BENNING EV 3-2

Operating manual

Translation of the German original version

5178 / 03/2021 en

Legal notice

5178 / 03/2021 enBENNING EV 3-22

Legal notice

Notes concerning the documentation

Ensure that the applicable documentation is used for this product. For safe handling, knowledge

that is provided in these instructions is required.

The product may only be handled while following this documentation, particularly the safety

instructions and warnings it contains. The personnel must be qualified for the respective task

and have the capability to recognise risks and prevent possible dangers.

Manufacturer and holder of rights

BENNING Elektrotechnik und Elektronik GmbH&Co.KG

Münsterstraße135–137

46397 Bocholt

Germany

Phone: +492871/93‑0

E-Mail: [email protected]

Internet: www.benning.de

Commercial register Coesfeld HRA No. 4661

This document – particularly all of the contents, texts, photographs and graphics that it contains

– are protected by copyright.

No part of this documentation or the associated contents may be reproduced or edited, copied

or distributed using electronic media in any form (printed, photocopied or using any other

method) without express written permission.

Disclaimer

The contents of the documentation has been checked to ensure that it corresponds to the

hardware and software described. Nevertheless, deviations cannot be ruled out, so Benning

cannot guarantee complete correspondence. The contents of this documentation are checked

at regular intervals, and any corrections that are needed are contained in the versions that

follow.

General non-discrimination

Benning is aware of the importance of language with regard to the equality of men and women,

and endeavours to take this into account at all times. To improve readability, we have refrained

from consistently using differentiating formulations.

Table of contents

1 Introduction................................................................................................................................................6

1.1 General notes........................................................................................................................6

1.2 History ...................................................................................................................................7

1.3 Service & support..................................................................................................................8

2 Safety..........................................................................................................................................................9

2.1 Warning system ....................................................................................................................9

2.2 Standards applied .................................................................................................................9

2.3 Symbols used......................................................................................................................10

2.4 Intended use .......................................................................................................................10

2.5 Special types of risks ..........................................................................................................12

3 Scope of delivery.....................................................................................................................................13

4 Device description...................................................................................................................................14

4.1 Device structure ..................................................................................................................14

4.2 Functions.............................................................................................................................15

5 Operation..................................................................................................................................................17

5.1 Testing with an installation tester ........................................................................................17

5.2 Testing with an oscilloscope ...............................................................................................18

6 Maintenance.............................................................................................................................................20

6.1 Cleaning the device.............................................................................................................20

7 Technical data..........................................................................................................................................21

8 Disposal and environmental protection ................................................................................................22

Index .........................................................................................................................................................23

5178 / 03/2021 en BENNING EV 3-2 3

Table of figures

Figure 1 BENNINGEV3-2 device structure ......................................................................................... 14

Figure 2 Assignment of the Type2 connector for connection to the charging station (EVSE) ............. 15

Figure 3 Connecting the device ............................................................................................................ 17

5178 / 03/2021 enBENNING EV 3-24

List of tables

Table 1 History.......................................................................................................................................... 7

Table 2 Symbols on the device................................................................................................................. 10

Table 3 Symbols used in the operating manual........................................................................................ 10

Table 4 Switch positions of the “PP-Status/State” rotary switch............................................................... 15

Table 5 Switch positions of the “CP-Status/State” rotary switch............................................................... 16

Table 6 Technical data ............................................................................................................................. 21

5178 / 03/2021 en BENNING EV 3-2 5

1.1 General notes

Introduction

5178 / 03/2021 enBENNING EV 3-26

1 Introduction

The BENNINGEV3-2 measuring adapter described here (in the following only referred to as

“device”) is an optional accessory for the BENNINGIT130 and IT200 installation testers. The

BENNINGEV3-2 measuring adapter enables you to perform safety and functional tests on

certain charging stations for electric vehicles (EVSE, electric vehicle supply equipment) in

compliance with DINVDE0100-600 (IEC60364-6) and DINVDE0105-100 (EN50110) using

the corresponding installation tester.

The device is intended for testing charging stations according to DINEN/ IEC61851-1

(VDE0122-1) of charging mode “Mode3” and is provided with a Type2 connector according to

IEC/ EN62196. The “Mode3” charging mode is used for 1-phase and 3-phase charging with

alternating current (AC) at permanently installed charging stations (so called “wall boxes”).

The device establishes safe contact with the BENNING installation tester and triggers the

charging process of the charging station by simulating an electric vehicle (EV).

Further information

http://tms.benning.de/ev3-2

On the Internet, you will find the following additional information directly at the specified link or

at www.benning.de (product search):

• Operating manual of the device in several languages

• Further information depending on the device (e.g. brochures, technical reports, FAQs)

1.1 General notes

Target group

This operating manual is intended for the following groups of people:

• Qualified electricians and qualified technical personnel

Required basic knowledge

To understand these operating manual, you will need general knowledge of testing and

measuring equipment. Moreover, you will need basic knowledge of the following issues:

• General electrical engineering

Purpose of the operating manual

This operating manual describes the device and provide you information about how to handle it.

Keep this operating manual in a safe place for later use. Read this operating manual before

handling the device and follow the instructions.

Introduction

1.2 History

5178 / 03/2021 en BENNING EV 3-2 7

NOTE

Disclaimer of liability

Please make sure that any person using the device has read and understood the instructions of

this operating manual before handling the device and that the instructions are adhered to in all

points. Non-observance of this operating manual might result in product damage, property

damage and/or personal injury.

Benning assumes no liability for damage and malfunctions resulting from the failure to observe

the instructions in this operating manual.

The devices are subject to continuous further development. Benning reserves the right to make

changes to the device’s design, configuration and technology. The information in this operating

manual corresponds to the state of technical knowledge at the time of printing. For this reason,

no claims for certain device characteristics can be derived from the contents of this operating

manual.

Information in this operating manual can be changed at any time without prior notice. Benning is

not obligated to make amendments to this operating manual or to keep it up to date.

Direct any technical questions to Technical Support [}page8].

Trademarks

All trade marks that are used are the property of their respective owners, even if they are not

separately marked as such.

1.2 History

Release number Updates

03/2021 • Initial publication

Table1: History

1.3 Service & support

Introduction

5178 / 03/2021 enBENNING EV 3-28

1.3 Service & support

Please contact your specialty retailer or the BENNINGServiceCenter for any repair or service

work that might be required.

Technical support

Please contact our Technicalsupport for technical questions on handling the device.

Phone: +49287193-555

Fax: +49287193‑6555

E-Mail: [email protected]

Internet: www.benning.de

Returns management

Easily and conveniently use the BENNING returns portal for a quick and smooth returns

processing:

https://www.benning.de/service-de/retourenabwicklung.html

Phone: +49287193-554

E-Mail: [email protected]

Return address

BENNING Elektrotechnik und Elektronik GmbH & Co. KG

Retourenmanagement

Robert-Bosch-Str. 20

D - 46397 Bocholt

Safety

2.1 Warning system

5178 / 03/2021 en BENNING EV 3-2 9

2 Safety

2.1 Warning system

This operating manual contains notes that must be taken into consideration for your personal

safety and in order to avoid injuries and damage to property. Warnings about your personal

safety and to prevent personal injuries are marked with a warning triangle. Warnings on sole

prevention of material damage are shown without a warning triangle. The warnings are shown

in descending order depending on the hazard level as follows.

DANGER

Extremely dangerous situation for humans

If you do not pay attention to this warning, irreversible or deadly injuries will occur.

WARNING

Hazard to humans

If you do not pay attention to this warning, irreversible or deadly injuries could occur.

CAUTION

Minor hazard to humans

If you do not pay attention to this warning, minor or moderate injuries could occur.

NOTICE

Danger to property, not to persons

If you do not pay attention to this warning, material damage could occur.

If multiple hazard levels occur, the warning for the highest respective hazard level will be used.

In addition, a warning about personal injuries can also include a warning about material

damage.

2.2 Standards applied

The device has been built and tested in compliance with the following standards and has left the

factory in perfectly safe condition.

• IEC/ DINEN61010-1 (VDE0411‑1)

• IEC/ DINEN61010-2-030 (VDE0411‑2‑030)

• IEC/ DINEN 61010-031 (VDE0411‑031)

2.3 Symbols used

Safety

5178 / 03/2021 enBENNING EV 3-210

2.3 Symbols used

Symbols on the device

Symbol Meaning

Please observe the information provided in this operating manual in

order to avoid dangers.

The device complies with EUdirectives.

At the end of product life, dispose of the unserviceable device via

appropriate collecting facilities provided in your community.

The device is provided with protective insulation (protection classII).

Table2: Symbols on the device

Symbols used in the operating manual

Symbol Meaning

General warning

Warning of electric voltage!

(AC) alternating voltage or alternating current

Earth (voltage to earth)

Table3: Symbols used in the operating manual

2.4 Intended use

Only use the device within the framework of the corresponding technical data. Any operating

conditions that deviate from this shall be considered as improper use. Solely the user of the

device shall be liable for any resulting damage.

In particular, note the following:

• In case of improper use, the liability and warranty claims become void. Solely the user of the

device shall be liable for any damage resulting from improper use. Uses not complying with

the intended use include e.g.:

– Use of components, accessories, spare or replacement parts that have not been

released and approved for the respective application by Benning

– Non-observance, manipulation, changes or misuse of the operating manual or the

instructions and notes contained therein

– Any form of misuse of the device

– Any use other than or beyond that described in this operating manual

• Warranty and liability claims are generally excluded if damage is due to force majeure.

• If any prescribed services are not performed regularly or not on time according to

manufacturer specifications during the warranty period, a decision about a warranty claim

can only be made once the findings are available.

Direct any questions to Technical Support [}page8].

Table des matières

Autres manuels Benning Instrument de mesure

Benning

Benning CM P1 Manuel utilisateur

Benning

Benning VT 2 Manuel utilisateur

Benning

Benning DUSPOL Manuel utilisateur

Benning

Benning CC 2 Manuel utilisateur

Benning

Benning ST 755+ Manuel utilisateur

Benning

Benning ST 720 Manuel utilisateur

Benning

Benning CM 8 Manuel utilisateur

Benning

Benning CM 2-1 Manuel utilisateur

Benning

Benning PV 2 Manuel

Benning

Benning CFlex 1 Manuel utilisateur

Benning

Benning Sun 2 Manuel utilisateur

Benning

Benning MM 6-1 Manuel utilisateur

Benning

Benning CM 1 Manuel utilisateur

Benning

Benning IT 130 Manuel utilisateur

Benning

Benning CM 5-1 Manuel utilisateur

Benning

Benning IT 101 Manuel utilisateur

Benning

Benning LD 60 Manuel utilisateur

Benning

Benning CM E1 Manuel utilisateur

Benning

Benning IT 100 Manuel utilisateur

Benning

Benning DB 1 Manuel utilisateur

Benning

Benning 044146 Manuel utilisateur

Benning

Benning ST 725 Manuel utilisateur

Benning

Benning TA PV Manuel utilisateur

Benning

Benning DUSPOL Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
