Black Box AVSW-HDMI4X4 Manuel utilisateur

BL A C K B O X®

Switch multiple HDMI sources to multiple

displays in any combination.

HDMI Matrix Switches

Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)

FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax

724-746-0746 • Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence,

PA 15055-1018 • Web site: www.blackbox.com • E-mail: [email protected]

Customer

Support

Information

AVSW-HDMI4X4

AVSW-HDMI2X4

AVSW-HDMI4X2

AVSW-HDMI2X2

Page 2 724-746-5500 | blackbox.com AVSW-HDMI2X2

FCC and IC RFI Statements

FEDERAL COMMUNICATIONS COMMISSION AND

INDUSTRY CANADA RADIO FREQUENCY INTERFERENCE STATEMENTS

This equipment generates, uses, and can radiate radio-frequency energy,

and if not installed and used properly, that is, in strict accordance with the

manufacturer’s instructions, may cause interference to radio communication.

It has been tested and found to comply with the limits for a Class A computing

device in accordance with the specifications in Subpart J of Part 15 of FCC rules,

which are designed to provide reasonable protection against such interference

when the equipment is operated in a commercial environment. Operation of

this equipment in a residential area is likely to cause interference, in which case

the user at his own expense will be required to take whatever measures may be

necessary to correct the interference.

Changes or modifications not expressly approved by the party responsible

for compliance could void the user’s authority to operate the equipment.

This digital apparatus does not exceed the Class A limits for radio noise

emission from digital apparatus set out in the Radio Interference Regulation

of Industry Canada.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les

limites applicables aux appareils numériques de la classe A prescrites dans le

Règlement sur le brouillage radioélectrique publié par Industrie Canada.

Page 3

724-746-5500 | blackbox.com

AVSW-HDMI2X2

NOM Statement

Normas Oficiales Mexicanas (NOM)

Electrical Safety Statement

INSTRUCCIONES DE SEGURIDAD

1. Todas las instrucciones de seguridad y operación deberán ser leídas antes

de que el aparato eléctrico sea operado.

2. Las instrucciones de seguridad y operación deberán ser guardadas para

referencia futura.

3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de

operación deben ser respetadas.

4. Todas las instrucciones de operación y uso deben ser seguidas.

5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo,

cerca de la tina de baño, lavabo, sótano mojado o cerca de una alberca,

etc.

6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales

que sean recomendados por el fabricante.

7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea

recomendado por el fabricante.

8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más allá

lo descrito en las instrucciones de operación. Todo otro servicio deberá ser

referido a personal de servicio calificado.

9. El aparato eléctrico debe ser situado de tal manera que su posición no

interfiera su uso. La colocación del aparato eléctrico sobre una cama, sofá,

alfombra o superficie similar puede bloquea la ventilación, no se debe

colocar en libreros o gabinetes que impidan el flujo de aire por los orificios

de ventilación.

10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor

como radiadores, registros de calor, estufas u otros aparatos (incluyendo

amplificadores) que producen calor.

11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del

tipo descrito en el instructivo de operación, o como se indique en el

aparato.

Page 4 724-746-5500 | blackbox.com AVSW-HDMI2X2

NOM Statement

12. Precaución debe ser tomada de tal manera que la tierra fisica y la

polarización del equipo no sea eliminada.

13. Los cables de la fuente de poder deben ser guiados de tal manera que no

sean pisados ni pellizcados por objetos colocados sobre o contra ellos,

poniendo particular atención a los contactos y receptáculos donde salen

del aparato.

14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las

recomendaciones del fabricante.

15. En caso de existir, una antena externa deberá ser localizada lejos de las

lineas de energia.

16. El cable de corriente deberá ser desconectado del cuando el equipo no sea

usado por un largo periodo de tiempo.

17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean

derramados sobre la cubierta u orificios de ventilación.

18. Servicio por personal calificado deberá ser provisto cuando:

A: El cable de poder o el contacto ha sido dañado; u

B: Objectos han caído o líquido ha sido derramado dentro del aparato; o

C: El aparato ha sido expuesto a la lluvia; o

D: El aparato parece no operar normalmente o muestra un cambio en su

desempeño; o

E: El aparato ha sido tirado o su cubierta ha sido dañada.

Page 5

724-746-5500 | blackbox.com

AVSW-HDMI2X2

Trademarks Used in this Manual

Black Box and the Double Diamond logo are registered trademarks of

BB Technologies, Inc.

AMX is a registered trademark of AMX LLC.

Control4 is a registered trademark of Control4 Corporation.

Crestron is a registered trademark of Creston Electronics, Inc.

Dolby is a registered trademark of Dolby Laboratories Licensing Corporation.

Any other trademarks mentioned in this manual are acknowledged to be

the property of the trademark owners.

Page 6 724-746-5500 | blackbox.com AVSW-HDMI2X2

Table of Contents

1. Specifications ..............................................................................................7

2. Overview..................................................................................................... 8

2.1 Introduction ....................................................................................... 8

2.2 Features ............................................................................................. 8

2.3 What’s Included ................................................................................. 9

2.4 Hardware Description ........................................................................9

2.4.1 Front Panel..............................................................................9

2.4.2 Back Panel ............................................................................ 11

3. Remote Control Functions ........................................................................ 12

4. RS-232 Serial Interface.............................................................................. 16

4.1 Pin Definitions .................................................................................. 16

4.2 Commands....................................................................................... 16

5. RS-232 Serial Commands.......................................................................... 17

5.1 Standby Mode ................................................................................. 17

5.2 Power Off Mode.............................................................................. 17

5.3 Front Panel Lock............................................................................... 18

5.4 Unit Reset ........................................................................................ 18

6. Typical Application.................................................................................... 19

7. Safety Information .................................................................................... 20

7.1 Safeguards ....................................................................................... 20

7.2 Precautions....................................................................................... 20

Page 7

724-746-5500 | blackbox.com

AVSW-HDMI2X2

Chapter 1: Specifications

1. Specifications

Bandwidth: 6.75 Gbps (single-link)

Resolutions Supported: PC: Up to 1920 x 1200;

HDTV: 480i, 576i, 480p, 576p, 720p, 1080i, 1080p

CE Approval: Yes

RoHS: Yes

Connectors: AVSW-HDMI4X4: Input: (4) HDMI F;

Output: (4) HDMI F;

Control/command port: (1) DB9 F (RS-232);

AVSW-HDMI2X4: Input: (2) HDMI F;

Output: (4) HDMI F;

Control/command port: (1) DB9 F (RS-232);

AVSW-HDMI4X2: Input: (4) HDMI F;

Output: (2) HDMI F;

Control/command port: (1) DB9 F (RS-232);

AVSW-HDMI2X2: Input: (2) HDMI F;

Output: (2) HDMI F;

Control/command port: (1) DB9 F (RS-232)

Power: Input: 12 VDC

Size: 1.75"H (1U) x 17.3"W x 8.5"D (4.3 x 43.9 x 22 cm)

Weight: 7.5 lb. (3.4 kg)

NOTE: When connecting outputs to both displays and AV receivers, the audio out-

put will only be stereo because of the limitations of the display.

In addition, the switch will determine the resolution of all connected

displays and output the resolution of the lowest display. For example:

If you have both a 1080p LCD and a 720p LCD connected, the output

to both will be 720p.

Page 8 724-746-5500 | blackbox.com AVSW-HDMI2X2

Chapter 2: Overview

2. Overview

2.1 Introduction

HDMI Matrix Switches from Black Box support sharp, highly defined video in HD

resolutions of up to 1080p—with a bandwidth of 6.75 Gbps.

Any input can be routed to any output, or the same input can be routed to all

outputs or any combination, eliminating the need to manually move various cables

to display HDMI video from different sources on different screens. An input source

LED tells you at a glance each output you’ve selected.

The switch sets up in seconds and is easy to use. Control using front-panel

buttons, the included IR remote controller, or an RS-232 connection linked to a

Crestron®, AMX®, Control4®system, or any third-party computerized software/

hardware control system. The switch even comes with an RS-232 serial cable for

quick setup.

The switch also has an IR signal extension port (and includes an IR extender

receiver). Once plugged in, the receiver enables you to use the IR remote

controller to switch ports on the unit from another room—up to 984 feet

(300 m) away.

Four models are available:

• AVSW-HDMI4X4: (4) HDMI inputs, (4) HDMI outputs

• AVSW-HDMI2X4: (2) HDMI inputs, (4) HDMI outputs

• AVSW-HDMI4X2: (4) HDMI inputs, (2) HDMI outputs

• AVSW-HDMI2X2: (2) HDMI inputs, (2) HDMI outputs

2.2 Features

• HDMI 1.3 and HDCP compliant.

• Works with all HDMI sources and displays—plus it’s 3D capable.

• Signal boosters on ports amplify HDMI signals up to 60 feet (18.2 m).

• Supports the latest HDMI audio formats, including Dolby®TrueHD and DTS-HD.

• Carries the high-speed digital video signaling of TMDS formats for the delivery

of 12-bit Deep Color.

• Ideal for corporate theaters, conference rooms, classroom and training facilities,

and video broadcasting applications.

Page 9

724-746-5500 | blackbox.com

AVSW-HDMI2X2

Chapter 2: Overview

• Rackmountable 1U-high unit with mounting ears.

• Switch audio and video of two or four sources to two or four displays in any

combination.

• Control from the front panel, with the included IR remote controller, or from an

RS-232 console.

• Supports resolutions up to 1080p.

2.3 What’s Included

Your package should include the following items. If anything is missing

or damaged, contact Black Box Technical Support at 724-746-5500 or

info@blackbox.com.

• Matrix switch • Rackmount kit

• 12-VDC power supply adapter • Control software

• IR extender kit • RS-232 serial cable

• IR remote controller • This user‘s manual

2.4 Hardware Description

2.4.1 Front Panel

Figure 2-1 shows the front panel of the converter. Table 2-1 describes its

components.

1 3 4 5 6

Figure 2-1. Front panel.

Page 10 724-746-5500 | blackbox.com AVSW-HDMI2X2

Chapter 2: Overview

Table 2-1. Front panel components.

Number Component Description

1 Power switch and Press this button to power the switch on

LED indicator or off.

2 LEDs 1–4 Provides input port status

3 Input selector A Press the HDMI OUT A button

repeatedly to switch to your desired

source, and the LED will light to indicate

which input source is selected and

routed to HDMI A display.

4 Input selector B Press the HDMI OUT B button

repeatedly to switch to your desired

source, and the LED will light to indicate

which input source is selected and

routed to HDMI B display.

5 Input selector C Press the HDMI OUT C button

repeatedly to switch to your desired

source, and the LED will light to indicate

which input source is selected and

routed to HDMI C display.

6 Input selector D Press the HDMI OUT D button

repeatedly to switch to your desired

source, and the LED will light to indicate

which input source is selected and

routed to HDMI D display.

7 Status LEDs (4) seven-segment LEDs to show current

output status.

NOTE: AVSW-HDMI4X2 and

AVSW-HMDI2X2 switches only

have (2) seven-segment LEDs.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Black Box Changer

Black Box

Black Box LB9801A Manuel utilisateur

Black Box

Black Box PSE544-DE-R2 Manuel utilisateur

Black Box

Black Box ACL201A Manuel utilisateur

Black Box

Black Box KVP4004A Manuel utilisateur

Black Box

Black Box LB9020A Manuel utilisateur

Black Box

Black Box DPMSTHUB-4P Manuel utilisateur

Black Box

Black Box LGB304A Manuel utilisateur

Black Box

Black Box ACXC Series Manuel utilisateur

Black Box

Black Box LPH008A-R2 Manuel utilisateur

Black Box

Black Box ClassWork Junior Manuel utilisateur

Black Box

Black Box LT0007A-4U Manuel utilisateur

Black Box

Black Box LGB1126A Manuel utilisateur

Black Box

Black Box ServSwitch DTX5002 Manuel utilisateur

Black Box

Black Box 10BASE-T MiniHub Manuel utilisateur

Black Box

Black Box AVSW-HDMI2X1A Manuel utilisateur

Black Box

Black Box ServSwitch SW625A-R2 Manuel utilisateur

Black Box

Black Box LEH1104A-2GSFP Manuel utilisateur

Black Box

Black Box LGB1048A Manuel utilisateur

Black Box

Black Box IC440A Manuel utilisateur

Black Box

Black Box ServSelect III KV21008A Instructions d'installation et d'entretien

Black Box

Black Box IC254A-US Manuel utilisateur

Black Box

Black Box ServSwitch Secure USB Manuel utilisateur

Black Box

Black Box SWL065A Manuel utilisateur

Black Box

Black Box LBS005A Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
