BLACK DECKER DVJ325BFSP Manuel utilisateur

www.blackanddecker.co.uk

DVJ325BFSP

10 3

10a

H I

10c

10d

10b

E F

Intended use

Your BLACK+DECKER DVJ325BFSP Dustbuster®hand-held

vacuum cleanerr has been designed for vacuum cleaning pur-

poses. These appliances are intended for household use only.

Read all of this manual carefully

before operating the appliance.

Safety instructions

@Warning! Read all safety

warnings and all instructions.

Failure to follow the warnings

and instructions listed below may

result in electric shock, re and/or

serious injury.

uThe intended use is described in this

manual. The use of any accessory

or attachment or the performance

of any operation with this appliance

other than those recommended in this

instruction manual may present a risk

of personal injury.

uRetain this manual for future

reference.

ENGLISH

(Original instructions)

Using your appliance

uDo not use the appliance to pick up

liquids or any materials that could

catch re.

uDo not use the appliance near water.

uDo not immerse the appliance in water.

uNever pull the charger lead to

disconnect the charger from the

socket. Keep the charger lead away

from heat, oil and sharp edges.

uThis appliance can be used by

children aged from 8 years and above

and persons with reduced physical,

sensory or mental capabilities or

lack of experience and knowledge

if they have been given supervision

or instruction concerning use of

the appliance in a safe way and

understand the hazards involved.

Children shall not play with the

appliance. Cleaning and user

maintenance shall not be made by

children without supervision.

Inspection and repairs

Before use, check the appliance for

damaged or defective parts. Check for

breakage of parts, damage to switches

and any other conditions that may affect

its operation.

uDo not use the appliance if any part is

damaged or defective.

uHave any damaged or defective parts

repaired or replaced by an authorized

repair agent.

uRegularly check the charger lead for

damage. Replace the charger if the

lead is damaged or defective.

uNever attempt to remove or replace

any parts other than those specied in

this manual.

Additional safety instructions

After use

uUnplug the charger before cleaning the

charger or charging base.

uWhen not in use, the appliance should

be stored in a dry place.

uChildren should not have access to

stored appliances.

Residual risks

Additional residual risks may arise when

using the tool which may not be included

in the enclosed safety warnings. These

risks can arise from misuse, prolonged

use etc.

Even with the application of the relevant

safety regulations and the implementa-

tion of safety devices, certain residual

risks can not be avoided. These include:

uInjuries caused by touching any

rotating/moving parts.

uInjuries caused when changing any

parts, blades or accessories.

uInjuries caused by prolonged use

of a tool. When using any tool for

prolonged periods ensure you take

regular breaks.

uImpairment of hearing.

uHealth hazards caused by breathing

dust developed when using your

tool (example:- working with wood,

especially oak, beech and MDF.)

ENGLISH (Original instructions)

Chargers

Your charger has been designed for a

specic voltage. Always check that the

mains voltage corresponds to the voltage

on the rating plate.

Warning! Never attempt to replace the

charger unit with a regular mains plug.

uUse your BLACK+DECKER charger

only to charge the battery in the

appliance with which it was supplied.

Other batteries could burst, causing

personal injury and damage.

uNever attempt to charge non-

rechargeable batteries.

uIf the supply cord is damaged, it must

be replaced by the manufacturer or an

authorised BLACK+DECKER Service

Centre in order to avoid a hazard.

uDo not expose the charger to water.

uDo not open the charger.

uDo not probe the charger.

uThe appliance/battery must be

placed in a well ventilated area when

charging.

Electrical safety

Symbols on the charger

Read all of this manual carefully before using the

appliance.

#This tool is double insulated; therefore no earth wire

is required. Always check that the power supply

corresponds to the voltage on the rating plate.

$The charging base is intended for indoor use only.

Labels on appliance

The following symbols appear on this appliance along with the

date code:

+Read all of this manual carefully before

using the appliance

S010Q 14

Only use with charger S010Q 14

Features

This tool includes some or all of the following features.

1. On/off power switch

2. Handle

3. Nozzle

4. Pull out crevice tool

5. LED charging indicator

6. Dust bowl

7. Dust bowl release button

8. Charging base

9. Detachable push in brush accessory

10. Power head

Use

Switching on and off (Fig. A)

uPress the button (1) to turn on, the unit operates

in slow speed, low power mode, conserving the

battery life.

uPress the button (1) again, and the unit goes to a BOOST

mode.

uPressing the button (1) again will turn the product off.

Using the pull out crevice tool (Fig. B,C)

uExtend the crevice tool (4) as shown in gure C, until

it clicks in place. The push in brush (9) can be tted if

required for dusting and upholstery cleaning.

uTo retract the crevice tool (4) press the crevice tool release

button (4a) allowing it to return to its normal position

(Fig. B).

Attaching the power head (Fig. D)

uSlide the nozzle (3) into the opening of the power head

(10), ensuring that the connectors (10a) engage with the

recesses (3a). An auadible click will be heard.

Detaching the power head (Fig. E)

uPush th power head release button (10b).

uLift the main dustbuster unit from the power head (10).

Removing the beater bar from the power head

for cleaning (Fig. F)

uPress the beater bar release button (10c).

uLift the beater bar (10d) up and out of the power head.

uThe beater bar can now be freed from any hair and accu-

mulated debris.

ENGLISH

(Original instructions)

Charging (Fig. G)

uPlace the appliance onto the charging base (8) and plug

into the electrical outlet.

uSwitch the electrical outlet on. The LED charging indicator

(B) will illuminate.

Multi LED Display

A. Filter sensor

Whenever a lter is Blocked and needs cleaning, the red

lter LED (A) in the handle will illuminate.

Clean ne dust from lter (See section on ‘cleaning lters’

in this manual).

B. LED Charging display

The charging display LED (B) will illuminate when the unit

is charging and will indicate (ash) when further charging

is required.

C. BOOST mode

LED (C) Illuminates when the appliance is in BOOST

mode.

LED Patterns

Charging

Battery Fault

Charger Fault

Battery Hot

Warning! NEVER charge the unit with the power head

attached, as this will cause the unit to unbalance and may

cause safety problems.

Cleaning the lters (Fig. , H, I, J, K, L,

uPress the dust bowl release button (7) (Fig. H)

uEject the dust bowl (6) (Fig.I)

uLift the filter assembly (11) using the metal handle provid-

ed from the dust bowl (6) (Fig. J)

Note: On unit DVJ325BFSP the pre filter is impregnated with

a fragrance allowing for a pleasing odour to be released when

the appliance is in use.

uEmpty the dust bowl (6) by lightly shaking over a dustbin

(Fig. K).

uThe lter (12) can now be removed from the lter assem-

bly (11) (Fig. L)

uEmpty any remaining dust from the dust bowl.

uRinse out the dust-bowl with warm soapy water.

uWash the lters with warm soapy water (Fig. M).

uMake sure the lters are dry

uRet the lters into the appliance.

uClose the dust-bowl. Make sure the release latch (7) clicks

into place.

Warning! Before performing any maintenance or cleaning on

the appliance, unplug the appliance.

From time to time wipe the appliance with a damp cloth.

Do not use any abrasive or solvent-based cleaner. Do not

immerse the appliance in water

Maintenance

Your BLACK+DECKER cordless appliance has been designed

to operate over a long period of time with a minimum of main-

tenance. Continuous satisfactory operation depends upon

proper tool care and regular cleaning.

Warning! Before performing any maintenance on cordless

appliances:

uRun the battery down completely if it is integral and then

switch off.

uUnplug the charger before cleaning it. Your charger does

not require any maintenance apart from regular cleaning.

ENGLISH (Original instructions)

uRegularly clean the ventilation slots in your appliance/

charger using a soft brush or dry cloth.

uRegularly clean the motor housing using a damp cloth. Do

not use any abrasive or solvent-based cleaner.

Replacing the lters

The lters should be replaced every 6 to 9 months and when-

ever worn or damaged. Replacement lters are available from

your BLACK+DECKER dealer (cat. noVPF20).

There are also pre-scented lters available to be purchased

(cat. no: VSPF10LC). These t all units.When these lters

reach the end of their lifespan they must be disposed of at a

local recycling centre.

Filters are supplied in foil packaging which needs to be

removed. To assemble lters see Fig. I.

Warning!

Cotton linen fragrance.

Wash face, hands and any exposed skin

thoroughly after handling. Wear protective gloves/

protective clothing/eye protection/face protection.

If in eyes: Rinse cautiously with water for several

minutes. Remove contact lenses if

present and easy to do.

Continue rinsing. If skin irritation

occurs:

Get medical advice/attention.

Avoid release into the environment. Do not ingest.

uRemove the old lters as described above.

uFit the new lters as described above.

Protecting the environment

ZSeparate collection. Products and batteries

marked with this symbol must not be disposed of

with normal household waste.

Products and batteries contain materials that can be recov-

ered or recycled reducing the demand for raw materials.

Please recycle electrical products and batteries according to

local provisions. Further information is available at

www.2helpU.com

Technical Data

DVJ325BFSP

Voltage 10.8V

Current 2.5Ah

Watt Hours 27Wh

Weight (Power Head + unit) 1.6Kg

Guarantee

Black & Decker is condent of the quality of its products and

offers consumers a 24 month guarantee from the date

of purchase. This guarantee is in addition to and in no way

prejudices your statutory rights. The guarantee is valid within

the territories of the Member States of the European Union

and the European Free Trade Area.

To claim on the guarantee, the claim must be in accordance

with Black&Decker Terms and Conditions and you will need to

submit proof of purchase to the seller or an authorised repair

agent. Terms and conditions of the Black&Decker 2 year guar-

antee and the location of your nearest authorised repair agent

can be obtained on the Internet at www.2helpU.com, or

by contacting your local Black & Decker ofce at the address

indicated in this manual.

Please visit our website www.blackanddecker.co.uk to register

your new Black & Decker product and receive updates on new

products and special offers.

ENGLISH

(Original instructions)

ENGLISH (Original instructions)

Autres manuels pour DVJ325BFSP

Table des matières

Autres manuels BLACK DECKER Aspirateur

BLACK DECKER

BLACK DECKER NVB115J Manuel utilisateur

BLACK DECKER

BLACK DECKER Dustbuster SVJ520BFSP Manuel utilisateur

BLACK DECKER

BLACK DECKER OWERSERIES dustbuster 2in1 Cordless Stick... Manuel utilisateur

BLACK DECKER

BLACK DECKER DV7210EL Manuel utilisateur

BLACK DECKER

BLACK DECKER BHFE520J Manuel utilisateur

BLACK DECKER

BLACK DECKER BDCDB18 Manuel utilisateur

BLACK DECKER

BLACK DECKER BDCV610-LA Manuel utilisateur

BLACK DECKER

BLACK DECKER Dustbuster ADV1200 Manuel utilisateur

BLACK DECKER

BLACK DECKER HHVJ315JD Manuel utilisateur

BLACK DECKER

BLACK DECKER BDH1200NVAV Manuel utilisateur

BLACK DECKER

BLACK DECKER BDX19301-4B Manuel utilisateur

BLACK DECKER

BLACK DECKER DUSTBUSTER DB1440SV Manuel utilisateur

BLACK DECKER

BLACK DECKER BHFEA420J Manuel utilisateur

BLACK DECKER

BLACK DECKER BDXRBV660 Manuel utilisateur

BLACK DECKER

BLACK DECKER BHHV315B Manuel utilisateur

BLACK DECKER

BLACK DECKER BDH3600SV Manuel utilisateur

BLACK DECKER

BLACK DECKER BEMW351 Manuel utilisateur

BLACK DECKER

BLACK DECKER TBSV2020S Manuel utilisateur

BLACK DECKER

BLACK DECKER VCBD8090-AR Manuel utilisateur

BLACK DECKER

BLACK DECKER BHHV315B Manuel utilisateur

BLACK DECKER

BLACK DECKER BSV2020G Manuel utilisateur

BLACK DECKER

BLACK DECKER BDH1200PVAV Manuel utilisateur

BLACK DECKER

BLACK DECKER PV1820LAVC Manuel utilisateur

BLACK DECKER

BLACK DECKER VM1200 Manuel utilisateur

Manuels Aspirateur populaires d'autres marques

Bissell

Bissell LittleGreen Proheat 1425 Series Manuel utilisateur

Panasonic

Panasonic MC-YL637S147-AE Manuel utilisateur

NEFF

NEFF N17XH10 0 Series Manuel utilisateur

LG A9 Series Manuel utilisateur

Oreck

Oreck Cordless Captura BK51700 Series Manuel utilisateur

Kogan

Kogan KAVACROBVWA Manuel utilisateur

Kränzle

Kränzle VENTOS 50 ID Guide de l'utilisateur

EVVO

EVVO Ai35 Manuel utilisateur

DeWalt

DeWalt DWH200D Manuel utilisateur

Pontec

Pontec Pondomatic Vacuum Cleaner Manuel utilisateur

Cleanmaxx

Cleanmaxx PC-P007E Manuel utilisateur

Exido

Exido 240-114 Manuel utilisateur

RIDGID

RIDGID WD1685AU0 Manuel utilisateur

Ezviz

Ezviz RE4P Manuel utilisateur

STG global

STG global TANVAC HDV3000 Manuel utilisateur

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Manuel utilisateur

Factory

Factory M3340 Manuel utilisateur

Shop-Vac

Shop-Vac VN92 SERIES Manuel utilisateur
