BLACK DECKER FEJ520JF Manuel utilisateur

www.blackanddecker.co.nz

www.blackanddecker.com.au FEJ520JF

FEJ520JFS

1347

1216

17 G

610

ENGLISH (Original instructions)

Intended use

Your BLACK+DECKER FEJ520JF and FEJ520JFS

Dustbuster® hand-held vacuum cleaners have been designed

for vacuum cleaning purposes. These appliances are intended

for household use only.

Read all of this manual carefully

before operating the appliance.

Safety instructions

@Warning! Read all safety

warnings and all instructions.

Failure to follow the warnings

and instructions listed below may

result in electric shock, re and/or

serious injury.

uThe intended use is described in this

manual. The use of any accessory

or attachment or the performance

of any operation with this appliance

other than those recommended in this

instruction manual may present a risk

of personal injury.

uRetain this manual for future

reference.

Using your appliance

uDo not use the appliance to pick up

liquids or any materials that could

catch re.

uDo not use the appliance near water.

uDo not immerse the appliance in water.

uNever pull the charger lead to

disconnect the charger from the

socket. Keep the charger lead away

from heat, oil and sharp edges.

uThis appliance can be used by

children aged from 8 years and above

and persons with reduced physical,

sensory or mental capabilities or

lack of experience and knowledge

if they have been given supervision

or instruction concerning use of

the appliance in a safe way and

understand the hazards involved.

Children shall not play with the

appliance. Cleaning and user

maintenance shall not be made by

children without supervision.

Inspection and repairs

Before use, check the appliance for

damaged or defective parts. Check for

breakage of parts, damage to switches

and any other conditions that may affect

its operation.

uDo not use the appliance if any part is

damaged or defective.

uHave any damaged or defective parts

repaired or replaced by an authorized

repair agent.

uRegularly check the charger lead for

damage. Replace the charger if the

lead is damaged or defective.

uNever attempt to remove or replace

any parts other than those specied in

this manual.

Additional safety instructions

After use

uUnplug the charger before cleaning the

charger or charging base.

uWhen not in use, the appliance should

be stored in a dry place.

uChildren should not have access to

stored appliances.

Residual risks

Additional residual risks may arise when

using the tool which may not be included

in the enclosed safety warnings. These

risks can arise from misuse, prolonged

use etc.

ENGLISH

(Original instructions)

Even with the application of the relevant

safety regulations and the implementa-

tion of safety devices, certain residual

risks can not be avoided. These include:

uInjuries caused by touching any

rotating/moving parts.

uInjuries caused when changing any

parts, blades or accessories.

uInjuries caused by prolonged use

of a tool. When using any tool for

prolonged periods ensure you take

regular breaks.

uImpairment of hearing.

uHealth hazards caused by breathing

dust developed when using your

tool (example:- working with wood,

especially oak, beech and MDF.)

Chargers

Your charger has been designed for a

specic voltage. Always check that the

mains voltage corresponds to the voltage

on the rating plate.

Warning! Never attempt to replace the

charger unit with a regular mains plug.

uUse your BLACK+DECKER charger

only to charge the battery in the

appliance with which it was supplied.

Other batteries could burst, causing

personal injury and damage.

uNever attempt to charge non-

rechargeable batteries.

uIf the supply cord is damaged, it must

be replaced by the manufacturer or an

authorised BLACK+DECKER Service

Centre in order to avoid a hazard.

uDo not expose the charger to water.

uDo not open the charger.

uDo not probe the charger.

uThe appliance/battery must be

placed in a well ventilated area when

charging.

Electrical safety

Symbols on the charger

+Read all of this manual carefully before using the

appliance.

#This tool is double insulated; therefore no earth wire

is required. Always check that the power supply

corresponds to the voltage on the rating plate.

wShort circuit proof safety isolating transformer. The

mains supply is electrically separated from the

transformer output.

xThe charger automatically shuts off if the ambient

temperature becomes too high. As a consequence

the charger will be inoperable. The charging base

must be disconnected from the mains supply and

taken to an authorised service centre for repair.

$The charging base is intended for indoor use only.

Labels on appliance

The following symbols appear on this appliance along with the

date code

+Read all of this manual carefully before

using the appliance

S010Q 23 Only use with charger S010Q 23

Features

This tool includes some or all of the following features.

1. On/off power switch

2. Handle

3. Nozzle

4. Pull out crevice tool

5. LED charging indicator

6. Dust bowl

7. Push in brush

8. Floor extension release clip

9. Floor extension tube

10. Floor head release clip

11. Flip down brush

12. Floor head

13. Wall bracket

14. Charger

15. Charging port

ENGLISH (Original instructions)

Use

Switching on and off (Fig. A)

uPress the button to turn, on the unit operates in slow

speed, low power mode, conserving the battery life.

uPress the button again, and the unit goes to a BOOST

mode.

uPressing the button again will turn the product off.

Using the pull out crevice tool (Fig. B,C)

uExtend the crevice tool (4) as shown in gure C, until it

clicks in place. The push in brush (7) can then be tted if

required for dusting and upholstery cleaning.

uTo retract the crevice tool (4) press the crevice tool release

button (4a) allowing it to return to its normal position

(Fig. B).

Fitting the oor extension tube (Fig. D)

uSlide the nozzle (3) into the oor extension tube (9) until

you hear an audible ‘click’ as shown in gure D.

uThe oor extension tube is supplied with a ip down brush

(11) for cleaning difcult to reach areas (Fig.E).

Fitting the oor head (Fig. F)

uSlide the oor extension tube (9) onto the oor extension

head (12) until you hear an audible ‘click’ as shown in

gure F.

Floor sense feature

The appliance is tted with a unique oor sensing feature.

It senses thick pile carpet and automatically goes from low

speed to BOOST mode for greater cleaning performance.

Removing and clearing hair from the beater

bars

(Fig. G, H)

uDepress the beater bar unit (16) release button (17) as

shown in gure G.

uThe beater bar (18) can now be removed. The end pieces

are also removable allowing you to clear any hair or other

debris that may have accumulated during use (Fig. H).

Charging (Fig. I)

The appliance can be charged either as a single unit or while

attached to the oor extension.

Wall Mounting

The wall mount (13) can be attached to a wall to provide a

convenient storage for the appliance.

Warning! When xing to a wall, make sure that the xing

method is suitable for the wall type and is appropriate to the

weight of the appliance.

uMark the location of the screw holes (within reach of an

electrical outlet for charging the vac while it is on the wall

bracket).

uPlace the charger (14) into the charging port (15) and plug

into the electrical outlet.

uSwitch the electrical outlet on. The LED charging indicator

(B) will Illuminate.

Multi LED Display

A. Filter sensor

Whenever a lter is blocked and needs cleaning, the red

lter LED (A) in the handle will illuminate.

Clean ne dust from lter (See section on ‘cleaning lters’

in this manual).

B. LED Charging display

Battery icon will illuminate when appliance requires

charging. LED display indicates state of charge (See LED

pattern chart in this manual).

C. BOOST mode

Illuminates when the appliance is in BOOST mode

allowing you to operate at higher power.

ENGLISH

(Original instructions)

LED Patterns

Charging

Battery Fault

Charger Fault

Battery Hot

uPress the dust bowl release button (19) (Fig. J)

uEject the dust bowl (6) (Fig.K)

the dust bowl (6) (Fig.L).

uEmpty the dust bowl by lightly shaking over a dustbin.

Note: On unit FEJ520JFS the pre filter is impregnated with a

fragrance allowing for a pleasing odour to be released when

the appliance is in use.

(Fig. M).

uEmpty any remaining dust from the dust bowl.

uRinse out the dust-bowl with warm soapy water.

uClose the dust-bowl. Make sure the release latch (19)

clicks into place.

Warning! Before performing any maintenance or cleaning on

the appliance, unplug the appliance.

From time to time wipe the appliance with a damp cloth.

Do not use any abrasive or solvent-based cleaner. Do not

immerse the appliance in water

Maintenance

Your BLACK+DECKER cordless appliance has been designed

to operate over a long period of time with a minimum of main-

tenance. Continuous satisfactory operation depends upon

proper tool care and regular cleaning.

Warning! Before performing any maintenance on cordless

appliances:

uRun the battery down completely if it is integral and then

switch off.

uUnplug the charger before cleaning it. Your charger does

not require any maintenance apart from regular cleaning.

uRegularly clean the ventilation slots in your appliance/

charger using a soft brush or dry cloth.

uRegularly clean the motor housing using a damp cloth. Do

not use any abrasive or solvent-based cleaner.

your BLACK+DECKER dealer (cat. noVPF20)

reach the end of their lifespan they must be disposed of at a

local recycling centre.

Warning!

Cotton linen fragrance.

Wash face, hands and any exposed skin

thoroughly after handling. Wear protective

gloves/protective clothing/eye protection/

face protection. If in eyes: Rinse cautiously

with water for several minutes. Remove

contact lenses if present and easy to do.

Continue rinsing. If skin irritation occurs: Get

medical advice/attention. Avoid release into

the environment. Do not ingest.

Protecting the environment

ZSeparate collection. Products and batteries

marked with this symbol must not be disposed of

with normal household waste.

Products and batteries contain materials that can be recov-

ered or recycled reducing the demand for raw materials.

Please recycle electrical products and batteries according to

local provisions. Further information is available at

www.2helpU.com

Technical Data

FEJ520JF, FEJ520JFS

Voltage 18V

Watt Hours 36Wh

Weight 2.5Kg

ENGLISH (Original instructions)

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels BLACK DECKER Aspirateur

BLACK DECKER

BLACK DECKER Dustbuster NV1200AV Manuel utilisateur

BLACK DECKER

BLACK DECKER VPX2102 Manuel utilisateur

BLACK DECKER

BLACK DECKER HFEJ415JWMF22 Manuel utilisateur

BLACK DECKER

BLACK DECKER VM2040 Manuel utilisateur

BLACK DECKER

BLACK DECKER CUA525BH Manuel utilisateur

BLACK DECKER

BLACK DECKER WDA315 Series Manuel utilisateur

BLACK DECKER

BLACK DECKER DVJ325BFSP Manuel utilisateur

BLACK DECKER

BLACK DECKER BHFEV362DA Manuel utilisateur

BLACK DECKER

BLACK DECKER BSV2020G Manuel utilisateur

BLACK DECKER

BLACK DECKER BDCAR1200 Manuel utilisateur

BLACK DECKER

BLACK DECKER DVB315JP Manuel utilisateur

BLACK DECKER

BLACK DECKER OWERSERIES dustbuster 2in1 Cordless Stick... Manuel utilisateur

BLACK DECKER

BLACK DECKER HHVI325JR Manuel utilisateur

BLACK DECKER

BLACK DECKER VH800 Manuel utilisateur

BLACK DECKER

BLACK DECKER BEMW351 Manuel utilisateur

BLACK DECKER

BLACK DECKER SVB520JW-B5 Manuel utilisateur

BLACK DECKER

BLACK DECKER Dustbuster DVA315J Manuel utilisateur

BLACK DECKER

BLACK DECKER CYCLONIC POWER PRO Manuel utilisateur

BLACK DECKER

BLACK DECKER PV1820LAVC Manuel utilisateur

BLACK DECKER

BLACK DECKER HSV320J32 Manuel utilisateur

BLACK DECKER

BLACK DECKER NVB215WN Manuel utilisateur

BLACK DECKER

BLACK DECKER dustbuster AdvancedClean+ HHVK515JP07 Manuel utilisateur

BLACK DECKER

BLACK DECKER Dustbuster DVJ215J Manuel utilisateur

BLACK DECKER

BLACK DECKER BXVMS600E Manuel utilisateur

Manuels Aspirateur populaires d'autres marques

Bissell

Bissell LittleGreen Proheat 1425 Series Manuel utilisateur

Panasonic

Panasonic MC-YL637S147-AE Manuel utilisateur

NEFF

NEFF N17XH10 0 Series Manuel utilisateur

LG A9 Series Manuel utilisateur

Oreck

Oreck Cordless Captura BK51700 Series Manuel utilisateur

Kogan

Kogan KAVACROBVWA Manuel utilisateur

Kränzle

Kränzle VENTOS 50 ID Guide de l'utilisateur

EVVO

EVVO Ai35 Manuel utilisateur

DeWalt

DeWalt DWH200D Manuel utilisateur

Pontec

Pontec Pondomatic Vacuum Cleaner Manuel utilisateur

Cleanmaxx

Cleanmaxx PC-P007E Manuel utilisateur

Exido

Exido 240-114 Manuel utilisateur

RIDGID

RIDGID WD1685AU0 Manuel utilisateur

Ezviz

Ezviz RE4P Manuel utilisateur

STG global

STG global TANVAC HDV3000 Manuel utilisateur

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Manuel utilisateur

Factory

Factory M3340 Manuel utilisateur

Shop-Vac

Shop-Vac VN92 SERIES Manuel utilisateur
