Beta Three V152a Manuel utilisateur

V152a

UM-V152a-20140423 ver A

User Manual

TwoWay15" Full Range

Active Speaker

V Series Pro Loudspeaker System

10.

Read the instruction first before using this product.

Pay attention to all warnings.

Obey all operating instructions.

Do not expose this product to rain or moisture.

Do not block any ventilation openings. Install according to instructions .

Do not install this product near any heat source, such as , heater, burner, or any other equipment with heat radiation .

Only use spare parts by manufacturer.

Pay attention to the safety symbol on the of the cover.

manual

Please keep this manual for future reference

Clean this equipment with a dry cloth.

manufacturer's

supplied the

outside

SAFETY INSTRUCTIONS

PLEASE READTHIS MANUAL FIRST

Thank you for a buyin product. Read this manual first as it will help you operate the system properly. Please keep this manual

for future reference. g

WARNING:

Thisproduct mustbeinstalledbyprofessionals.Whenusing hangingbracketsorrigging other than those supplied with

theproduct,pleaseensuretheycomplywiththelocalsafetycodes.

Theexclamationpoint withinan equilateral triangleis intendedtoalertyou tothe presenceofimportant

operatingand servicinginstructions.

ATTENTION:Don'trefitthesystemorsparepartswithoutbeingauthorizedasthiswill .voidthewarranty

WARNING: Don't (suchas candles) theequipment.placenakedflames closeto

V152a

CONTENT

Features

Description

Applications

Frequency Response andTHD CurveCurve

AMPLIFIER MODULE

INSTALLATION

Mounting Accessories

Installation Reference

INTRODUCTION

Technical Sheet

2D Dimension

TECHNICAL SPECIFICATION

Amplifier Module

V Series Pro Loudspeaker System

Product information is subject to change without

prior notification. Please visit www.elderaudio.com

for latest updates.

V152a

V Series Pro Loudspeaker System

INTRODUCTION

Applications

Multifunctional hall

Auditorium

Church

Conference room

Small performance

TwoWay15" Full Range Active Speaker

Features

Description

V152aV series is designed for prtalble and installed

applications.The integrated polymer PVC cabinet design

ensures durability and full natural high performance sound.

β3 V152a is a full range active speaker with a 500W Class D

amplifier module.The high powered 15" woofer delivers

powerful low frequency and the 34mm Titanium compression

driver delivers high definition mid/high frequencies. .

Compact light weight design, versatile sound reinforcement.

High output SPL and sensitivity.

Built-in digital amplifier provides abundant energy.

Heavy duty protective front grill.

Pole mount socket for speaker stand.

Suitable as a main system with or without sub speaker.

V152a

100V-240V ~ 50/60Hz

RATED POWER

CONSUMPTION:100W

OFF

Elder Audio Manufacture Co.,Ltd. S/N:

RoHS

CAUTION

AC INPUT POWER

PEAK

INPUT OUTPUT

LINE MIC

MIC

LINE

VOLUME BASS TREBLE

INPUT

SELECTOR

0-15 +15

-15 +15

15" ACTIVE LOUDSPEAKER

V152a

6. Line/microphone selector

7. Power supply input

8.Treble control

9. Line output

10. Line/microphone input

11. Power ON/OFF switchl

1. Bass control

2. PEAK indicator

3.Volume control

4. Line input signal indicator

5. Microphone input signal

indicator

V Series Pro Loudspeaker System AMPLIFIER MODULE

Amplifier Module

V152a

V Series Pro Loudspeaker System

INSTALLATION

Installation Accessories(Optional) Installation Reference

1. Speaker stand

Warning:Make sure the mounting accessories safety

factor not less than 5:1 or meet the local standard during

installation .

1.Reference A

2.Reference B

V152a

200001000010001005020

180

108

100

110

120

130

Sensitivity (dB)

Frequency (Hz)

-36

-108

-180

V Series Pro Loudspeaker System TECHNICAL SPECIFICATION

Specification

Frequency response(-3dB):

Max.SPL:

Transducer:

Input:

Connector:

Input impedance(line):

Input level:

Input overloading level:

Wire connection:

Heat radiation:

Power cable:

50Hz-20kHz

128dB

1 15"Woofer×

Channel one (Mic/Line) balanced input

XLR for input, XLR for output

20Kohm balanced input, 10Kohm unbalanced input

0 dBV (0.775V rms, 1.0V peak)Line-100Hz

Maximum input level 8V peak

pin 1: ground; pin2: signal +; pin3: signal -

Forced air-cooled drives

IEC 3 pin power connector

85°×75°

Dispersion(H×V):

1 34mm×Compression Driver

Safety voltage range:

Amplifier power output:

Cabinet:

Handle:

Painting:

Cabinet dimension(WxDxH):

Packing dimension(WxDxH):

Net weight:

Gross weight:

AC 100V-240V~50Hz/60Hz

500W

Powder coated grill

Flying/ Mounting accessories：Hanging point,supporting seat

Polypropylene injection moulding

Rated impedance: 8 Ohms

Frequency response curve &THD curve

Frequency Response

THD

23.5kg(51.7 lbs)

26.5kg(58.3 lbs)

485×458×727mm(19.1×18.0×28.6in)

545×515×800mm(21.5×20.3×31.5in)

Two side

485mm

[19.1in]

727mm

[28.6in]

458mm

[18.0in]

V152a

V Series Pro Loudspeaker System

Top view

Front viewSide view Back view

Bottom view

2D Dimension

TECHNICAL SPECIFICATION

Notes:

www.beta3pro.com
