User Instructions for Remote Controlled
2kW Rotisserie Effect Fan Heater – Model 1276
T ese instructions s ould be read carefully and retained for future reference.
Tec nical Specification
Parts list Tec nical Data
1. Long screws 4 pcs Model 1276
2. Plastic wall plug 4 pcs Voltage AC 230 240V Fuse 13 amp
3. Remote Control Unit (Inc Battery) 1 Pc Frequency 50Hz
4. Small Screws 4 pcs Power 1800 2000W
5. Small wall Brackets 2 pcs Lamp LED Unit
6. Pebble 1 sets Dimensions 36”
Width 920mm
Height 620mm
Depth 150mm
Fire Installation
Unpack the heater carefully and retain all packaging for future use. Ensure that all packing items are removed and read any warning
labels carefully (see Maintenance Section).
T e appliance must be positioned so t at t e plug is accessible. Only w en you are certain t at you ave completed
t e installation s ould you plug in and switc on at t e wall socket.
CAUTION: In order to avoid a hazard due to inadvertent resetting of the thermal cut out, this appliance must not be supplied
through an external switching device, such as a timer, or connected to a circuit that is regularly switched on and off by the utility.
Important Notes
•These Instructions should be read carefully and retained for the future reference.
•This heater must not be located immediately above a fixed socket outlet.
•Do not use the heater in the immediate surrounds of a bath, a shower, or a swimming pool.
•Do not cover this heater, or obstruct the air inlet or outlet, otherwise there is a risk of overheating.
•The heater must be cooled down completely before any maintenance
•This heater must be fixed against a vertical surface.
•Under no circumstances should the heater be used as a free standing appliance.
•After unpacking, please make sure that the appliance is intact, with no signs of damage caused by transpor
use the appliance and contact the Service Centre.
•During normal operation this appliance will emit noise from the internal fan unit.
•If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similar
ly qualified persons in order
to avoid a hazard.
•This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given supervision or i
nstruction concerning use of the appliance by a
person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.
Warning: This appliance must be earthed.
The wires in the mains lead connected to this appliance are coloured in accordance with the following code:
GREEN and YELLOW Earth
BLUE Neutral
Brown Live
As the colour of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the
terminals in your plug, proceed as follows:
•
The wire which is coloured Green and Yellow must be connected to the terminal in the plug which is marked with the letter E or
by the earth symbol or coloured Green or Green and Yellow.
•The wire which is coloured Blue must be connected to the terminal which is marked with the letter N or coloured Black.
•The wire which is coloured Brown must be connected to the terminal which is marked with letter L or coloured Red.
