BLACK BOX®

Switch between two or four different HDMI sources

to a single display.

Supports up to 4 K (UHD) resolutions (3840 x 2160).

Automatically switches to a source when it becomes available.

2 x 1 or 4 x 1 HDMI Switch 4K

VSW-HDMI2X1-4K

VSW-HDMI4X1-4K

Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S.

call 724-746-5500) • FREE technical support 24 hours a day, 7 days

a week: Call 724-746-5500 or fax 724-746-0746 • Mailing address:

Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018

Web site: www.blackbox.com • E-mail: [email protected]

Customer

Support

Information

724-746-5500 | blackbox.com

Page 2

Trademarks Used in this Manual

Black Box and the Double Diamond logo are registered trademarks of

BB Technologies, Inc.

Any other trademarks mentioned in this manual are acknowledged to be

the property of the trademark owners.

724-746-5500 | blackbox.com Page 3

FCC and IC RFI Statements/NOM Statement

FEDERAL COMMUNICATIONS COMMISSION AND INDUSTRY

CANADA RADIO FREQUENCY INTERFERENCE STATEMENTS

This equipment generates, uses, and can radiate radio-frequency energy, and if

not installed and used properly, that is, in strict accordance with the manufacturer’s

instructions, may cause interference to radio communication. It has been tested

and found to comply with the limits for a Class A computing device in accordance

with the specifications in Subpart B of Part 15 of FCC rules, which are designed

to provide reasonable protection against such interference when the equipment

is operated in a commercial environment. Operation of this equipment in a

residential area is likely to cause interference, in which case the user at his own

expense will be required to take whatever measures may be necessary to correct

the interference.

Changes or modifications not expressly approved by the party responsible

for compliance could void the user’s authority to operate the equipment.

This digital apparatus does not exceed the Class A limits for radio noise emission

from digital apparatus set out in the Radio Interference Regulation of Industry

Canada.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant

les limites applicables aux appareils numériques de classe A prescrites dans le

Règlement sur le brouillage radioélectrique publié par Industrie Canada.

Normas Oficiales Mexicanas (NOM)Electrical Safety Statement

INSTRUCCIONES DE SEGURIDAD

1. Todas las instrucciones de seguridad y operación deberán ser leídas antes

de que el aparato eléctrico sea operado.

2. Las instrucciones de seguridad y operación deberán ser guardadas para

referencia futura.

3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de

operación deben ser respetadas.

724-746-5500 | blackbox.com

Page 4

NOM Statement

4. Todas las instrucciones de operación y uso deben ser seguidas.

5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo, cerca

de la tina de baño, lavabo, sótano mojado o cerca de una alberca, etc.

6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales que

sean recomendados por el fabricante.

7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea

recomendado por el fabricante.

8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más allá

a lo descrito en las instrucciones de operación. Todo otro servicio deberá ser

referido a personal de servicio calificado.

9. El aparato eléctrico debe ser situado de tal manera que su posición no

interfiera su uso. La colocación del aparato eléctrico sobre una cama, sofá,

alfombra o superficie similar puede bloquea la ventilación, no se debe colocar

en libreros o gabinetes que impidan el flujo de aire por los orificios de

ventilación.

10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor

como radiadores, registros de calor, estufas u otros aparatos (incluyendo

amplificadores) que producen calor.

11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del

tipo descrito en el instructivo de operación, o como se indique en el aparato.

12. Precaución debe ser tomada de tal manera que la tierra fisica y la polarización

del equipo no sea eliminada.

13. Los cables de la fuente de poder deben ser guiados de tal manera que no

sean pisados ni pellizcados por objetos colocados sobre o contra ellos,

poniendo particular atención a los contactos y receptáculos donde salen del

aparato.

14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las

recomendaciones del fabricante.

15. En caso de existir, una antena externa deberá ser localizada lejos de las lineas

de energia.

724-746-5500 | blackbox.com Page 5

NOM Statement

16. El cable de corriente deberá ser desconectado del cuando el equipo no sea

usado por un largo periodo de tiempo.

17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean

derramados sobre la cubierta u orificios de ventilación.

18. Servicio por personal calificado deberá ser provisto cuando:

A: El cable de poder o el contacto ha sido dañado; u

B: Objectos han caído o líquido ha sido derramado dentro del aparato; o

C: El aparato ha sido expuesto a la lluvia; o

D: El aparato parece no operar normalmente o muestra un cambio en su

desempeño; o

E: El aparato ha sido tirado o su cubierta ha sido dañada.

724-746-5500 | blackbox.com

Page 6

Table of Contents

1. Specifications................................................................................................. 7

2. Overview........................................................................................................ 9

2.1 Introduction.......................................................................................... 9

2.2 Features ................................................................................................ 9

2.3 What's Included ................................................................................. 10

2.4 Hardware Description..........................................................................11

2.4.1 4 x 1 HDMI Switch 4K (VSW-HDMI2X1-4K) ............................11

2.4.2 2 x 1 HDMI Switch 4K (VSW-HDMI4X1-4K) ............................11

3. Installation ................................................................................................... 14

3.1 Device Connection ............................................................................. 14

3.2 Connection Pattern ............................................................................ 15

4. Operation..................................................................................................... 16

4.1 LED Indicators..................................................................................... 16

4.2 Push Button Control........................................................................... 17

4.2.1 A/V Source Selection ............................................................... 17

4.2.2 EDID Setting............................................................................. 17

4.2.3 EDID Emulation........................................................................ 18

4.2.4 EQ Adjustment......................................................................... 18

4.2.5 Factory Default Settings........................................................... 19

4.3 IR Remote Control.............................................................................. 19

5. Serial Control ............................................................................................... 20

724-746-5500 | blackbox.com Page 7

Chapter 1: Specifications

1. Specifications

Approvals Unit and power supply: FCC Part 15, CE, UL, RoHS,

Power supply: Also has CSA, TUV

Color Black

Frequency Range 25–297 MHz

Material Steel

Mode Configuration Switch/Autosensing/Priority/Matrix

MTBF 50,000 hours

Serial Control VSW-HDMI2X1-4K: Not applicable,

VSW-HDMI4X1-4K: Yes, RJ-11

Signal Configuration Video: Auto/inventory,

Audio: Auto/inventory

User Controls (1) port selection switch button,

(1) EDID Copy button,

(1) EDID switch for EDID selection,

(1) EGO setting switch for auto functions

Video Mode 4K x 2K @ 30 Hz

Connectors VSW-HDMI2X1-4K:

Input: (2) HDMI female,

Output: (1) HDMI female,

Power: (1) 2.5-mm barrel jack,

VSW-HDMI4X1-4K:

Input: (4) HDMI female,

Output: (1) HDMI female,

Power: (1) 2.5-mm barrel jack,

Control port: (1) RJ-11 RS-232

724-746-5500 | blackbox.com

Page 8

Chapter 1: Specifications

Specifications (continued)

Indicators VSW-HDMI2X1-4K:

(2) LEDS for input status;

VSW-HDMI4X1-4K:

(4) LEDs for input status

NOTE: Only one input LED is lit at a time.

Environmental Temperature Tolerance:

Operating:

32 to 104° F (0 to 40° C);

Storage:

-4 to +140° F (-20 to +60° C);

Relative Humidity: 80%

Altitude: 10,000 ft.

Power Input voltage:

100 to 240 VAC, 50 to 60 Hz, 45 watts,

Input connector: IEC320 C14.

Output voltage: 9 VDC, 1.5 A via a 2.5-mm barrel

plug center-positive desktop power supply

Dimensions 0.8"H x 6.1"W x 2.6"D (2 x 15.6 x 6.5 cm)

Weight Product: 1.55 lb. (0.7 kg),

Shipping: 2.09 lb. (0.8 kg)

724-746-5500 | blackbox.com Page 9

Chapter 2: Overview

2. Overview

2.1 Introduction

The 2 x 1 or 4 x 1 HDMI Switch 4K enables users to quickly and easily share display

devices (HDTV, Blu-ray player, HD-DVD, Xbox, Wii, PS3, satellite receiver, etc.) from

your device inputs to one output device (monitor, projector, or TV). You can select

the desired input source within the range of 16.4 feet (5 meters) via the remote

control or push button located on the switch. You don’t need to plug and unplug

video sources, so A/V equipment is more convenient, more affordable, and more

efficient.

The HDMI Switch with Advanced Auto-Sensing includes Auto mode and Priority

mode functions. The system can either automatically select the latest video source

for display in Auto mode, or automatically select a video source following priority

order in Priority mode. And it also offers EDID Copy function to ensure the optimal

resolution for your application.

The built-in serial interface allows users to control the HDMI Switch through a PC,

serial controller device, or home theater system, integrating the whole A/V

environment.

2.2 Features

• Select one output device from 2 or 4 different sources.

• Autosensing function automatically selects active input source or prioritized

source.

• Control the switch via the front-panel push button, IR remote controller, or, for the

4-port model, via the serial connection.

• Individually turn ON/OFF the output port.

• Locking HDMI cables keep your connections secure.

• 3D-video, HDCP compliant, and Blu-ray ready

• Non-volatile memory stores all settings in case of blackout.

• Innovative technology designed to avoid unnecessary flicker when adding system

instruments.

• Signal optimization chooses the best output setting from the available alternatives.

• HDTV, 3D HDTV compatible.

• Supports resolutions up to Full HD 1080p/4K (3840 x 2160).

724-746-5500 | blackbox.com

Page 10

Chapter 2: Overview

Advanced Autosensing

• Select ports in Priority, Auto-sensing, and Switch modes.

- In Priority mode, the system automatically selects highest priority source to display

(Priority order: Source-1 > Source-2 > ……).

- In Auto-sensing mode, the system automatically selects the latest video source to

display.

- In Switch mode, the system selects the outputs to switch.

• Switch outputs by pressing a button or setting priority.

EDID Function

• EDID Copy and EDID Pre-setting ensure accurate output display.

• Set to separately learn audio and video EDID for multimedia/home theater system

integration.

• Emulating EDID information ensures optimum video performance.

• Read and store the EDID from the connecting display to the video extension.

2.3 What’s Included

Both switches include:

• 2 x 1 HDMI Switch 4K (VSW-HDMI2X1-4K) or 4 x 1 HDMI Switch 4K

(VSW-HDMI4X1-4K)

• Power adapter

• IR remote controller

• Set of foot pads

• This user manual

4 x 1 HDMI Switch 4K (VSW-HDMI4X1-4K) also has:

• RJ-11 cable for serial (RS-232) control

• RJ-11 to RS-232 converter for serial (RS-232) control

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Black Box Changer

Black Box

Black Box ServSwitch Wizard MP KV804A Manuel utilisateur

Black Box

Black Box SERVSWITCH PANTHER KV1108A Manuel utilisateur

Black Box

Black Box LBH081A Manuel utilisateur

Black Box

Black Box LPH1004A Manuel utilisateur

Black Box

Black Box ServView 17S KVT128AE-UK-8-R2 Manuel utilisateur

Black Box

Black Box IC454AE Manuel utilisateur

Black Box

Black Box CATX DVI-D Series Manuel utilisateur

Black Box

Black Box Peripheral Sharer 2 to 1 Manuel utilisateur

Black Box

Black Box SM906C Manuel utilisateur

Black Box

Black Box KV9404A Manuel utilisateur

Black Box

Black Box IC147A Manuel utilisateur

Black Box

Black Box ServSwitch 17S Manuel utilisateur

Black Box

Black Box SS4P-KM-U Manuel utilisateur

Black Box

Black Box SW1000A Manuel utilisateur

Black Box

Black Box LB8408A-R2 Manuel utilisateur

Black Box

Black Box Active Star Hub IC207A Manuel utilisateur

Black Box

Black Box Code Operated Switch-16 Manuel utilisateur

Black Box

Black Box KV7000A Manuel utilisateur

Black Box

Black Box LB9306A Manuel utilisateur

Black Box

Black Box ServSwitch SW625A-R2 Manuel utilisateur

Black Box

Black Box ServSwitch KV1510A Manuel utilisateur

Black Box

Black Box AC1032A-2 Manuel utilisateur

Black Box

Black Box LE401A Manuel utilisateur

Black Box

Black Box 10BASE-T MiniHub Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
