Black & Decker SPACEMAKER SCM2000BD Manuel utilisateur
TM
8-CUP THERMAL
UNDER THE
CABINET
COFFEEMAKER
CAFETERA TÉRMICA
DE 8 TAZAS PARA
INSTALAR DEBAJO
DEL GABINETE
CAFETIÈRE THERMIQUE
DE 8 TASSES POUR
INSTALLATION SOUS
UNE ARMOIRE
SPACEMAKER
use & care manual guide d’utilisation et d ’entretien manual de uso y cuidado
SCM2000BD
2
Should you have any questions or concerns with your new product, please
call our Customer Service Line at 1-800-231-9786 (US and Canada). Please
do not return to the store.
Si usted tiene alguna inquietud o pregunta con su producto, por favor llame
a nuestra línea de servicio al cliente una atención inmediata 1-800-231-9786
(EE.UU/Canadá) 01-800-714-2503 (México). No devuela a la tienda.
Si vous avez des questions ou des préoccupations à propos de votre
nouveau produit, veuillez communiquer avec notre Service à la clientèle au
1 800 231-9786 (États-Unis et Canada). Veuillez ne pas rapporter le produit
au magasin.
Thank you for your purchase!
Gracias por su compra!
Merci de votre achat!
3
CONTENTS
Table of Contents ................................................. 3
Important Safeguards ............................................. 4
Getting to Know Your Coffeemaker ................................. 5
Installation Hardware .............................................. 6
Installing your SpaceMaker™ ....................................... 7
Programming Your Coffemaker ..................................... 10
Auto Brew Delay .................................................. 11
Before Brewing ................................................... 11
Brewing Coffee ................................................... 12
Care and Cleaning .................................................13
Troubleshooting ..................................................14
Warranty and Customer Service Information ......................... 15
WELCOME!
Congratulations on your purchase of the Black+Decker SpaceMaker™
8 Cup Thermal Coffeemaker. We have developed this guide to ensure
optimal product performance and your complete satisfaction.
Save this use and care manual and be sure to register your appliance
online at www.prodprotect.com/applica.
SAVE THESE INSTRUCTIONS.
4
• Do not use appliance for other than
intended use.
• Close supervision is necessary when any
appliance is being used by or near children.
• Do not touch hot surfaces. Use handles or
knobs.
• Keep lid on the carafe during the brewing
cycle. Scalding may occur if it is removed.
• To reduce the risk of fire or electric shock:
• Do not let cord hang over edge of table
or counter, or touch hot surfaces.
• Do not place on or near a hot gas or
electric burner or in a heated oven.
• Do not mount this unit over or near any
portion of a heating or cooking appliance.
• Do not place any heating or cooking
appliance beneath this appliance.
• Do not store anything directly on top of
the appliance surface.
• Do not immerse cord, plugs or appliance
in water or other liquid.
• Do not mount over a sink.
• The use of accessory attachments not
recommended by the manufacturer may
result in fire, electrical shock or other injury.
• Unplug from outlet when not in use and
before cleaning. Allow to cool before putting
on or taking off parts.
• To disconnect, turn all controls to OFF, then
remove plug from wall outlet.
• Do not use outdoors.
• This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
• Do not operate any appliance with
a damaged cord or plug or after the
appliance malfunctions, has been dropped,
or damaged in any manner. Call the
appropriate toll-free number listed in this
manual.
PLEASE READ AND SAVE THIS USE AND CARE BOOK.
IMPORTANT SAFEGUARDS.
When using electrical appliances, always follow basic safety precautions to
reduce the risk of fire, electric shock, and/or injury, including the following:
SAVE THESE INSTRUCTIONS.
This product is for household use only.
GROUNDED PLUG
As a safety feature, this product is equipped
with a grounded plug, which will only fit into
a three-prong outlet. Improper connection of
the grounding conductor may result in the
risk of electric shock. Consult a qualified elec-
trician if you are unsure whether the outlet is
properly grounded.
TAMPER-RESISTANT SCREW
A tamper-resistant screw secures the outer
cover. To reduce the risk of fire or electric
shock, do not attempt to remove this screw or
the outer cover. There are no user-serviceable
parts inside. Repairs should be completed by
authorized service personnel only.
ELECTRICAL CORD
1) A short power-supply cord is provided to
reduce the risk resulting from becoming
entangled in or tripping over a longer cord.
2) Longer detachable power-supply cords or
extension cords are available and may be
used if care is exercised in their use.
3) If a long detachable power-supply cord or
extension cord is used:
a) The marked electrical rating of the exten-
sion cord should be at least as great as
the electrical rating of the appliance,
b) If the appliance is of the grounded type,
the extension cord should be a ground-
ing-type 3-wire cord, and
c) The longer cord should be arranged so
that it will not drape over the countertop
or tabletop where it can be pulled on by
children or tripped over.
SAFETY FEATURES
5
1
3
2
6
4
5
7
1. Brew basket
(Part # SCM003)
2. Sneak-A-Cup™ interrupt feature
3. Thermal carafe with lid
(Part # SCM002)
4. Keep hot carafe plate
5. Illuminated water reservoir with
water-level markings
(Part # SCM004)
6. Reservoir lid
(not shown)
7. Digital display
8. Control panel
9. Cord management hook
(not shown)
10. Plug receptacle
(not shown)
Product may vary slightly from what is illustrated.
GETTING TO KNOW YOUR
SPACEMAKER™ 8 CUP THERMAL COFFEEMAKER
6
SPACERS
SCREWS
WASHERS
INSTALLATION HARDWARE
• Mounting Parts
(Part # SDC-MOUNTING KIT)
16 Spacers
4: 1⁄2"
4: 1⁄4"
4: 3⁄16"
4: 1⁄16"
12 Screws
4: 1"
4: 1 3⁄4"
4: 2 1⁄4"
4 Washers
• Mounting Template (in box)
You will also need:
• Tape
• Ruler
• Electric drill with a 1⁄4" drill bit
and a 1⁄32" drill bit
• Screwdriver
• Protective glasses
• A second person
Note: The use of all provided mounting hardware may not be
necessary in the installation of all SpaceMaker™ products.
7
GETTING STARTED
• Carefully unpack your coffeemaker, removing all packaging materials,
labels and/or stickers, and the plastic band around the power plug.
• Register your product at www.prodprotect.com/applica
• Remove and save literature.
• Remove mounting hardware and template. Set them safely aside.
• For warranty verifi cation, do not remove cord tag.
Do not attempt to operate appliance until properly installed.
INSTALLING YOUR SPACEMAKER™
CHOOSE A LOCATION
When choosing your location, consider the following:
• DO make sure to mount within reach of an electrical outlet.
• DO consider your normal work patterns in the kitchen when choosing location.
• DO NOT mount over any heating or cooking appliance such as your range or
oven.
• DO NOT mount over or near a sink.
• DO NOT mount under, in front of or behind any under-cabinet light
fi xtures.
Note: If you are mounting multiple SpaceMaker™ appliances, they should
not be mounted fl ush to one another. Allow at least 1" of space between
appliances and 4" of space if you are installing a toaster oven. This is
necessary for adequate cooling.
Note: This appliance may feature a Save-A-Plug™ outlet receptacle to
connect smaller SpaceMaker™ appliances. Do not use this outlet for any
other purpose!
If you are connecting this appliance to the receptacle of another
SpaceMaker™ appliance such as the toaster oven or coffeemaker, make
sure you can easily unplug the appliance following use.
DETERMINE CABINET TYPE
Important: SpaceMaker™ appliances are only recommended to be installed
on cabinets without a top lip and with a fl at bottom. It is not recommended
to install SpaceMaker™ appliances on cabinets with an overhang. See image
below for recommended cabinet types.
FLAT BOTTOM TOP LIP OVERHANG
8
STANDARD INSTALLATION FOR FLAT CABINETS ONLY
Important: Always wear protective glasses or goggles to prevent injury
when drilling.
Important: Do not align screw holes on the template directly under the
partition between cabinets, as this will prevent you from installing the
appliance properly. Pay close attention to where drill holes will be set so as
not to damage your cabinets during mounting. Drilling through your cabinet’s
partition may cause damage to cabinets and prevent proper installation.
1. Clear countertop under installation area to avoid getting dust or
debris on other appliances or items. Open cabinets and remove
contents to make mounting easier.
2. Clean both the underside and topside of the bottom panel of the
cabinet.
3. Decide whether you will be drilling from the top down or from the
bottom up.
IF DRILLING FROM THE BOTTOM UP:
a. With cabinet doors open, place mounting
template against the surface of the front
edge of your cabinet. Align the thick line
on the template (labeled “cabinet front
edge”) with the lower front edge of your
cabinet (D).
b. Fold the balance of the template up
along the underside of your cabinet,
ensuring the “cabinet front edge” line
remains aligned with the bottom front
cabinet edge.
c. Make sure the template is smooth and
fl ush against the cabinet’s underside. Pull
template tight and tape down to hold in
place.
IF DRILLING FROM THE TOP DOWN:
a. With cabinet doors open, place mounting
template against the surface of the front
edge of your cabinet. Align the thick line
on the template (labeled “cabinet front
edge”) with the upper front edge of your
cabinet (E).
b. Fold the balance of the template over into
the inside of your cabinet, ensuring the
“cabinet front edge” line remains aligned
with the upper front cabinet edge.
c. Make sure the template is smooth and
fl ush against the cabinet’s inside. Pull
template tight and tape down to hold in
place.
D
E
9
Important: Always ensure you are drilling straight
up or straight down through the marked mounting
holes on the template. Drilling at an angle may
prevent proper installation and may damage
cabinets if the drill bit pierces the partition.
4. Using a 1⁄32" drill bit, drill from the underside
of the cabinet up or the top down, creating
pilot holes through the 4 holes marked on
the template. This will help guide the ¼" drill
bit in the next step. (F)
5. Switch to a ¼" drill bit and drill straight up
or straight down through the holes that
have just been created. (G)
6. Once holes are drilled, remove tape and
mounting template.
7. Wipe dust and debris off the top side and
the underside of the cabinet surface.
8. Place a washer inside the cabinet over each
of the 4 holes you drilled. (H)
9. Determine what size screws to use by
placing a screw through the hole in
the cabinet without the appliance in
place. The screw should be ½" exposed
underneath the cabinet to ensure the
appliance is properly attached to the
cabinet. (I)
Note: Several standard screw lengths are
provided but may not fi t all cabinet sizes.
10. Place one of the screws through each of
the washers covering the holes in the
cabinet, from the inside of the cabinet
down.
11. Hold appliance up to the screws, aligning
the front of the appliance with the front
edge of the cabinet base. The screws in
the cabinet should align with the mounting
holes in the appliance. (J)
Note: It may require two people to ensure the
appliance is held in place while drilling.
12. Screwing from inside the cabinet down
into the appliance holes, use your drill or
screwdriver to tighten the four screws in
place. (K)
F
G
H
I
J
K
10
PROGRAMMING YOUR COFFEEMAKER
SETTING THE DIGITAL CLOCK
1. Plug your coffeemaker into a standard electrical outlet.
2. The entire digital clock will fl ash “12:00” to indicate that the time has
not yet been set.
3. Press the HOUR and MIN (minute) buttons until the correct time
appears on the display.
Note: A “PM” symbol will appear to indicate afternoon time settings.
This symbol will not appear for AM settings.
4. Your clock is now set.
SETTING THE AUTO BREW DELAY
1. Ensure the digital clock has been set (see “SETTING THE DIGITAL
CLOCK” section for assistance).
2. Press the PROG (program) button. The display will fl ash “12:00.”
3. Press the HOUR and MIN buttons until they indicate the time you
would like automatic brewing to begin.
Note: A “PM” symbol will appear in the upper right hand corner of
the digital display to indicate afternoon time settings. This symbol
will not appear for AM settings.
4. The Auto Brew display will fl ash for a few moments before switching
back to the digital clock.
TIP: After programming, press the PROG button to check the preset Auto
Brew time.
Note: Always tighten screws to properly secure
the appliance to the cabinet and to ensure
the appliance does not move or shake during
operation.
13. Pull out cord from cord storage behind the
appliance and plug into a standard electrical
outlet. Extra cord can be fed back into
storage or hung over cord management
hook behind the appliance. (L)
Note: If you are connecting this appliance to the receptacle of another
SpaceMaker™ appliance such as the toaster oven or coffeemaker, make sure
you can easily unplug the appliance following use.
14. Your SpaceMaker™ appliance is now ready for use!
L
Autres manuels pour SPACEMAKER SCM2000BD
1
Table des matières
Langues :
Autres manuels Black & Decker Cafetière
Black & Decker
Black & Decker DCM600BT Instructions d'installation
Black & Decker
Black & Decker MGD300 Manuel utilisateur
Black & Decker
Black & Decker DLX850B Manuel du propriétaire
Black & Decker
Black & Decker Spacemaker SDC740 Manuel du propriétaire
Black & Decker
Black & Decker Brew'N Go DCM16PK Instructions d'installation
Black & Decker
Black & Decker Brew 'N Go DCM18 Series Instructions d'installation
Black & Decker
Black & Decker DCM3200B Instructions d'installation
Black & Decker
Black & Decker DCM100B Instructions d'installation
Black & Decker
Black & Decker BCM1410BC Instructions d'installation
Black & Decker
Black & Decker DLX850 DLX900 Instructions d'installation
Black & Decker
Black & Decker Spacemaker SDC740 Manuel du propriétaire
Black & Decker
Black & Decker CM4500BD Manuel utilisateur
Black & Decker
Black & Decker CM2070B Instructions d'installation
Black & Decker
Black & Decker TCM400 Series Instructions d'installation
Black & Decker
Black & Decker CM1105B Manuel utilisateur
Black & Decker
Black & Decker CM5000BD Manuel utilisateur
Black & Decker
Black & Decker Home DCM3100B Instructions d'installation
Black & Decker
Black & Decker CM9050C Manuel utilisateur
Black & Decker
Black & Decker DCM100 Manuel utilisateur
Black & Decker
Black & Decker CM1110B Manuel utilisateur
Black & Decker
Black & Decker Home Cafe AM7 Instructions d'installation
Black & Decker
Black & Decker Cup-At-A-Time DCM7 Series Instructions d'installation
Black & Decker
Black & Decker Spacemaker ODC460 Instructions d'installation
Black & Decker
Black & Decker CAFE SELECT CM6000B Instructions d'installation
