the operating instructions should be

adhered to.

4. All operating and use instructions should be followed.

iClock 10

Important Notes

This safety and operating instruction should be retained for future reference.

The apparatus should not be exposed to dripping or splashing or placed in a

humid atmosphere such as a bathroom.

Do not install the product in the following areas:

Places exposed to direct sunlight or close to radiators

On top of other stereo equipment that radiate too much heat

Blocking ventilation or in a dusty area

Areas where there is constant vibration

Humid or moist places.

Do not place near candles or other naked flames

Operate the product only as instructed in this manual

Before turning on the power for the first time, make sure the power adaptor is

properly connected.

For safety reasons, do not remove any covers or attempt to gain access to the

inside of the product. Refer any servicing to qualified personnel.

Do not attempt to remove any screws, or open the casing of the unit; there

are no user serviceable parts inside, refer all servicing to qualified service

personnel.

CE Declaration of conformity

CE Hereby, Blaupunkt Competence Center Audio M3 Electronic GmbH,

declares that this product is in compliance with the essential reqirement and

other relevant provisions of Directive 1999/5/EC. You can consulted at

www.blaupunkt.com.

iClock 10

Safety instruction

1. READ INSTRUCTIONS – All the safety and operating instructions should

be read before appliance s operated.

2. RETAIN INSTRUCTIONS - The safety and operating instructions should

be retained for future reference.

3. HEED WARNINGS – All warnings on the appliance and in the operating

instructions should be adhered to.

4. FOLLOW INSTRUCTIONS – All operating instructions should be

followed.

5. WATER AND MOISTURE – The appliance should not be used near water,

for example, near a bathtub, washbowl, kitchen sink, laundry tub,

swimming pool or in web basement.

6. VENTILATION – The appliance should be situated so that its location or

position does not interfere with its proper ventilation. Do not place on

bed, sofa, rug or similar surface that may block the ventilation

openings, in a built-in installation, such as a bookcase or cabinet that

may impede the flow of air through the ventilation openings.

7. HEAT – The appliance should be situated away from heat sources such

as radiators, stoves, or other appliances (including amplifiers) that

produce heat.

8. POWER SOURCE – the appliance should be connected to power supply

only of the type described in the operating instructions or as marked on

the appliance.

9. POWER CORD PROTECTION – power supply cords should be routed so

that they are not likely to be walked on or pinched by items placed

upon or against them.

10. POWER LINES – an outdoor antenna should be located away from

power lines.

11. OBJECT AND LIQUID ENTRY – care should be taken so that objects do

not fall and liquids are not spilled into the enclosure through openings.

12. ESD WARNING – the display does not function properly or not reaction

to operation of any the control may due to the electrostatic discharge.

Switch off and unplug the set. Reconnect after a few seconds.

iClock 10

13. DAMAGE REQUIRING SERVICE – the appliance should be serviced by

qualified service personal when:

a. the power-supply cord or plug has been damaged.

b. Objects have fallen into, or liquid has been spilled into the

appliance enclosure.

c. The appliance has been exposed to rain.

d. The appliance has been dropped, or the enclosure damaged.

e. The appliance does not appear to operate normally.

14. SERVICING – the user should not attempt to service the appliance

beyond that described in the user operation instructions. All other

servicing should be referred to qualified service personnel.

15. DO ensure that all electrical connections (including the mains plug,

extension leads and inter- connections between the pieces of

equip ment) a re p ro per ly m ade and in a ccordan ce w ith the

manufacturer's instructions. Switch off and unplug the power before

making or changing connections.

16. Unplug this apparatus during lightning storms or when unused for long

periods of time.

17. Never unplug your radio by pulling on the power cord. Always grasp the

plug firmly and pull straight out from the outlet.

18. DON'T remove any fixed cover as this may expose dangerous voltages.

19. DON'T place hot objects or naked flame sources such as lighted candles

or nightlights on, or close to equipment. High temperatures can melt

plastic and lead to fires.

20. DON'T leave equipment switched on when it is unattended unless it is

specifically stated that it is designed for unattended operation. Switch

off using the switch on the equipment and make sure that your family

knows how to do this. Special arrangements may need to be made for

infirm or handicapped people.

21. DON'T continue to operate the equipment if you are in any doubt about

if it's working normally or if it's damaged in any way. Switch it off,

unplug the mains power and consult your dealer.

22. REPAIR OR REPLACE all electric service cords that have become frayed

or otherwise damaged immediately. Do not use a cord that shows

cracks or abrasion damage along its length, the plug, or the connector

end.

iClock 10

CATALOGUE

Interface Information ...............................................................................2

General Operation.....................................................................................3

Play Music...................................................................................................4

Radio Operation ........................................................................................5

Setting.........................................................................................................5

Specifications.............................................................................................7

Packing content:

1 main unit 1 user manul

1 quick start guide 2 warranty card

1 power adaptor

iClock 10

INTERFACE INFORMATION

Back view

1 FM ANT: FM antenna

2 DC 5V: DC input slot

3 AUX: External music source input ( 3.5mm jack)

iClock 10

Front view

1 : Power On/Off

2 FUN: Function mode switch

3 /T+: Search +/ Next/Forward

4 VOL+: Volume up

5 VOL-/AL MODE: Volume down /Alarm mode

6 /T-: Search-/Last/Backward

7 /MEM/SET: Play and pause/Memory/Clock setting

8 SNOOZE/SLEEP/dimmer: Alarm snooze/Sleep selecting/LCD brightness

adjustment

Power On

1. After plugging DC5V AC adapter into DC power input jack at the back of the

unit, then the display screen lightens, clock appears on the screen, then click

press “ ” to power on.

2. Volume: VOL- and VOL+ can be adjusted within 00-20.

Play music

IPHONE: The music station will enter to ”IPHONE” function directly when

power on. Dock IPHONE/IPOD on the iPhone/iPod dock, and play the music

from IPHONE/IPOD. (IPOD/IPHONE can be changed when the main unit

connects to power)

Pause: Under “IPHONE/IPOD” mode, press “ ”for pause. (Note: there is no

“ ”on the IP19 LCD when “IPHONE/IPOD”is played or paused, but on the

IPHONE/IPOD itself ).

Music selection: Press “ /T- / /T+”for music selection when

“IPHONE/IPOD”is played or paused.

Rewind/Forward：Pre s s " /T- / /T+”and hold it for rewind or

forward when “IPHONE/IPOD”is played or paused.

IPHONE Incoming call alert: If IPHONE plays music, a call is incoming, the

unit will auto switch, stop playing music and switching into call music, when

auto hang up, it will return to music playing.

Time synchronization function between the main unit and iPhone/iPod:

Under the state of power-on or power-off, plug iPhone/iPod, the main unit

can synchronize the current time on iPhone/iPod.

LINE operation: Select AUX under power on,and input the external music

source to AUX,turn on volume and the music is ready.

iClock 10

GENERAL OPERATION

iClock 10

Radio operation

Manual Tuner or Auto matic Tuner：Press

/T- / / T+” for manual tuner, while

press “ /T- / /T+”and hold it for two seconds when enter to automatic tuner.

The tuner will st op automat ically when get access to channels.

Manual channel memory：when get acess t o t he channels by manua l, press

“ /MEM/SET”and hold for a while. Press “ /T- / /T+ ” to choose the saving

location. 20 channles can be memorized and sav ed.

Memory selection：Press “ /MEM/SET”to alter nate the memor y channel.

Timing setting

1. Hold and press “ /MEM/SET”key around 2 seconds, “24H” charac ters are flashing

on LCD screen, enter into 12/24H system option, t hen c lick press “ /T- /

/T+”k ey to select ”12/24” system, finally click press “ /MEM/SET” key to

confirm, which enters into time setting.

2. Ent er into the time setting mode, set the hour first, click press “ /T- /

/T+”k ey to select preset hour, finally click press “ /MEM/SET”k ey to confir m,

then use the same methods to set the minutes.

Alarm clock setting

When it’s in STAND By stat us, hold and press“VOL-/AL MODE”key to enter into setting,

then display clock, “Hour” digits are flashing on LCD, and clic k pr ess “ /T- / /T+”

key to adjust t he hour, click press “VOL-/AL MODE” key to confirm, then “Minute” digits

ar e flashing on LC D, and clic k press“ /T- / /T+” key to adjust the minutes, click

press “VOL-/A L MODE” key to confirm t he setting and return to clock status.
