BIXOLON BGT-100P Instructions d'installation et d'entretien

Network Manual

BGT-100P/102P

mPOS Thermal Printer

Rev. 1.00

http://www.bixolon.com

Network

Rev.1.00

- 2 -

■Table of Contents

1. Specifications.................................................................................................................3

2. How to Connect..............................................................................................................4

2-1 Initial Wireless LAN Connection (Windows 2000)....................................................5

2-2 Initial Wireless LAN Connection (Windows XP).......................................................5

2-3 Initial Wireless LAN Connection (Windows VISTA, Windows 7, 8, 10)..................10

3. Configuration ...............................................................................................................16

3-1 Web Browser.........................................................................................................18

3-2 FTP........................................................................................................................20

3-3 Telnet.....................................................................................................................22

4. SMTP.............................................................................................................................23

5. Factory Reset...............................................................................................................26

6. Troubleshooting...........................................................................................................28

Network

Rev.1.00

- 3 -

1. Specifications

(1) WLAN USB Adapter

BIXOLON printers require WLAN USB adapter to use the wireless LAN function.

WLAN USB Adapter for BIXOLON printers should be available from BIXOLON.

USB Adapter from market not BIXOLON is not guaranteed to be working properly with

BIXOLON printers.

(2) Ethernet(LAN) / WLAN Protocol

Layer

Protocol

Network Layers

ARP, IP, ICMP

Transport Layers

TCP, UDP

Application Layers

DHCP, DNS

Raw Print

SMTP (notify printer status)

HTTP, HTTPS (setting)

FTP (settings)

TELNET (settings)

(3) Ethernet Security

- HTTPS (SSL2.0, SSL3.0, TLS1.0)

(4) WLAN Security

- WEP64/128

- WPA/WPA2 (TKIP/AES-CCMP) PSK

- EAP(PEAP, FAST, LEAP, TTLS)

- HTTPS (SSL2.0, SSL3.0, TLS1.0)

Network

Rev.1.00

- 4 -

2. How to Connect

Both Ethernet and WLAN can be configured through the printer’s Ethernet interface.

Likewise, both Ethernet and WLAN can also be configured though the printer’s WLAN

interface. When you want to change the Ethernet or WLAN of the printer, the network

settings of the host (PC, PDA, etc) and Ethernet or WLAN of the printer must configured

properly configured so that communication can be established.

(1) Connecting Printer

1) Ethernet(LAN)

Connect the LAN cable to the printer

A direct cable or cross cable can be connected to the Hub or Host for use.

2) WLAN

Connect to the AP (Access Point) configured in Infrastructure mode in order to connect

to the LAN/wireless network.

Infrastructure Mode

In order to configure the network between wireless terminals, connect to the terminal in

Ad-hoc Mode.

Ad-hoc Mode

A P

Network

Rev.1.00

- 5 -

2-1 Initial Wireless LAN Connection (Windows 2000)

Windows 2000 does not support wireless network setting.

When you use Windows 2000, you need to set the utility option as below after installing

utility program related to the wireless LAN driver that you use.

- Network mode : Ad-hoc

- SSID : BIXOLON_adhoc

- IP address : 192.168.1.2

- Subneet Mask : 255.255.255.0

- Authentication(Encription) : Open(None)

2-2 Initial Wireless LAN Connection (Windows XP)

When wireless utility program is installed, you have to set the wireless control values

via the program, otherwise you have to terminate the program in order to do proper

setting after following the steps “Control Panel>>Administrative tools>>

Services>>Wireless Zero Configuration>>Start”.

1) Right click on the icon, and select Properties.

2) Select and right click on the Wireless Network Connection, and then select Properties.

Network

Rev.1.00

- 6 -

3) Select Internet Protocol (TCP/IP), and then click “Properties”.

4) Set the IP settings as shown below, and then click “OK”.

Network

Rev.1.00

- 7 -

5) Select the Wireless LAN tab, and then select “Use Windows to configure my wireless

network settings.”

Click the “Advanced” button.

6) Select “Computer-to-computer (ad hoc) network only.”

Network

Rev.1.00

- 8 -

7) Click the “Add” button.

8) Enter “BIXOLON_adhoc” as the Network name (SSID).

Network Authentication: Select Open

Data Encryption: Select Disabled

Click the “OK” button.

Network

Rev.1.00

- 9 -

9) Click the “Connect” tab and check “Connect when this network is in range.”

10) Check whether the settings are updated as shown below, and then click “Close”

When the printer is set to the default value (Adhoc mode, SSID: BIXOLON_adhoc), it

will automatically connect.

Network

Rev.1.00

- 10 -

2-3 Initial Wireless LAN Connection (Windows VISTA, Windows 7, 8, 10)

When wireless utility program is installed, you have to set the wireless control values via

the program, otherwise you have to terminate the program in order to do proper setting

after following the steps “Control Panel>>Administrative tools>>Services>>Wireless Zero

Configuration>>Start”.

1) Click the “Start>>Control Panel”.

2) Click the “View network status and tasks”.
