Installation Instructions
Position the heater on a at, level, non-ammable, solid surface.
Direct-red heaters are intended for use in outdoor open areas or in indoor well ventilated areas. For indoor use, provide permanent ventilation openings of at
least 25 cm²/kW, equally distributed between oor and high level, with a minimum of 250 cm².
616913 616914
Minimum Opening Size 600 cm² 800 cm²
Only install the heater in normal upright position.
Do not place the heater near walls, corners or low ceilings.
Do not place the heater below a socket outlet.
Do not place the heater on moving vehicles or where it can tip over.
Keep the heater away from ammable, combustible, explosive or corrosive materials.
Keep the heater away from curtains or similar materials that could block the air inlet and outlet.
Never block or restrict the air inlet and outlet for any reason.
Keep the power cable away from heat sources, sharp edges, cutting and moving parts.
Do not expose directly to the weather or to excessive humidity.
Do not place the heater in the immediate surroundings of a bath, shower or swimming pool.
Follow general and special re safety regulations in force in all elds of applications. In any case ensure the following minimum safety clearances from materials or
objects in the surroundings of the heater:
Side:.......................................................... 0.6 m
Air inlet side:................................................1 m
Top: ........................................................... 1.5 m
Hot air outlet side:.....................................3 m
Floor:............................................................ 0 m
Floors and ceilings must be made of reproof materials in the place where the heater is operated.
Do not connect direct-red heaters to air ducts.
Instructions for Use
STARTUP
Fill tank with clean fuel. Only use Diesel or Kerosene.
The fuel gauge on top of the tank allows to check fuel level
Connect the power cord plug to a AC220-240V 50 Hz earthed electrical supply system.
Earthing is mandatory.
When complete“start-up”above, the left display window shows“--”, the right display window shows ambient temperature value.
Push the power switch to“ON”(1) position.
The default temperature setting is 20°C, be showed on the left display window.
If the ambient temperature is lower than default temperature, the electrodes start sparking, after 7 seconds, the heater starts.
If the ambient temperature is higher than default temperature, turn thermostat control knob to desired temperature, the electrodes start sparking, after 7
seconds, the heater starts.
COLD START-UP: at low temperature keep the air vent hole (see Fig. 6) closed by a nger during ignition to make start-up easier.
ABNORMAL OPERATION: in case of malfunction (ame failure, reduced air ow, bad combustion, etc.) the heater stops and the indicator light starts FLASHING
(THE LOCK-OUT MODE code will be showed on the display window).
MANUAL RESET/RESTART
If the heater is in lock-out mode, check and remove the cause of lock-out before restarting the heater. To reset, turn the ON/OFF switch to 0 and then again to I. In
case of repeated malfunction, call technical service. Turning the thermostat control knob will NOT reset the heater.
SHUTDOWN
Move switch to“OFF”(O) position. Unplug the unit when not used for a long time.
Never disconnect the heater from mains to stop it while in operation. Always allow the cooling sequence to be completed (BGO1601-50), otherwise the residual
heat could damage internal components.
Do not cover the heater. Do not block the air inlet and outlet.
The heater outlet is very hot during operation and after use. Do not touch! Use personal protecting equipment if needed.
Children should be supervised to ensure that they do not play with the appliance.
The appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge.
Unplug the heater before moving it. Never pull the cable to unplug or move the unit.
Do not leave the heater unattended when in use.
Never use the appliance with wet hands or when either the heater or the power cable is wet.
If the supply cable is damaged, it must be replaced by the manufacturer, by a service agent or a similar qualied person.
