OWNERS MANUAL
REMOTE START SECURITY SYSTEM
Standard Features
The System has the following standard features:
• 5-button remote transmitter
• Status indicator (LED)
• Valet/Service mode switch
• Remote Start capabilities
• Extended Range Receiver
• Multi-tone siren (126dB)
• Dual stage impact detector
• Remote panic
• Valet mode
• Remote chirp delete
• Remote sensor bypass
• Passive or active arming
• Stop & Go Feature
• Auto Cold Start
• Flashing parking lights
• Auto Rearm
• Passive/Active Arming
Optional Features
This System has many optional features that may
require additional parts and/or labor. Please contact
your dealer for more details.
•Remote keyless entry (Door lock/unlock)
•Illuminated entry
•LCD FM 2-way Remote
•Hood & trunk protection
•Horn honk
•Trunk/hatch release
•Window roll-up
•Back up battery
•Additional sensors: glass breakage/microwave
Note: Some features may not be appropriate for
certain vehicles. Automatic transmission and
electronic fuel injection are required. on vehicles for
use with this system.
REMOTE TRANSMITTER FUNCTIONS
Button I Arms the system and locks the
doors*. Button I also activates the Panic
feature.
Button 2 Disarms the system and unlocks the
doors*.
Button 3 Activates the optional Trunk Release
feature*.
Button 4 Activates the Remote Start Feature.
Button 5 Auxiliary Shift Key.
Buttons 5 then 4 Activates the 2nd auxiliary
function.
* Optional Feature
1
Button 1
5-Button
Transmitter
Button 3
Button 2
Button 5
Button 4
Security System Operation
ARMING OPERATION
To arm the system press transmitter button 1:
•The siren will chirp once. -
•The parking lights will flash once.
•The doors will lock*.
•The L.E.D. will turn solid for 10 seconds
then start flashing slowly, the system - is
now armed.
While the system is armed the alarm will
trigger if
•A door is opened.
•The hood/trunk is opened*.
•The shock sensor detects an impact to the
vehicle.
When the alarm is triggered the siren will sound, the
parking lights will flash, and the horn will honk*. If the
alarm is triggered while the remote start is engaged,
the remote start will immediately shut down.
PASSIVE ARMING
The passive arming feature allows the system to
arm automatically without user intervention.
This programmable feature may be enabled during
installation.
To arm the system passively:
1.Turn the ignition key off.‡
2.Exit the vehicle and close all doors.
•The LED will start flashing rapidly to indicate
that the system is preparing to arm. (The
system can be armed at any time by pressing
transmitter button 1.)
•The siren will chirp 30 seconds after
the last door is closed to indicate the
system is now armed.
•The doors will lock.†*
‡The ignition must have been on for at least 10 seconds prior to
exiting the vehicle or Passive Arming will be bypassed.
†If the Passive Locking feature was enabled during installation.
DISARMING OPERATION
To disarm the system press transmitter button 2.
•The siren will chirp twice.¥
•The parking lights will flash twice.¥
•The doors will unlock.†*
•The dome light will turn. on for 30
seconds.*
¥If the alarm was triggered while away, the system will respond
with 3 chirps and 3 parking light flashes.
†If the Passenger Unlock Feature is enabled, pressing the unlock
button will unlock only the driver’s door. Pressing the unlock
button again unlocks all doors.
TAMPER ALERT
If the alarm was triggered while away from the vehicle, the
siren will chirp 3 times on disarming for tamper indication.
After disarming the alarm, enter vehicle and turn ignition
on. The LED will flash the zone that was triggered 5
times (see LED chart).
AUTO REARM
The Auto Rearm feature allows the system to
automatically re-arm itself in the event the
system is disarmed and ignition is not turned on
within 30 seconds.
NOTE: This programmable feature may be disabled
during installation. The Passive Arming feature and Auto
Rearm feature are related In order to disable the Auto
Rearm feature, the Passive Arming feature must also be
disabled during installation. This feature will not work on
vehicles with the illuminated entry feature enabled
SILENT ARMING/DISARMING
Press transmitter button 5 (the Shift Button)
then the Arm or Disarm button for one-time
silent operation.
* Optional Feature
2
CHIRP DELETE
For full time silent operation, the ARM/ DISARM
chirps can be permanently disabled.This feature must
be programmed during installation.
IGNITION LOCK*
The ignition locking feature allows the doors to
automatically lock when the ignition key is turned on,
and automatically unlock when the ignition key is
turned off. This feature may be disabled during
installation.
REMOTE PANIC
In the event of an emergency (PANIC) situation, the
system’s siren can be triggered for 45 seconds to
attract attention.To activate the Panic Feature, press
transmitter button I for 3 seconds:
•The siren will chirp once.
•To exit Valet Mode:
•The siren will sound.
•The parking lights will flash.
Press button I to exit panic mode and rearm
the system. Press button 2 to exit panic mode
and disarm the system.The Panic Feature will
operate when the ignition is on.
EMERGENCY OVERRIDE
If the ‘transmitter becomes lost or fails to
operate, the system can be disarmed by using
the emergency override feature.
To override the system:
1. Enter the vehicle.
Because the system is armed, the siren
will sound.
2.Turn on the ignition key.
3. Press the Valet switch for 5 seconds.
The siren will stop sounding.
Starter defeat bypassed.
VALET MODE
When the system is placed into the Valet Mode
the security system will be disabled. However, the
optional keyless entry and trunk release and
remote start features will still function if
installed.
NOTE: Remote Start feature maybe disabled
during valet mode if programmed during
installation.
To enter the Valet Mode:
I . Be sure the system is disarmed.
2.Turn the ignition key on.
3.Press and hold the valet/service mode
switch for 3 seconds.
•The LED will chirp once.
•The LED will turn on solid indicating
the system is in Valet Mode.
To exit the Valet Mode:
1. Turn the ignition key on.
2. Press and hold the valet/service mode
switch for 3 seconds.
•The LED will turn off.
•The Siren will chirp 2 times.
OPTIONAL TRUNK RELEASE
Press button 3 for approximately 2 seconds to open
the trunk.
OPTIONAL TRUNK DISARM
The trunk disarm feature allows the alarm to
disarm automatically whenever transmitter
button 3 is used to activate the optional trunk
release.This eliminates having to first disarm
the alarm before activating the trunk release.
NOTE: This feature must be programmed during
installation.
REMOTE SENSOR BYPASS
To arm the system and bypass the shock sensor, press
button I to arm, then within 2 seconds press button I
again.The siren will chirp 5 times and sensors will be
ignored until the
* Optional Feature
3
system is disarmed and rearmed.
OPTIONAL SECURE
OVERRIDE CODE
If your system was programmed to override with a
personal override code-pressing the override switch
from I to 15 times.
To disarm the system with your personal override
code please use the following steps:
1. Open Door Alarm system will trigger
2.Turn ignition key to on
3. Press the override switch to the selected number
of times and hold on the last one for 5 seconds until
the alarm turns off.
Remote Start Operation
Important: Only start the vehicle in a well
ventilated area. Do not use in a closed garage or
indoors. Be sure to familiarize yourself with all
features prior to using this product.
REMOTE STARTING THE VEHICLE
To remote start the vehicle:
Press transmitter button 4 for 3 seconds.
•The parking lights turn on.
•Approximately 2 seconds later the system will
attempt to start the vehicle.
•Once the car has started, the heater or air
conditioner will turn on and run for the
pre-programmed time (15 or 25 minutes). If the
engine fails to start on the first attempt, it will
repeat the starting procedure 2 more times.If the
vehicle fails to start after a total of 3 times the
system will shut down.
Driving vehicle after Remote Starting:
Unlock the door by pressing button 2* on
the remote transmitter. Enter vehicle, turn ignition
key to the on position (Note: Do not turn the key all
the way to the start position as you may damage the
starter).
Once the ignition key is turned to the on position,
press the brake pedal and shift the car into the
proper gear and you may now drive the vehicle
(Note: If broke pedal is pressed prior to turning on
ignition, engine will turn off).
REMOTE ENGINE SHUTDOWN
If the vehicle has been remotely started and you
desire to turn the vehicle off, simply press and hold
button 4 on the remote transmitter for three
seconds. After the motor has turned off the doors
will relock*.This feature must be programmed during
installation.
AUTO COLD START
This feature allows the system to start and run the
vehicle every one or two hours (selectable by your
installer) for a period of 24 hours.This allows the
engine to remain at an operational temperature in
extremely cold weather. Auto Cold Start must be
enabled during installation or it cannot be engaged.
Engaging the Auto Cold Stan feature:
To turn Auto Cold Start on:
1. Press and hold the brake pedal.
2. While holding the brake pedal down, push the
Valet switch and transmitter button 2 for two
seconds.
•The parking lights will flash four times to
indicate the Cold Start feature is engaged.
3. Release the brake pedal.
* Optional Feature
4
Disengaging the Auto Cold Start feature:
The Auto Cold Start feature can be
deactivated in one of three ways:
•Press the brake pedal.
•Turn on the ignition.
•Remote start the vehicle using the
transmitter.
STOP AND GO
The Stop and Go feature allows the vehicle to remain
running without use of the ignition key during short
stops.
To activate the Stop and Go feature:
1. With engine running push transmitter
button 4 (on FM 2-way press button 2.). - The
parking lights will turn on.
2. Remove the key from the ignition.
3. Exit the vehicle and lock the doors manually or
using transmitter button 1*.
To resume driver control:
1. Unlock the doors manually or by pressing
transmitter button 2*.
2. Turn on the ignition.
•The vehicle resumes driver control,
SAFETY FEATURES
The System will not start the vehicle if the brake
pedal is pressed or the hood is open.Also, if the brake
is pressed or the hood is opened while- remote
running, the remote start will shut down.
REPLACING LOST OR STOLEN
REMOTE TRANSMITTERS
This System can “learn”a maximum of 4 remote
transmitters.To add a transmitter or replace
lost/stolen transmitters, please consult with an
authorized Black Widow Dealer.
* Optional Feature
5
6
© 2003, DAVID LEVY COMPANY, INC. 65-6150/7150, 1/03 Rev. 1
SYSTEM REFERENCE INDICATORS
STATUS INDICATOR (LED) FUNCTIONS
On Solid =Valet Mode
Slow Flash System Armed
Rapid Flash Passive Arming
TAMPER ALERT LED FUNCTIONS
I flash ‘= sensor #22 flashes = shock sensor
4 flashes = door
5 flashes = hood or trunk
flash-flash-pause-flash-flash-pause = shock sensor
PARKING LIGHTS FUNCTIONS
On Solid =Vehicle Remote Starting
Flash I x =System armed
Flash 2x = System disarmed
Flash 3x =Tamper indication (after disarming)
Flash 4x = Defective zone warning
(after arming)
Table des matières
Autres manuels Black Widow Alarme de voiture
Black Widow
Black Widow 1 Channel Manuel utilisateur
Black Widow
Black Widow BW-800 SMART SYSTEM Guide de démarrage rapide
Black Widow
Black Widow BW 2800 Manuel utilisateur
Black Widow
Black Widow BW 3150 Manuel utilisateur
Black Widow
Black Widow BW1700 Manuel utilisateur
Black Widow
Black Widow BW 4100 Manuel utilisateur
Black Widow
Black Widow BW1700 Manuel utilisateur
Black Widow
Black Widow BW-2000 CLASSIC Manuel utilisateur
Black Widow
Black Widow BW-2500 PREMIER Manuel utilisateur
Black Widow
Black Widow BW-2500 PREMIER PLUS Manuel utilisateur
Black Widow
Black Widow BW 4150 Manuel utilisateur
Black Widow
Black Widow BW 3650 Manuel utilisateur
Black Widow
Black Widow 5-BUTTON SERIES Manuel utilisateur
Black Widow
Black Widow 1R / 2-BUTTON SERIES Manuel utilisateur
Black Widow
Black Widow BW 2850 Manuel utilisateur
Black Widow
Black Widow BW-1150 EXPLORER PLUS Manuel utilisateur
Black Widow
Black Widow BW 550 Manuel utilisateur
Black Widow
Black Widow BW-1400 CHALLENGER Manuel utilisateur
Black Widow
Black Widow BWS 1000 Series Manuel utilisateur
Black Widow
Black Widow BW-1500 CHALLENGER PLUS Manuel utilisateur
Manuels Alarme de voiture populaires d'autres marques
Federal Signal Corporation
Federal Signal Corporation Pathfinder Siren Series Manuel
Falcon
Falcon Predator XL3 Guide de l'utilisateur
Audiovox
Audiovox Auto Security XR91 Mode d'emploi
Clifford
Clifford Sabre II Manuel utilisateur
CrimeStopper
CrimeStopper CS-8717 Guide de démarrage rapide
Ultra Start
Ultra Start 450 SERIES Manuel utilisateur
