Black Box Fiber Meter Manuel utilisateur

1000 Park Drive • Lawrence, PA 15055-1018 • 724-746-5500 • Fax 724-746-0746

MAY 2003

TS1250A

Fiber Meter

CUSTOMER SUPPORT INFORMATION

Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)

FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746

Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018

Web site: www.blackbox.com • E-mail: [email protected]

PRECAUTIONS FOR HANDLING FIBEROPTIC CABLING

Precautions for Handling Fiberoptic Cabling

Observe the following precautions when handling fiberoptic

cabling:

• Fibers can be broken by poor handling, especially at

connectors.

• Dirt is harmful to fiberoptic connectors.

• Clean the ends of connectors with alcohol cleaning pads

before testing or reassembling equipment.

• Do not bend fibers too tightly, especially near connectors.

• Do not drop connectors on hard surfaces.

• Do not touch the ends of the connectors with your fingers.

• Do not leave connectors without dust caps.

FIBER METER

TRADEMARKS USED IN THIS MANUAL

ST is a registered trademark of American Telephone

and Telegraph Company.

Windows and Windows NT are either registered

trademarks or trademarks of Microsoft Corporation in

the United States and/or other countries.

Any other trademarks mentioned in this manual are

acknowledged to be the property of the trademark owners.

CONTENTS

Contents

Chapter Page

1. Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

1.1 Test Standards . . . . . . . . . . . . . . . . . . . . . . . . 7

1.2 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2. Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.1 Description . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.2 What the Package Includes . . . . . . . . . . . . . 10

2.3 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.4 The Handset. . . . . . . . . . . . . . . . . . . . . . . . . 13

2.5 Battery Information . . . . . . . . . . . . . . . . . . . 15

2.5.1 Low Battery Message. . . . . . . . . . . . . 16

2.5.2 Changing the Batteries. . . . . . . . . . . 16

2.5.3 Recharging the NiMH

Battery Pack. . . . . . . . . . . . . . . . . . . . 17

2.6 Changing Performance Modules . . . . . . . . 18

3. Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

3.1 Set the Test Mode . . . . . . . . . . . . . . . . . . . . 23

3.2 Set the Number of Connections. . . . . . . . . 24

3.3 Set the Number of Splices. . . . . . . . . . . . . . 25

3.4 Set the Core Diameter. . . . . . . . . . . . . . . . . 26

3.5 Set the Length Measurement Units . . . . . . 26

FIBER METER

Contents (continued)

Chapter Page

3.6 Set the PowerDown Time . . . . . . . . . . . . . . 26

3.7 Adjust the Backlighting Time . . . . . . . . . . . 27

3.8 Set the Power Frequency. . . . . . . . . . . . . . . 28

3.9 Set the Baud Rate. . . . . . . . . . . . . . . . . . . . . 29

3.10 Set the Flow Control . . . . . . . . . . . . . . . . . . 29

3.11 Set the Date . . . . . . . . . . . . . . . . . . . . . . . . . 30

3.12 Set the Time . . . . . . . . . . . . . . . . . . . . . . . . . 30

3.13 Set Audible Tones . . . . . . . . . . . . . . . . . . . . 31

3.14 Set the Circuit Names . . . . . . . . . . . . . . . . . 32

3.15 Set the Company Name. . . . . . . . . . . . . . . . 34

3.16 Reset to Defaults . . . . . . . . . . . . . . . . . . . . . 35

4. Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

5. Autotest . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

5.1 Set the Loss Budget . . . . . . . . . . . . . . . . . . . 40

5.2 Set the Reference Power . . . . . . . . . . . . . . . 41

5.2.1 OFSTP-14A Method B Reference . . 43

5.2.2 OFSTP-14A Method A Reference . . 46

5.3 Autotest Optical Power Measurements . . . 49

5.4 Autotest Using One-Way Testing . . . . . . . . 50

CONTENTS

Chapter Page

5.5 Autotest Using Two-Way Testing . . . . . . . . 54

5.6 Changing the Cable Test Standard . . . . . . 56

5.7 Save Autotest Results . . . . . . . . . . . . . . . . . . 57

5.8 Enter a Circuit Identification Name. . . . . . 60

6. Extended Functions . . . . . . . . . . . . . . . . . . . . . . . 61

6.1 LinkTalk . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

6.2 Manual Power Meter . . . . . . . . . . . . . . . . . . 63

6.3 Manual LED Source . . . . . . . . . . . . . . . . . . 68

6.4 Manual Multimode Loopback

Measurements . . . . . . . . . . . . . . . . . . . . . . . 69

6.5 Self-Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

6.6 Download Firmware. . . . . . . . . . . . . . . . . . . 72

6.7 Upload Reports . . . . . . . . . . . . . . . . . . . . . . 72

7. Test Results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

7.1 View Test Reports . . . . . . . . . . . . . . . . . . . . 73

7.2 Print Test Reports . . . . . . . . . . . . . . . . . . . . 74

7.3 Sample Autotest Reports . . . . . . . . . . . . . . . 76

7.4 Delete Test Reports . . . . . . . . . . . . . . . . . . . 79

7.5 Change Serial Port Settings. . . . . . . . . . . . . 80

FIBER METER

Contents (continued)

Chapter Page

Appendix. Report Manager . . . . . . . . . . . . . . . . . . . 83

A.1 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . 83

A.1.1 System Requirements . . . . . . . . . . . . 83

A.1.2 Installation Procedure . . . . . . . . . . . 83

A.2 Report Manager Components . . . . . . . . . . 84

A.2.1 Menus . . . . . . . . . . . . . . . . . . . . . . . . 84

A.2.2 Toolbar . . . . . . . . . . . . . . . . . . . . . . . 85

A.2.3 Status Bar. . . . . . . . . . . . . . . . . . . . . . 86

A.2.4 Help . . . . . . . . . . . . . . . . . . . . . . . . . . 86

A.3 Setting Up Report Manager . . . . . . . . . . . . 87

A.3.1 Detecting the COM Port . . . . . . . . . 87

A.3.2 Connecting the Fiber Meter

to a PC . . . . . . . . . . . . . . . . . . . . . . . . 88

A.4 Using Report Manager . . . . . . . . . . . . . . . . 89

A.4.1 Upload Test Reports. . . . . . . . . . . . . 89

A.4.2 View Test Reports . . . . . . . . . . . . . . . 92

A.4.3 Print Test Reports. . . . . . . . . . . . . . . 93

A.4.4 Save Test Reports to Disk . . . . . . . . . 93

A.4.5 Load Test Reports from Disk. . . . . . 95

A.4.6 Download Firmware

to the Fiber Meter. . . . . . . . . . . . . . . 95

CHAPTER 1: Specifications

1. Specifications

1.1 Test Standards

Test Standard 850 nm 1300 nm Propagation Length

TIA 568A Horizontal 2.0 dB 2.0 dB N/A 90 m

(62.5 µm and 50 µm)

TIA 568A Backbone Equation 1 Equation 2 N/A 2000 m

(62.5 µm)

IEC 11801 Horizontal Equation 3 Equation 4 N/A 500 m

(62.5 µm and 50 µm)

IEC 11801 Backbone Equation 3 Equation 4 N/A 90 m

62.5 µm and 50 µm)

1000BASE-SX 62.5 µm 2.53 dB N/A N/A 275 m

1000BASE-SX 50 µm 3.43 dB N/A N/A 550 m

1000BASE-LX N/A 2.32 dB N/A 550 m

Equation 1: Max Loss = (# of mated connectors x 0.75) + (# of splices x 0.3) + (length x

3.75 dB/km)

Equation 2: Max Loss = (# of mated connectors x 0.75) + (# of splices x 0.3) + (length x

1.5 dB/km)

Equation 3: Max Loss = (# of mated connectors x 0.75) + (# of splices x 0.3) + (length x

3.5 dB/km)

Equation 4: Max Loss = (# of mated connectors x 0.75) + (# of splices x 0.3) + (length x

1.0 dB/km)
