Bernafon SoundGate 3 Manuel utilisateur

GUIDE

FOR WIRELESS

CONNECTIVITY

SoundGate 3

SoundGate Mic

TV Adapter 2

Phone Adapter 2

RC-N Remote Control

Purpose

In this guide, you will nd detailed instructions for SoundGate 3 operation with a Bluetooth®-enabled

mobile telephone, SoundGate Mic, and accessories for television and landline telephone use.

You will also nd instructions for how to set up the demo version of the RC-N remote control.

Equipment Required for SoundGate 3 Operation

Before you begin, ensure the SoundGate 3 is completely charged and the following components

are readily available for use:

· One, or a pair of hearing aids that offer wireless connectivity with

S o u n d G ate 3

· One completely charged SoundGate 3 and the accessories delivered

within its original packaging

– Neck strap antenna

– Wall outlet charging unit or USB charger cable

– Charger cradle

· One Bluetooth®-enabled mobile phone

· One iPhone®

(SoundGate App supports iPhone 5s, iPhone 5c, iPhone 5, iPhone 4s,

andiPhone 4)

SN2_ILLU_Overview_HI

SN2_ILLU_Charger_HI

SN2_ILLU_UsbCable_HI

SN2_ILLU_Neckloop_HI

SN2_ILLU_ChargerCradle_HI

GUIDE FOR WIRELESS CONNECTIVITY

· One SoundGate Mic and the following accessory delivered within its

original packaging

– Power adapter

· One TV Adapter 2 and the following accessories delivered within its

original packaging

– Power adapter

– SCART adapter

– RCA stereo cable

– TOSLINK cable

– Mini jack adapter

· One television or audio/video source, e.g., PC or laptop computer

· One Phone Adapter 2 and the following accessories delivered within its

original packaging

– Power adapter

– Standard analog phone cable

· One landline telephone with an active telephone network connection

SN2_ILLU_SoundgateTopOfTelevisionAdapter_HI

SN2_ILLU_Charger_HI

Equipment Required for

RC-N Operation

Before you begin, ensure the RC-N remote control has two (2) AAAA batteries inserted and the

following components are readily available for use:

· One, or a pair of hearing aids that offer wireless connectivity

· One RC-N remote control

RC-N_ILLU_RemoteControl_Front_BW

GUIDE FOR WIRELESS CONNECTIVITY

Preparing the SoundGate 3

and Hearing Aids

With the hearing aids connected to the Oasis tting software, choose Options and select

Start Pairing in the area of the screen designated for SoundGate 3 / Remote control.

Ensure the SoundGate 3 is fully charged and powered ON. Then follow the tting software

instructions to complete the pairing between the SoundGate 3 and the connected hearing aids.

1. Press the Volume Up key on the SoundGate 3 while holding it approximately 30 – 50 cm (1– 1½ feet)

from the hearing aids

2. To conrm the link between SoundGate 3 and the connected hearing aids, repeat this step by pressing

the Volume Up key

The Oasis tting software will conrm the successful pairing.

Before disconnecting the hearing aids, be sure to save the tting session in Oasis by clicking

Save and Quit.

Using SoundGate 3

with a Mobile Telephone

Pairing the SoundGate 3 and Mobile Telephone

A secure connection between the SoundGate 3 and mobile telephone must be established prior

to Bluetooth® streaming. Ensure the SoundGate 3 and mobile telephone are positioned within one meter

(3 feet) of each other, and follow the steps below to pair the devices.

1. Prepare the mobile telephone for Bluetooth®pairing

As this process may vary from one mobile telephone to the next, refer to the instruction manual for

the mobile telephone when available. If the manual is not readily available, Bluetooth® settings can

typically be found under the mobile telephone’s “Settings” menu.

Here is an example, using an iPhone 5 mobile telephone:

· Press the “Settings” icon on the home screen

· Press “Bluetooth®”

· If Bluetooth® function is turned OFF, swipe your nger across the touch screen from left toright to

turn the function ON

The mobile telephone is now prepared to search for other active Bluetooth® devices within range.

2. Prepare the SoundGate 3 for Bluetooth®pairing

· Press and hold the SoundGate 3 Power key for 5-6 seconds

· The LED indication will begin ashing rapidly blue. This indicates that the SoundGate 3

is in pairing mode. Pairing mode will be active for two minutes.

3. Activate pairing

· Once both devices are in active pairing mode, the Bluetooth® mobile telephone will locate

the SoundGate 3, and the name “SoundGate 3” will appear in the mobile phone display

· Select “SoundGate 3”

· When prompted to enter a pin code by the mobile telephone, enter “0000” (four zeros)

and press “OK”. The phone will now complete pairing and connect the two devices.

GUIDE FOR WIRELESS CONNECTIVITY

Using SoundGate 3 with a

Mobile Telephone

For optimal use with a mobile telephone, ensure the SoundGate 3 is worn with the neck strap

antenna and that the hearing aids are powered ON.

Make a Phone Call

1. Dial a phone number from the connected mobile telephone

2. The Phone key on the SoundGate 3 will illuminate green and the normal ringing signal will

become audible to the wearer

3. When the other party answers the phone call, the conversation can begin

4. To end the phone call at any time, press the SoundGate 3 Phone key. The Phone key will

no longer illuminate and the previous listening program will resume.

Answer a Phone Call

1. When the paired mobile telephone rings, the SoundGate 3 Phone key will ash green and a ring

tone will become audible to the hearing aid wearer. Press the SoundGate 3 Phone key to accept

the incoming call.

2. The SoundGate 3 Phone key will now illuminate steady green

3. Begin speaking toward the SoundGate 3 microphone to initiate the conversation

4. To end the phone call at any time, press the SoundGate 3 Phone key. The Phone key will

no longer illuminate and the previous listening program will resume.

For additional information on mobile telephone streaming, please refer to SoundGate 3

Instructions for Use.

A secure connection between the SoundGate 3 and mobile telephone must be established prior to

Bluetooth® streaming (see page 6).

If an iPhone (SoundGate App supports iPhone 5s, iPhone 5c, iPhone 5, iPhone 4s, and iPhone 4)

is used, the hearing aid volume, program, and more can alternatively be controlled via the SoundGate

App. The app can be downloaded for free from the App Store. Search for “Bernafon SoundGate”.

A demo version is available with the

SoundGate App. SoundGate 3 and the

mobile telephone must not be paired in

this demo mode.

Apple, the Apple logo, and iPhone are trademarks of Apple Inc., registered in the U.S. and other

countries. App Store is a service mark of Apple Inc.

Using the SoundGate App

GUIDE FOR WIRELESS CONNECTIVITY

A secure connection between the SoundGate 3 and SoundGate Mic must be established.

Follow the instructions below to prepare the devices for use.

Setting Up the SoundGate Mic

Ensure the SoundGate Mic is fully charged. To charge the microphone, connect the power

adapter to the mini USB connector at the bottom of the microphone. The power indicator will be

illuminated green when SoundGate Mic is fully charged.

Battery charge

connector (mini USB)

Constant

green light

Fully charged

After approx. 1.5 hours

of charging, device will

operate for up to 5 hours

Using SoundGate 3

with the SoundGate Mic

Pairing the SoundGate 3 and SoundGate Mic

Ensure the SoundGate Mic is fully charged, and the SoundGate 3 battery is charged and powered ON.

The power indicator on the SoundGate Mic and the status indicator on the SoundGate 3 should be

illuminated green.

SN2_ILLU_TopLedFlashingBlue_HI

6 secs

1. Press and hold the SoundGate 3 Power key

for 5 – 6 seconds until the status indicator

starts ashing blue rapidly.

2. Press and hold the SoundGate Mic ON/OFF

button for 5 – 6 seconds until the LED indicator

starts ashing orange rapidly.

The pairing is completed when the SoundGate Mic

LED indicator and the SoundGate 3 AUX input key

turn stable orange.
