Bernard Controls AQ Series Guide de l'utilisateur

AQ Switch

RANGE

Start Up Guide

SUG_17003 EN - Ind. C

Art: 5100466

English

TABLE OF CONTENTS

1DOCUMENTS -------------------------------------------------------------5

2INTENDED USE OF THE ACTUATOR-----------------------------------6

3SAFETY--------------------------------------------------------------------6

4PACKAGING, STORAGE AND MAINTENANCE-------------------------7

4.1 Packaging 7

4.2 Storage 7

4.3 Maintenance 7

5HANDWHEEL OPERATION ----------------------------------------------8

6ASSEMBLY ON THE VALVE OR DAMPER ------------------------------8

6.1 Changing closing direction visual indication 8

7ELECTRICAL COMMISSIONING --------------------------------------- 10

7.1 Electrical configurations 10

7.2 Before wiring 11

7.3 Wiring without positioner option 12

7.4 Wiring with positioner option 13

7.5 After wiring 16

7.6 Heating element 16

8CALIBRATION OF TRAVEL LIMITS ----------------------------------- 17

8.1 Calibration of cams corresponding to end position

switches 17

8.2 Calibration of mechanical stops 18

8.3 Calibration of cams corresponding to signaling

switches (if wired) 19

8.4 Calibration of positioner (OPTION) 19

9CALIBRATION OF POSITION OPTIONS ------------------------------ 21

English

9.1 Position feedback potentiometer (OPTION) 21

9.2 TAM position transmitter (OPTION) 23

9.3 Positioner board setting (OPTION) 25

10 TORQUE LIMITING DEVICE (EXCEPT ON AQ5/10/15)------------ 27

10.1 Torque limiter operation 27

10.2 Torque limiter adjustment 28

11 APPENDIX--------------------------------------------------------------- 29

11.1 Wiring diagram without positioner option 29

11.2 Wiring diagrams with positioner option 31

English

Thank you for choosing a Bernard Controls electric actuator.

Our actuator has been designed, manufactured and tested rigorously

to give you maximum satisfaction.

Bernard Controls develops a range of products and accessories to

meet your needs for various applications. Visit our website to

discover these innovative products: www.bernardcontrols.com

In accordance with its policy of continuous improvement, Bernard

Controls reserves the right to modify the specifications of all

products described herein without prior notice.

All measures are expressed in metric units. Converted values to other

systems (notably US and UK) are given for reference only.

Pictures are non-contractual ones.

1DOCUMENTS

Please keep this manual and all the documents that accompany it

nearby so that you can consult them if necessary.

We decline all responsibility for damages caused by not observing

the instructions of this manual.

English

2INTENDED USE OF THE ACTUATOR

Bernard Controls actuators are manufactured in accordance with the

latest technical evolutions and safety regulations.

The AQ SWITCH and AQ SWITCH POSITIONER are intended to operate

a valve or a damper in moderate environmental and operational

constraints.

All other uses are considered inadequate.

In no case will the manufacturer be held responsible for damages or

harm caused by using the actuator for any purpose other than that

for which it is designed. The user takes responsibility for all risks.

The notion of intended use also includes compliance with the

instructions in this manual and all accompanying documents, as well

as compliance with the installation and maintenance conditions.

3SAFETY

This device complies with current applicable safety standards.

The installation, use and maintenance of this unit require a skilled

and trained staff.

Please carefully read this entire document before mounting and

starting-up the actuator.



Warnings and cautions in this manual cannot cover all the risks

associated with the use of the actuator. In addition to the

instructions given, it is important to exercise good judgment and

apply basic principles of safety.



As a standard, AQ actuators are configured to close clockwise.

If your actuator closes counterclockwise, please see §6.1.

English

4PACKAGING, STORAGE AND MAINTENANCE

4.1 Packaging

AQ actuators are delivered in a cardboard box of a size equivalent to

the actuator and sit in a cardboard wedge.

4.2 Storage

Actuators should be stored under a shelter, in a clean and dry place,

and protected from wide temperature variations.



•Avoid placing the actuator directly on the floor.

•Check that the plugs on cable entries are correctly tightened.

•Check that the cover screws are correctly tightened to ensure

weatherproof sealing of the cover.



The heating element must be connected to the power supply,

especially if the storage place is wet (standard 230 VAC, except

otherwise specified).

AQ actuators include electrical components and lubricated gears.

Even with a weatherproof enclosure, oxidation, seizing and other

alterations may occur if actuators are not correctly stored.

What to check after storage

1. Visually check the electrical equipment.

2. Manually operate the micro-switches, buttons, selectors,

etc., to ensure their proper mechanical functioning.

3. Manually operate the actuator.

4.3 Maintenance

This actuator features lifetime lubrication. If the device is correctly

mounted and sealed, no specific maintenance is required.

Test the motor operation once a year and make sure that the

electrical compartment is free from condensation.

This actuator includes an anticondensation heater to avoid

condensation build-up when operating in a wet atmosphere.

English

5HANDWHEEL OPERATION

AQ actuators feature a handwheel for safety operation.

To avoid potentially harmful rotating protruding parts during

electrical operation, AQ handwheels feature a foldable handle: you

can fold it during electrical operation and unfold it if you need to

operate the actuator manually.

6ASSEMBLY ON THE VALVE OR DAMPER

The actuator should be directly attached to the valve using proper

bolts or via a proper interface.

If the valve is in the closed position, then the actuator should also

be installed in the closed position. If the valve is open, so should be

the actuator.



If you cannot reach the correct position because you are blocked by

a mechanical stop, loosen the mechanical stop so that you have

enough space to go to the correct position.

After assembly on the valve or on the damper, the actuator can

operate in any position.



However:

•do not lift the actuator by the handwheel to avoid damage on

internal gearing.

•cable glands must not be oriented upwards (loss of water

tightness).

6.1 Changing closing direction visual indication

As a standard, AQ actuators are configured to close clockwise. If the

actuator must close counterclockwise, you can change the

orientation of the position indicator cap.

English

Standard indicator orientation

for clockwise closing

Reverse indicator orientation

for counterclockwise closing

How to change cap orientation

1. Disassemble the cover then the

cap.

2. Turn the cap 90°.

3. Reassemble the cap then the

cover.

English

7ELECTRICAL COMMISSIONING

7.1 Electrical configurations

During the commissioning, the actuator will correspond to one of the

two following configurations:

8- Capacitor

7- Switches board

6- Torque limiter (except on

AQ5/10/15)

5- Motor

4–Heating resistance

3- Cams

2- Terminal block

1- Position indicator

Without Positioner

12 –Capacitor

11 –Handwheel

10 –Heating resistance

9–Micro-switches

8- Potentiometer

7–Mechanical stop

6- Cams

5- Plug (cable gland)

4–Power terminal block

3- Push buttons

2–Command and signaling

terminal block

1- Position indicator

With Positioner

The actuator and its components are wired to internal terminal

blocks.
