BlackVue DR380-HD Manuel utilisateur

www.blackvue.com

User's Manual

DR380-HD / DR380G-HD / DR400G-HD / DR400G-HD II

BlackVue_Eng_0726.indd 1 2012-07-26 �� 4:00:45

BlackVue_Eng_0726.indd 2 2012-07-26 �� 4:00:45

Table of Contents

Preparations 2 Before Reading the User's Manual

3 Safety Instructions

5 Product Features

6 What's included

7 BlackVue At a Glance

BlackVue Usage 8 Installation

12 Recording

14 Playing Recorded Videos

BlackVue Software 17 Running BlackVue Software

18 Screen At a Glance

19 Playing Recorded Files

23 Saving as an Image File / Printing

24 Conﬁguring BlackVue Settings

Others 34 Installing the BlackVue Software

35 Upgrading the Firmware

36 Product Speciﬁcations

BlackVue_Eng_0726.indd 1 2012-07-26 �� 4:00:45

Preparations Before Reading the User's Manual

Thank you for purchasing Pittasoft's BlackVue. This product is a video event

data recorder (VEDR) for vehicles.

Please read the User's Manual carefully before using the BlackVue.

Pittasoft is planning to supplement its product and add new features via

ﬁrmware on a constant basis. All information and speciﬁcations in this manual

are subject to change without a prior notice.

Screens and pictures of the User's Manual may be different from the actual object.

Descriptions of Symbols Used in the Manual

Symbol Name Description

Caution Cases where the device fails to work properly or its settings are

disabled.

Tip Additional notes that are helpful in working the device

Warranty and Disclaimer

We shall take no responsibility for accidental damage, injuries and other losses

caused by improper use of the product.

This product is a video event data recorder for vehicles but does not guarantee

that all accidents will be recorded. This device may fail to record a minor

accident caused by too light an impact to trigger the impact sensor.

This product creates a record of video to help determine what happened before,

during and after the crash or event.

Pittasoft Co. shall not take any responsibility for damages (property, business

and/or indirect damages).

BlackVue_Eng_0726.indd 2 2012-07-26 �� 4:00:45

Preparations Safety Instructions

This manual is about what should be done to protect the user's safety and

prevent property damage.

Please make sure to read it thoroughly before using the product.

Do not disassemble, repair and/or alter the product.

This may cause a ﬁre, an electric shock and/or malfunction. Contact the service

center if you need to have the product ﬁxed. User may not be entitled to free

service if and when product malfunction is caused by user's fault.

Do not spray water on each parts of the product when cleaning it. Make

sure not to wet the product.

This may cause a ﬁre, an electric shock and/or malfunction.

Do not spray a cleansing agent on the surface of the product.

This may cause discoloration and/or cracks on the surface and result in

malfunction.

Do not give the product a shock, and make sure foreign matter does not

enter the product.

This may result in malfunction.

Do not operate the product while driving.

This may cause a trafﬁc accident because it distracts you from keeping your

eyes on the road. Use after stopping/parking your car in a safe place.

Do not install the product in a location where it may interrupt a safe driving

or block your view while driving.

This may cause a trafﬁc accident.

Excessively dark tinting on the windshield may make recorded images look

blurry or distorted.

The optimum temperature for picture quality ranges from 0 to 50 °C. The

picture quality may vary according to seasons, especially in midsummer or

winter season.

This product is fitted with a camera. Drastic changes in brightness (on

entry/exit of tunnels), strong backlight in the daytime, and no light source at

midnight may result in defective recorded images.

If power supply to the device is interrupted by a crash or accident, it may

cause video not to be recorded.

BlackVue_Eng_0726.indd 3 2012-07-26 �� 4:00:45

Cautions for GPS Usage GPS models Only

Poor GPS reception will not affect video recording.

It will only lead to a failure to record a vehicle's coordinates and speed.

Please maintain the optimum temperature, which ranges 0 to 50 ºC from for

proper working of GPS. GPS reception may get unstable or its connection time

may be delayed in the midsummer or wintertime.

When you use the product for the first time or you have not used it for an

extended period of time (over 3 days), it may take some time for GPS to identify

the current location. (at least 1 to 5 minutes)

Install the product avoiding the following instances where GPS reception is

interrupted, and check the GPS reception.

yAn instance where an object in put on top of GPS

yAn instance where the windshield is tinted with metallic substances

yAn instance where devices producing RF radiation interrupting GPS signals are installed

in a car (certain models of remote car alarms and MP3/CD players)

yAn instance where another device using GPS is used

yAn instance where it is dark and overcast

yAn instance where GPS is used under an overpass; in a tunnel, underpass, underground

parking lot, and an area concentrated with large buildings; and near a power station,

barracks, and broadcast relay station

Cautions for BlackVue Installation

Installing or operating the device while driving may cause an accident. Please

install or operate the device after stopping/parking your car in a safe place.

If the cigarette lighter receptacle emits fumes or a funny smell, stop using the

product immediately and contact us or our dealerships.

Dust and built-up dirt on the cigarette lighter receptacle may cause heat or a ﬁre.

Clean it on a regular basis.

Check frequently if the product is installed properly. Due to vibration, the BlackVue

comes off, resulting in an injury or damage.

We do not take any responsibility for malfunction, an injury or damage to the

product caused by inappropriate use.

Preparations Safety Instructions

BlackVue_Eng_0726.indd 4 2012-07-26 �� 4:00:45

Preparations Product Features

High-deﬁnition Video

The BlackVue uses high quality mega-pixel lenses, which produce clear and sharp

images even at night.

Smartphone/PC Viewer

The product comes with a PC viewer and applications for smartphones (running on

Android). You can check images easily and customize various settings.

Normal Recording

The product makes a high-deﬁnition video recording of all the events while driving.

Parking Mode Recording

The product automatically shifts to the parking mode. If there is no movement of

a vehicle for a certain period of time, the device automatically shifts to the parking

mode; and if the movement of a vehicle continues, the parking mode becomes

automatically deactivated. In the parking mode, only if the camera detects motion

or an impact occurs, recording gets started. (The product is equipped with motion

detection technology developed by Pittasoft, which specializes in IP cameras.)

Event (G-sensor) Recording

If the vehicle is given an impact, the G-sensor built in the BlackVue detects the

impact and starts recording the event.

Sound Recording

The microphone built in the BlackVue records surrounding sounds while recording

video.

Check Images on Various Devices

You can check recorded images on a variety of devices that can play MP4 ﬁles.

Reﬁned and Easy-to-Use Design

The BlackVue with its sleek and cylindrical design makes the vehicle's interior look

even better.

In addition, you can easily adjust the camera angle so that it can record the inside

of the car.

Voice Guide

The voice guide provides information about the current status of the BlackVue.

GPS Driving Record GPS models only (DR380G-HD, DR400G-HD, DR400G-HD II )

The built-in high-sensitivity GPS creates a record of the speed and location of the

vehicle at the time of recording. You can check the driving records via BlackVue

software. (when connected to the Internet)

BlackVue_Eng_0726.indd 5 2012-07-26 �� 4:00:46

Preparations What's included

Check the product and the accompanied accessories contained in the product

package.

Please contact your dealership if there is a problem with the components.

*Components provided and optional items may vary depending on a model.

Components provided and optional items are subject to change without a prior

notice.

BlackVue User Manual

Video OUT Cable* Video IN Cable* Power Cable

Cable Clips Double-sided Tape

(spare item for mounting the

BlackVue on the windscreen)

Micro SD Card

(including BlackVue software)

Micro SD Card Reader*

BlackVue_Eng_0726.indd 6 2012-07-26 �� 4:00:46

Preparations BlackVue At a Glance

Check the main body of the BlackVue.

For more information on the use of each part, refer to the relevant page.

Recording Mode LED

Microphone

Main Body Button (Parking

Mode Recording Button)

(X See page 12)

[DC IN] terminal (X See page 9)

Micro SD Card Slot

[VIDEO OUT] terminal

(X See page 11)

Holder

GPS Reception LED

GPS models only

Holder lock button

(X See page 11)

Camera Lens

BlackVue_Eng_0726.indd 7 2012-07-26 �� 4:00:47

BlackVue Usage Installation

Insert the Micro SD Card into the BlackVue

1. Insert the Micro SD card into the

Micro SD slot in the same direction

as shown in the picture.

Press the card again to remove

it. While doing this, be careful so

that the Micro SD card won't pop

out.

Tu rn of f the Black Vue before

inserting the card into it.

Cautions for Using the Micro SD Card

yInsert/remove the Micro SD card with the BlackVue off.

(Check to see if all the LEDs on the BlackVue are off.)

yDo not remove the Micro SD card while saving data on the card or reading data from

it. This may cause data loss and product malfunction.

yCheck the data stored on the Micro SD card to see if the product is working properly.

yWe recommend you use the genuine memory cards provided by Pittasoft. We do not

take any responsibility for problems caused by the use of other memory cards.

yThe Micro SD card is consumable. Replace it with a new one after a longtime use.

yMake sure to store important data on another storage medium. We do not take any

responsibility for data loss caused by user's fault.

BlackVue_Eng_0726.indd 8 2012-07-26 �� 4:00:47
