Parts Identiﬁcation

1. Handle

2. Spray button

3. Spray nozzle

4. Water tank cover

5. Steam control

6. Steam burst button

7. Self clean

8. Temperature control dial

9. Heating indicator light

10. Sole plate

11. Heel rest

ENGLISH

Intended use

Your Black & Decker iron has been designed

to remove creases from fabrics using heat &

steam and is not to be used for any other

purpose.

This appliance is intended for use in

household and similar applications such as:

sta kitchen areas in shops, oces and

other working environments; farm houses;

by clients in hotels, motels and other

residential type environments;

bed and breakfast type environments. This

product is not intended for regular use

Read this entire manual carefully

before using the appliance.

Denotes the risk of electric shock.

Safety instructions

Warning! When using mains-powered

appliances, basic safety precautions,

including the following, should always be

followed to reduce the risk of ﬁre, electric

shock, personal injury and material damage.

• The intended use is described in this

manual. The use of any accessory or

attachment or the performance of any

operation with this appliance other than

those recommended in this instruction

manual may present a risk of personal

injury.

• Retain this manual for future reference.

• Always route the cord carefully to avoid

a tripping hazard.

• Never operate an appliance directly

below the socket-outlet it is connected

to.

Using your appliance

• Always take care when using the

appliance.

• Do not use the appliance outdoors.

• Do not operate the appliance if your

hands are wet. Do not operate the

appliance if you are barefoot.

• Guide the power supply cord neatly so it

does not hang over the edge of a

worktop and cannot be caught

accidentally or tripped over.

• Never pull the power supply cord to

disconnect the plug from the socket.

Keep the power supply cord away from

heat, oil and sharp edges.

• If the power supply cord is damaged

during use, disconnect the appliance from

the power supply immediately. Do not

touch the power supply cord before

disconnecting from the power supply.

• Disconnect the appliance from the power

supply when not in use and before

cleaning.

Safety of others

• This appliance is not intended for use by

persons (including children) with reduced

physical, sensory or mental capabilities,

or lack of experience and knowledge,

unless they have been given supervision

or instruction concerning use of the

appliance by a person responsible for

their safety.

• Children should be supervised to ensure

that they do not play with the appliance.

ENGLISH

• Do not allow children or any person

unfamiliar with these instructions to use

the appliance.

• Do not allow children or animals to come

near the work area or to touch the

appliance or power supply cord.

• Close supervision is necessary when the

appliance is used near children.

After use

• Switch oﬀ and remove the plug from the

socket before leaving the appliance

unattended and before changing,

cleaning or inspecting any parts of the

appliance.

• When not in use, the appliance should be

stored in a dry place. Children should not

have access to stored appliances.

Inspection and repairs

• Before use, check the appliance for

damaged or defective parts. Check for

breakage of parts, damage to switches

and any other conditions that may aect

its operation.

• Do not use the appliance if any part is

damaged or defective.

• Have any damaged or defective parts

repaired or replaced by an authorised

repair agent.

• Before use, check the power supply cord

for signs of damage, ageing and wear.

• Do not use the appliance if the power

supply cord or mains plug is damaged or

defective.

• If the power supply cord or mains plug is

damaged or defective it must be

repaired by an authorised repair agent in

order to avoid a hazard. Do not cut the

power supply cord and do not attempt to

repair it yourself.

• Never attempt to remove or replace any

parts other than those speciﬁed in this

manual.

• Do not attempt to repair the appliance.

Take it to your nearest Black &

Decker-owned or authorised Service

Centre for repair.

Electrical safety

This product must be earthed.

Always check that the power

supply corresponds to the voltage on the

rating plate.

• Power plugs must match the outlet.

Never modify the plug in any way. Do not

use any adapter plugs with earthed

(Class 1) appliances. Unmodiﬁed plugs

and matching outlets will reduce the risk

of electric shock.

Extension cables & Class 1 product

• A 3-core cable must be used as your

appliance is earthed and of Class 1

construction.

• Up to 30m (100ft) can be used without

loss of power.

To avoid the risk of electric

shock, do not immerse the cord,

plug or appliance in water or

other liquid.

• If the supply cord is damaged, it must be

replaced by the manufacturer or an

authorized Black & Decker Service

Center in order to avoid a hazard.

ENGLISH

Additional safety instructions for

irons

• Always route the cord carefully to avoid

a tripping hazard.

• Do not use the appliance near water.

• Do not place the appliance near heat

sources or directly under cabinets. Do

not use the appliance in the presence of

explosive or ﬂammable materials.

• The ﬁlling aperture must not be opened

during use.

• Steam may escape from the soleplate.

• Surfaces may be hot during use and

during the cool down period.

• Set the temperature control dial to the

min position before plugging in or out.

• Let the appliance cool down before

leaving it unattended and before

cleaning or inspecting any parts of the

appliance.

• The power supply cord should not touch

the hot soleplate during use or during

the cool down period.

• Do not touch the soleplate until it has

cooled down.

• Wait until the appliance has cooled down

before emptying the water tank as the

water may still be hot.

• Do not immerse the appliance, cored set

or plug in liquids

• Always disconnect the appliance from

the supply before ﬁlling, emptying,

cleaning, or carrying out any

maintenance on the appliance.

• The iron must not be left unattended

while it is connected to the supply mains

• The plug must be removed from the

socketoutlet before the water reservoir is

ﬁlled with water.

• The iron must be used and rested on a

stable surface.

• The iron is not to be used if it has been

dropped, if there are visible signs of

damage or if it is leaking.

Caution : Hot Surface.

Before ﬁrst use

• Remove all packaging from the

appliance.

• Clean the appliance before ﬁrst use.

Warning! Before ﬁlling the appliance, make

sure that the appliance is switched o and

unplugged.

Filling the water tank

In order to be able to use the steam

function, you will ﬁrst need to ﬁll the water

tank with water.

• Make sure that the appliance is

unplugged.

• Set the steam control to the no steam

position.

• Hold the appliance at an angle.

• Fill the appliance with water using the

beaker provided.

Warning! Never ﬁll above the maximum

ﬁlling level indicated on the beaker

provided. Normal tap water can be used,

but if you live in a hard water area the use

of distilled water is recommended. Do not

use chemically de-scaled water.

Use

Warning! Do not leave the appliance

unattended while it is connected to the

power supply and during the cool down

period.

Temperature setting

The required temperature setting depends

on the garment fabric.

• Adjust the temperature control dial to

the required setting:

- •Synthetics

- •• Silk/wool

- ••• Cotton/Linen

If you are unsure of the ﬁber content of a

garment: start with a low temperature

setting and test on a small area (seam or

inside hem). If wrinkles remain, gradually

increase the heat setting until you ﬁnd the

optimum setting.

Using as a dry iron

• Stand the appliance on its heel rest.

• Plug the appliance in and switch on.

• Set the steam control to the no steam

position.

• Adjust the temperature control dial to

the required setting.

The heating light will switch o when the

appliance has reached the required

temperature.

Using as a steam iron

• Fill the water steam tank as described

above.

• Stand the appliance on its heel rest.

• Adjust the temperature control dial to

the required steam setting.

• Plug the appliance in and switch on.

• The heating light will switch on.

Readiness for use is indicated by the

colour of the heating light.

• To create steam, set the steam control to

the steam position.

Using the steam burst button

The steam burst feature can only be used

whilst ironing on a high temperature setting.

• Make sure that there is water in the tank

and the temperature control dial is set to

the high steam position.

• Lift the appliance and press the steam

burst button. You may need to press a

few times to activate the pump.

Self Clean

The self-clean function must be used before

using the appliance for the ﬁrst time and

then regularly to remove scale.

• Fill the tank to the maximum ﬁlling level.

• Set the temperature control dial to the

max position.

ENGLISH

• Plug the appliance in and switch on.

• Allow the appliance to heat up until the

heating light switches o and then on

again.

• Unplug the appliance and hold it

horizontally over the sink.

• Press the self-clean button

Warning! Hot water and steam will come

out of the vents. Impurities and scale will be

washed away.

• Move the iron backwards and forwards

while this is happening.

• Release the self-clean button.

• Stand the appliance upright on its heel

rest.

• Plug the appliance in and switch on.

• Iron an old cloth or towel to dry the

soleplate.

Using the spray button

The spray feature can be used at any

temperature setting when either steam or

dry ironing.

• Make sure that there is water in the spray

water tank.

• Press the spray button several times to

activate the pump while you are ironing.

Anti-drip

This iron is equipped with a anti drip

function: the iron automatically stops

steaming when the temperature is too low

to prevent water from dripping out of the

soleplate.

Anti-calc

The Anti-calc function ﬁlters the minerals

from the water to prevent mineral residue

build up in the steam chamber.

Automatic shut o

If the iron is switched on and not moved for

a period of 8 minutes while standing on its

heel or 30 seconds while standing on the

soleplate, an internal safety feature will

switch the iron o and the auto-shuto

indicator will blink. Move the appliance

sharply to switch it on again.

Heating indicator light

When the iron is switched on the heating

indicator light will light up to reﬂect the

temperature of the iron.

The temperature is indicated by the colour

of the heating light:

Blue On

Green • Cool Synthetics

Yellow •• Warm Silk, wool

Purple ••• Hot Cotton, linen

Red Max Denim

Cleaning and maintenance

Before cleaning and maintenance, remove

the plug from the socket and allow the

appliance to cool.

Warning! Before cleaning and maintenance,

switch the appliance o, remove the plug

from the socket and allow the appliance to

cool.

Warning! Do not immerse the appliance, the

cord set or the plug in water or any other

liquid.

ENGLISH

• Pour out any remaining water after each

use by tilting the appliance forward.

• Wipe the exterior with a damp cloth.

• Wipe scale and other residues oﬀ the

soleplate with a damp cloth.

• Do not use scouring pads.

• If necessary, use a mild detergent to

remove spots.

• Do not use any abrasive or solvent based

cleaner.

• Do not immerse the appliance in water

or any other liquid.

X2210

Voltage/ Supply 220-240V 50/60Hz

Power consumption 2200-2600W

Weight 1.38kg

Technical data

Protecting the environment

Separate collection. This product

must not be disposed of with normal

household waste.

Should you ﬁnd one day that your Black &

Decker product needs replacement, or if it is

of no further use to you, do not dispose of it

with household waste. Make this product

available for separate collection.

• Black & Decker provides a facility for

recycling Black & Decker products once

they have reached the end of their

working life. This service is provided free

of charge. To take advantage of this

service, please return your product to

any authorised repair agent who will

collect them on our behalf.

• You can check the location of your

nearest authorised repair agent by

contacting your local Black & Decker

oﬃce at the address indicated in this

manual. Alternatively, a list of authorized

Black & Decker repair agents and full

details of our after-sales service and

contacts are available on the Internet at:

www.2helpU.com.

ENGLISH

Warranty

Black & Decker is conﬁdent of the quality of

its products and oﬀers an outstanding

warranty.

This warranty statement is in addition to and

in no way prejudices your statutory rights.

The warranty is valid within the territories of

the Member States of the European Union

and the European Free Trade Area.

If a Black & Decker product becomes

defective due to faulty materials,

workmanship or lack of conformity, within

24 months from the date of purchase, Black

& Decker warranty to replace defective

parts, repair products subjected to fair wear

and tear or replace such products to ensure

minimum inconvenience to the customer

unless:

The product has been used for

trade, professional or hire

purposes;

The product has been subjected to

misuse or neglect;

The product has sustained damage

through foreign objects,

substances or accidents;

Repairs have been attempted by

persons other than authorised

repair agents or Black & Decker

service staﬀ.

To claim on the warranty, you will need to

submit proof of purchase to the seller or an

authorised repair agent. You can check the

location of your nearest authorised repair

agent by contacting your local Black &

Decker oﬃce at the address indicated in this

manual.

Alternatively, a list of authorised Black &

Decker repair agents and full details of our

after-sales service and contacts are available

on the Internet at: www.2helpU.com.

FRANÇAIS

Identiﬁcation des pièces

1. Poignée

2. Touche pulvérisation

3. Buse de pulvérisation

4. Couvercle du réservoir

5. Sélecteur de vapeur

6. Touche jet de vapeur

7. Auto-nettoyage

8. Cadran de réglage de la température

9. Voyant lumineux de contrôle de chauﬀe

10. Semelle

11. Socle

Table des matières

Langues :

Autres manuels Black & Decker Fer

Black & Decker

Black & Decker The Classic F63E Instructions d'installation

Black & Decker

Black & Decker XT1820 Manuel utilisateur

Black & Decker

Black & Decker Quick 'N Easy IM310 Instructions d'installation

Black & Decker

Black & Decker First Impressions ICR200 Series Instructions d'installation

Black & Decker

Black & Decker SteamXpress AS675 Instructions d'installation

Black & Decker

Black & Decker Surge Xpress F855 Instructions d'installation

Black & Decker

Black & Decker D2530 Manuel utilisateur

Black & Decker

Black & Decker Steam Xpress AS255 Instructions d'installation

Black & Decker

Black & Decker D2000 Series Instructions d'installation

Black & Decker

Black & Decker AS202 Instructions d'installation

Black & Decker

Black & Decker XPRESS STEAM IR08X Instructions d'installation

Black & Decker

Black & Decker X50 Instructions d'installation

Black & Decker

Black & Decker D2030 Manuel utilisateur

Black & Decker

Black & Decker SteamXpress AS200 Instructions d'installation

Black & Decker

Black & Decker The Classic F67E Instructions d'installation

Black & Decker

Black & Decker SteamXpress AS675 Instructions d'installation

Black & Decker

Black & Decker AvantSTEAM AS430 Manuel utilisateur

Black & Decker

Black & Decker F394S Instructions d'installation

Black & Decker

Black & Decker IR0820C Manuel utilisateur

Black & Decker

Black & Decker D905 Instructions d'installation

Black & Decker

Black & Decker X1030 Manuel utilisateur

Black & Decker

Black & Decker SteamAdvantage F2000 Instructions d'installation

Black & Decker

Black & Decker IR04VC Manuel utilisateur

Black & Decker

Black & Decker Digital Edge D1690 Instructions d'installation

Manuels Fer populaires d'autres marques

Clatronic

Clatronic DB 3703 Manuel utilisateur

TEFAL

TEFAL FV4093Z0 Manuel utilisateur

Gorenje

Gorenje SIH 2200 BS Manuel utilisateur

Philips

Philips GC6012 Manuel utilisateur

Bosch

Bosch 2 Series Manuel utilisateur

Riffel

Riffel Catena KB-819 Manuel utilisateur

Texi

Texi Hestia Manuel utilisateur

Maxwell

Maxwell MW-3010 Manuel utilisateur

TREVIDEA

TREVIDEA Girmi ST60 Manuel utilisateur

Philips

Philips HI5914/30 Manuel utilisateur

Primula

Primula Vapormat Manuel utilisateur

Magio

Magio MG-541 Manuel utilisateur

Scarlett

Scarlett SC-1334S Manuel utilisateur

Bosch

Bosch Sensixx B22L Manuel utilisateur

Philips

Philips GC651 Manuel utilisateur

Vitek

Vitek VT-1247 VT Manuel utilisateur

Cleanmaxx

Cleanmaxx 3397 Manuel utilisateur

Philips

Philips GC800 Manuel utilisateur
