Black Box WRT4002A Manuel utilisateur

BLACK BOX®

Quick Start Guide

Single box solution for Internet/WAN access, VPN, firewall,

Ethernet switching, and legacy protocol to IP internetworking.

WRT4000 Series Cellular Wireless Routers

Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)

FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax

724-746-0746 • Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence,

PA 15055-1018 • Web site: www.blackbox.com • E-mail: info@blackbox.com

Customer

Support

Information

March 2009

codes codes

WRT4001A WRT4011A WRT4001A-DC WRT4000-DIN

WRT4002A WRT4012A WRT4002A-DC WRT4000-PM

WRT4003A WRT4013A WRT4003A-DC WRT4000-ANT

WRT4004A WRT4014A WRT4004A-DC WRT4000-ANT-KIT

Page 2 724-746-5500 | blackbox.com

WRT4000 Series Cellular Wireless Router Quick Start Guide

STEP A: Collect the Items Needed for Installation

1A. Get everything out of the shipping box. It should contain:

• This Quick Installlation Guide

• WRT4000 Series Cellular Wireless Router1

• DC connector set or AC power adapter

• Antennas included

2A. Get additional items required to install the WRT4000 Series Cellular Wireless Router.

You will need:

• Computer with Web-browsing software2

• Ethernet cable

• Subscriber Identity Module (SIM)3

• Cellular wireless network account3

NOTES:

1This quick installation guide assumes that there will be one embedded cellular module.

2JavaScript must be enabled in the Web browser.

3The embedded cellular module must have a cellular wireless network account and a Subscriber

Identity Module (SIM) for that account. Order each SIM from a cellular wireless network provider.

SIMs are not shipped with the Router.

STEP B: Ports on the WRT4000 Series Cellular Wireless Router Chassis

USB

Port

Industrial model: left slot: installed

card with (2) serial ports;

Commercial model: empty slots

LEDs for

Power and

Status

LEDs (not

used)

LEDs for signal

strength for

internal wireless

module

Main antenna port for

internal wireless module

Figure 1. Front panel.

Page 3

724-746-5500 | blackbox.com

WRT4000 Series Cellular Wireless Router Quick Start Guide

Auxiliary antenna port

for internal wireless module

Port for AC power

adapter input

Ethernet WAN port (eth 0)

Ethernet LAN ports (eth 1)

Figure 2. WRT4000 Series Router back panel, AC power.

Auxiliary antenna port

for internal

wireless module DC power connector

Ethernet WAN port (eth 0)

Ethernet LAN ports (eth 1) Port for AC power

adapter input

Figure 3. WRT4000 Series Router back panel, DC power.

STEP C: Install the SIMs

1C. Make sure the WRT4000 Series Cellular Wireless Router is not connected to a power

source. Then make sure no cables are connected to the router's ports.

2C. Place the router chassis on a flat, stable surface. Turn the chassis over so that it is

resting on its top.

3C. Remove the screws from the sides of the chassis, and lift the chassis shell off the

bottom of the chassis. Locate the SIM slot 3 socket's on the bottom of the mother-

board.

4C. Swing a SIM slot 3 socket'ss hinged door open. Insert a SIM between the guides on

the SIM socket‘s door, and slide the SIM into place.

Contact pad on back of SIM Contact pads on bottom plate of SIM socket

Figure 4. SIM partially inserted into the SIM socket‘s door.

5C. Gently close the SIM socket‘s door.

Page 4 724-746-5500 | blackbox.com

WRT4000 Series Cellular Wireless Router Quick Start Guide

CAUTION: If the SIM is not in the correct position, the SIM socket‘s door will not close. In

that case, remove the SIM and re-insert it in the correct position.

If the SIM is positioned

incorrectly, the SIM socket’s

door will not close

If the SIM is positioned

correctly, the SIM socket’s

door can close

Figure 5. SIM in an incorrect position. Figure 6. SIM in the correct position

6C. Re-assemble the router chassis. Attach antennas to the antenna ports on the chassis‘

front and back panels.

NOTE: The antenna ports labeled MAIN 1 (on the front panel) and AUX 1 (on the back

panel) hold antennas for the embedded module.

STEP D: Connect and Start the WRT4000 Series Cellular Wireless Router

1D. Connect an Ethernet cable between the computer‘s Ethernet port and one of the

Local Area Network ports (the set of LAN ports labeled “eth 1” on the back of the

router.

2D. To connect safely to DC power, follow the instructions in STEP E. To use only AC

power, connect the AC power adapter to the router chassis, then to an AC outlet.

(The chassis powers up immediately upon connection.) Then go to STEP F.

STEP E: Quick Connection to DC Power

For WRT4000 Series Cellular Wireless Routers that use DC power (part numbers

WRT4001A-DC, WRT4002A-DC, WRT4003A-DC, and WRT4004A-DC), the DC mating

connector is supplied. To connect your router to a power source, follow these instructions:

1E. Verify that the intended DC power source is the same as the input DC power indicated

on the unit. The routers have 24-VDC input voltage,

12V 1.2A

— — —

− +

Figure 7.12-VDC power input socket.

2E. Note the following (with connector orientation as shown):

Page 5

724-746-5500 | blackbox.com

WRT4000 Series Cellular Wireless Router Quick Start Guide

• The right position is + (for the positive wire).

• The left position is - (for the negative/return wire).

− negativ

+ positive

- negative

+ positive

Figure 8. DC power connector with wires.

3E. Use a minimum 16 AWG wire with strip length of 0.27" (7 mm) to connect to each

position.

4E. Install a cable tie through the holes on the bottom of the shell assembly and around

the power cables, as shown.

5E. Install the snap-on cover, and plug the DC power connector assembly into the DC

power socket on the back of the router chassis.

Figure 9. Top section of shell above cabled lower shell assembly.

6E. If an AC adapter is also used to power the router, plug the AC barrel connector into

the mating socket labeled +5V.

Page 6 724-746-5500 | blackbox.com

WRT4000 Series Cellular Wireless Router Quick Start Guide

STEP F: Login to the WRT4000 Series Cellular Wireless Router

1F. On the computer, open a Web browser. In the browser‘s address field, type the

router‘s default LAN IP address (192.168.1.1) and press the Enter key. Accept cookies for

the WRT4000 Series Cellular Wireless Router management system.

2F. When the browser displays the WRT4000 Series Cellular Wireless Router system login

screen, type the default user name (root) and password (blackbox!1). Then press the

Enter key or click the screen‘s button to Log In (at the far right, below the entry fields).

Figure 10. WRT4000 Series Cellular Wireless Router system login screen.

STEP G: Activate the Modules on the Cellular Networks

1G. If the SIM package did not include instructions, go to STEP 5G.

2G. If the SIM package included instructions to configure the Access Point Name (APN),

select the “Network” tab, then the “Interfaces” tab.

3G. On the Interface Overview screen, identify the row for the cellular wireless module,

and select the Edit button near the right side of the module‘s row.

4G. On the module‘s Interface Configuration Screen, select the correct Protocol and

Service Type; then type the APN as shown on the SIM package. Leave the other fields

as they are.

5G. Leave the chassis powered up for 30 minutes to allow automatic over-the-air (OTA)

activation to occur.

STEP H: Log Out of the WRT4000 Series Cellular Wireless Router

To close the WRT4000 Series Cellular Wireless Router management session, select the tab

to “Log Out.”

NOTE: If the management system is unattended for several minutes, the session will log

out automatically. To resume management, log in again.

Page 7

724-746-5500 | blackbox.com

NOTES

Black Box Tech Support: FREE! Live. 24/7.

Tech support the

way it should be.

Great tech support is just 60 seconds away at

724-746-5500 or blackbox.com.

724-746-5500 | blackbox.com

About Black Box

Black Box provides an extensive range of networking and infrastructure products.

You’ll find everything from cabinets and racks and power and surge protection

products to media converters and Ethernet switches all supported by free, live 24/7

Tech support available in 60 seconds or less.

are registered trademarks of BB Technologies, Inc. Any third-party trademarks appearing in this manual

are acknowledged to be the property of their respective owners.

WRT4000-Series-Cellular-Wireless-Routers-Quick-Start-Guide, version 1
