Installation- and maintenance instruction

B 30 A

LMO14.113C2E

AS47CK

50/60Hz

Translation of the original instructions.

2Bentone

example Beispielexempel

352011030141

Designation

Type

Model

Serial no.

Motor supply

Main supply

MADE IN SWEDEN BY

LIGHT OIL 35-90kW 1,25-6,0 cSt 7-14bar

BF 1 KS 76-24

BF 1

BF 1 KS 76-24

1234567

1~230V 1,0A 50Hz IP 20

Man.Year 2019

Cap. Min-Max

-sv

1. Manualer på övriga språk

2. www.bentone.com\

nedladdning eller scanna

QR-koden.

3. Skriv in brännarens

artikelnummer som  nns på

din typskylt (se bild) och välj

ditt språk.

Detaljerad ecodesign

information kan laddas ner

på: www.bentone.com/

ecodesign.

-en

1. Manuals in other languages

2. www.bentone.com\download

or scan QR-code.

3. Enter the burner`s article

number on your data plate (see

picture) and select language.

Detailed ecodesign information

can be downloaded at:

www.bentone.com/ecodesign.

-da

1. Manualer på andre sprog

2. www.bentone.com\

download eller scan

QR-koden.

3. Indtast brænderens

artikelnummer, der  ndes

på typeskiltet (se billede), og

vælg dit sprog.

Detaljerede oplysninger om

ecodesign kan downloades

på: www.bentone.com/

ecodesign.

-fr

1. Manuels dans d’autres

langues

2. www.bentone.com\

download ou scannez le

code QR.

3. Saisir le numéro d’article

du brûleur sur votre plaque

signalétique (consultez

l’illustration) et sélectionnez

la langue.

Des informations détaillées

sur l’écodesign peuvent être

téléchargées à l’adresse:

www.bentone.com/

ecodesign.

-de

1. Gebrauchsanweisungen in

anderen Sprachen

2. www.bentone.com\download

oder scannen Sie den QR-Code.

3. Geben Sie die Artikelnummer

des Brenners auf Ihrem

Typenschild ein, (siehe Bild)

und wählen Sie die Sprache

aus.

Detaillierte Informationen zum

Ecodesign können unter

www.bentone.com/ecodesign

heruntergeladen werden.

3Bentone

Table of contents

1. General Information............................................................4

1.1 Delivery inspection........................................................................ 4

1.2 Safety ............................................................................................... 4

2. Technical data.......................................................................6

2.1 Dimensions B 30 A........................................................................ 6

2.2 Burner installation ........................................................................ 7

2.3 Workingeld.................................................................................. 7

2.4 Basic settings - Fuel oil................................................................. 7

2.5 Basic settings - HVO/XTL ............................................................. 8

2.6 Technicalspecication ................................................................. 8

2.7 Settingofignitionelectrodesandbrakeplate ....................... 9

2.8 Nozzleandpumppressure......................................................... 9

2.9 Nozzletable.................................................................................... 9

2.10 Components................................................................................. 10

3. Electric equipment.............................................................11

3.1 Safety system .............................................................................. 11

3.2 Wiringdiagram.......................................................................... 11

3.3 Function ........................................................................................ 12

3.4 Colourcodes................................................................................ 13

3.5 Faultcodes ................................................................................... 13

4. Installation..........................................................................14

4.1 General instructions................................................................... 14

4.2 Inspectionandmaintenance.................................................... 14

4.3 Start-up ......................................................................................... 14

4.4 Preparing for installation........................................................... 14

4.5 Oildistribution............................................................................. 14

4.6 Electrical connection .................................................................. 15

4.7 Handlingandliftinginstruction ............................................... 16

5. Mounting ............................................................................17

5.1 Check oil line seals...................................................................... 17

5.2 Example of Basic settings.......................................................... 18

5.3 Air setting ..................................................................................... 19

5.4 Brakeplateadjustment ............................................................. 19

6. Pump ..................................................................................20

6.1 SUNTEC AS .................................................................................. 20

7. Service .................................................................................26

7.1 BurnerServiceSchedule,Oil .................................................... 26

7.2 Component replacement intervals.......................................... 26

7.3 Combustiondevice .................................................................... 27

7.4 Airdamper................................................................................... 28

7.5 Fan ................................................................................................. 29

7.6 Replace oil pump ........................................................................30

7.7 Replacement of electrical components.................................. 31

7.8 Vibrations...................................................................................... 32

8. Fault Location.....................................................................33

8.1 Burner will not start.................................................................... 33

8.2 Burner will not start after normal use .................................... 33

8.3 Delayedignition .......................................................................... 34

8.4 Noise in pump ............................................................................. 34

8.5 Pump pressure ............................................................................ 35

9. Logofuegasanalysis.....................................................36

4Bentone

165 105 01-2 2021-12-07

1. General Information

The burner may only be used for its intended purpose in accordance with the

product’s technical data.

We reserve the right to make design changes and cannot be held liable for any

misprints or typographical errors.

Modifying the design or using accessories or components that have not been

approved by Enertech in writing is strictly prohibited.

This Installation and Maintenance manual:

• is to be regarded as part of the burner and must always be kept near

the installation site.

• must be read prior to installation.

• is intended for use by authorised personnel.

1.1 Delivery inspection

• Make sure everything is delivered and the goods have not been

damaged during transit.

Transport damage must be reported to the shipping company.

• If something is wrong with a delivery, report it to the supplier.

1.2 Safety

- before installation:

• Installation and work on the burner and associated system

components may only be carried out by persons who have undergone

relevant training.

• The product is packaged to prevent damage from occurring when

handled – Handle the product with care! Lifting equipment must be

used to lift larger packages.

• The products must be transported/stored on a level surface in a dry

environment, max. 80% relative humidity, no condensation.

Temperature -20 to +60 °C.

- installation:

• The burner must be installed in accordance with local regulations for

 re safety, electrical safety, and fuel distribution.

• The premises must comply with local regulations pertaining to use of

the burner, and must have adequate air supply.

• The installation site must be free of chemicals.

• Fire extinguisher with Class BE recommended.

• Make sure when installing the burner that there is enough space to

service the burner.

• The electrical installation must be professionally carried out in

accordance with current mains electricity regulations and in a

professional manner.

• Make sure that the burner is suitable for the application (see Technical

Data).

• All components must be installed without being bent, twisted or

subjected to mechanical or thermal forces that affect components.

5Bentone

• Care must be taken by the installer to ensure that no electrical cables

or fuel lines are pinched or otherwise damaged during installation or

service.

• Flame tubes, fan wheels and air dampers, for example, may contain

sharp edges.

- before  rst start:

• The burner must not be put into operation without proper safety and

protection devices.

• Permitted ambient temperature during operation -10 to +60 °C. Max.

80% relative humidity, no condensation.

• The surface temperature of the burner’s components may exceed

60 °C.

• Handle with caution – the burner has moving parts, and there is risk

of crushing injuries.

• Seal inspections must be performed during installation and servicing

to prevent leakage.

•  tting and installation work has been completed and approved.

• electrical installation has been correctly performed.

•  ue gas ducts and combustion air ducts are not blocked.

• all actuators and control and safety devices are in working order and

correctly set.

• If the boiler is equipped with an access hatch, this must be equipped

with a hatch opening switch connected to the burner’s safety system.

• When in operation, the burner’s noise level can exceed 85 dBA – use

hearing protection!

- Operation:

• Carry out all stipulated settings, service and inspection work within

the set time.

• If the oil burner control has a solid red light, contact your installer.

6Bentone

165 405 05-4

2. Technical data

The burner is intended for:

• Operation in installations according to EN 303 and EN 267.

When operating with a hot air boiler, the LMO24.255 or LMO44.255 control unit must be used.

Fuels:

• HVO/XTL according to EN 15940.

• Fuel oil according to DIN 51603-1.

• Fuel oil A Bio 10 according to DIN 51603-6.

2.1 Dimensions B 30 A

* Min. recommended distance to oor.

2.1.1 Dimensions ange

A Ø B Ø C D E F G H * I

115/187/315 104 108 372 220 84 172 205 200

G H

øB

øC E

A D

160303-724

ø108

160-190

7Bentone

2.3 Working eld

!Do not exceed working

eld.

2.2 Burner installation

2.2.1 Hole patten

Make sure the hole pattern on the boiler is designed for burner ange.

-0,5

0,0

0,5

1,0

1,5

2,0

2,5

3,0

3,5

60 80 100 120 140 160 180 200

mbar

6.0-17.0 kg/h

72-200 kW

160302-622

2.4 Basic settings - Fuel oil

100

75 100 125 150 175 200

160303-219

Air settings

Nozzle assembly

Scale1

Burner output

Air2<˚

1Scale nozzle assembly and air damper without damper motor.

Settings air damper with damper motor.

d1 d2 d3

ø 115 10 ø 160-190

8Bentone

2.5 Basic settings - HVO/XTL

Measurements according to EN 15036-1:2006

Alt.1 The noise level of the burner can be reduced by equipping the burner

with silencer. Installation must be done so it does not prevent air supply

to the burner.

Alt.2 The burner’s noise level can be reduced by connecting the burner’s air

intake to the air duct that opens into an appropriate location. Installation

must be done so it does not prevent air supply to the burner.

B 30 A

Main supply 1) 230V, 1~, 2.6/3.1A, 50/60Hz, IP20

Max fuse rating 10A

Elmin preheater excluded 1.67A, 375W

Elmax preheater excluded 1.7A, 382W

PSB 0

NOX-class 2

Noise level 82dBA

1) Max operating current, see data plate.

100

72 104 136 167 200

160303-598

Air settings

Nozzle assembly

Scale1

Burner output

Air2<˚

1Scale nozzle assembly and air damper without damper motor.

2Settings air damper with damper motor.

2.6 Technical specication

Flame signal

When operating at high power or low air excess and HVO/XTL is used as fuel,

the ame signal may deteriorate (blue ame), the signal lamp in the reset

button ashes green.

By lowering the air velocity or changing the ame detector to QRC1 A1, the

ame signal can be improved.

9Bentone

2.9 Nozzle table Pump pressure bar

The table applies to oil with a viscosity of 4.4 mm2/s at a density of 830 kg/m3..

Gph 7 8 9 10 11 12 13 14 15

kg/h kW kg/h kW kg/h kW kg/h kW kg/h kW kg/h kW kg/h kW kg/h kW kg/h kW

0,35 1,13 13 1,21 14 1,28 15 1,35 16 1,42 17 1,48 17 1,54 18 1,60 19 1,65 19

0,40 1,22 14 1,33 16 1,41 17 1,49 18 1,56 18 1,63 19 1,70 20 1,76 21 1,82 21

0,50 1,56 18 1,66 20 1,76 21 1,86 22 1,95 23 2,04 24 2,12 25 2,20 26 2,28 27

0,60 1,98 23 2,00 24 2,12 25 2,23 26 2,34 28 2,45 29 2,55 30 2,64 31 2,73 32

0,65 2,23 26 2,16 26 2,29 27 2,42 29 2,54 30 2,65 31 2,75 33 2,86 34 2,96 35

0,75 2,46 29 2,49 29 2,65 31 2,79 33 2,93 35 3,08 36 3,18 38 3,30 39 3,42 40

0,85 2,77 32 2,83 33 3,00 36 3,16 37 3,32 39 3,47 41 3,61 43 3,74 44 3,87 46

1,00 3,11 37 3,33 39 3,53 42 3,72 44 3,90 46 4,08 48 4,24 50 4,40 52 4,56 54

1,10 3,55 42 3,66 43 3,88 46 4,09 48 4,29 51 4,48 53 4,67 55 4,84 57 5,01 59

1,20 3,72 44 3,99 47 4,24 50 4,47 53 4,68 55 4,89 58 5,09 60 5,29 63 5,47 65

1,25 3,94 47 4,16 49 4,40 52 4,65 55 4,88 58 5,10 60 5,30 63 5,51 65 5,70 68

1,35 4,33 51 4,49 53 4,76 56 5,02 59 5,27 62 5,50 65 5,73 68 5,95 70 6,15 73

1,50 4,89 58 4,98 59 5,29 63 5,58 66 5,85 69 6,11 72 6,36 75 6,60 78 6,83 81

1,65 5,09 60 5,49 65 5,82 69 6,14 73 6,44 76 6,73 80 7,00 83 7,27 86 7,52 89

1,75 5,48 65 5,82 69 6,18 73 6,51 77 6,83 81 7,14 85 7,42 88 7,71 91 7,97 94

2,00 6,21 74 6,65 79 7,06 84 7,45 88 7,81 93 8,18 97 8,49 101 8,81 104 9,12 108

2,25 6,99 83 7,49 89 7,94 94 8,38 99 8,78 104 9,18 109 9,55 113 9,91 117 10,26 122

2,50 7,77 92 8,31 98 8,81 104 9,29 110 9,74 115 10,18 121 10,59 126 10,99 130 11,38 135

2,75 8,78 104 9,39 111 9,96 118 10,50 124 11,01 131 11,50 136 11,97 142 12,42 147 12,86 152

3,00 9,71 115 10,38 123 11,00 130 11,60 137 12,17 144 12,71 151 13,23 157 13,73 163 14,21 168

4,00 11,88 141 12,70 150 13,47 160 14,20 168 14,89 176 15,56 184 16,19 192 16,80 199 17, 3 9 206

Nozzle: 45° Solid/semisolid

60° Solid/semisolid

80° Solid/semisolid

Pump pressure: 10 bar (10-15 bar) depending on pump model

!*NB It is important that the spark

does not strike against the brake

plate or nozzle.

a b c d

2.5-3.5 7.0-9.0 1.0-2.0 5.0-6.0

2.7 Setting of ignition electrodes and brake

plate

2.8 Nozzle and pump pressure

Due to different furnace geometries and capacities, it is not possible to

recommend a nozzle model.

10 Bentone

2.10 Components

1. Brake plate

2. Nozzle

3. Ignition electrodes

4. Fixing ange

5. Ignition transformer

6. Reset button

7. Burner control

8. Electrical connection

9. Cover, inspection glass

10. Fan wheel

11. Motor

12. Air intake

13. Nozzle assembly adjustment

14. Air adjustment

15. Flame detector

16. Pump

17. Solenoid valve

18. Air damper

19. Flame tube

123 4 5 8 97

1012

16 18

15 13

160303-725

160303-726

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Bentone Brûleur

Bentone

Bentone B 45 A Caractéristiques techniques

Bentone

Bentone BG 550 M LN Caractéristiques techniques

Bentone

Bentone B30 Caractéristiques techniques

Bentone

Bentone STG 146/2 Caractéristiques techniques

Bentone

Bentone B 30 2A Caractéristiques techniques

Bentone

Bentone DMV-DLE 525/11 Caractéristiques techniques

Bentone

Bentone B 30 A2.2 Caractéristiques techniques

Bentone

Bentone STG 146/1 Caractéristiques techniques

Bentone

Bentone BF 1 FUV FAME/RME Caractéristiques techniques

Bentone

Bentone BG 400 Caractéristiques techniques

Bentone

Bentone LME21.550C2 Caractéristiques techniques

Bentone

Bentone 45 A2.2 Caractéristiques techniques

Bentone

Bentone B 2 Series Caractéristiques techniques

Bentone

Bentone B 80i-3R FAME J Caractéristiques techniques

Bentone

Bentone BG 450 M J IP20 Caractéristiques techniques

Bentone

Bentone bg 300 Caractéristiques techniques

Bentone

Bentone STG 120/1 Caractéristiques techniques

Bentone

Bentone B 70i-3R FAME J Manuel utilisateur

Bentone

Bentone BG400M Caractéristiques techniques

Bentone

Bentone BF 1 KSV FAME Caractéristiques techniques

Bentone

Bentone BG550M Caractéristiques techniques

Bentone

Bentone BG 950 M Caractéristiques techniques

Bentone

Bentone BG 650i M Caractéristiques techniques

Bentone

Bentone BG 650i M J/K IP54 Caractéristiques techniques

Manuels Brûleur populaires d'autres marques

Riello

Riello RS 28/M Guide de démarrage rapide

True Induction

True Induction TI4B Manuel utilisateur

Weishaupt

Weishaupt WG20 Series Manuel utilisateur

Carolina Cooker

Carolina Cooker M116672 Manuel utilisateur

Riello

Riello RX 500 S/PV Mode d’emploi

Unigas

Unigas HTP2000 Manuel utilisateur

baltur

baltur BT 250 DSG 4T Manuel utilisateur

muenkel design

muenkel design round burner Manuel utilisateur

Ecoflam

Ecoflam Multicalor 170.1 Manuel utilisateur

baltur

baltur BT 14 DSGW Manuel utilisateur

artisan

artisan Art-SB1 Mode d’emploi

Riello

Riello P 140 T/G Guide de démarrage rapide

AESYS

AESYS TurboFire II Manuel utilisateur

Riello

Riello RG1RKD Guide de démarrage rapide

IKEA

IKEA GRILLSKÄR Manuel utilisateur

RUSTA

RUSTA SAREK Manuel utilisateur

PROPOINT

PROPOINT 8933657 Manuel utilisateur

baltur

baltur TBL 1000 ME Manuel de référence
