INSTALLATION & OPERATION
INSTRUCTIONS
60cm 4Burner Gas Cooktop
Model No.
BGM604
BGM604-F
Only In Builders Pack BP370EG FINELINE: 5103600 Aus Only
V.15 Jan21
Thank you
Thank you for choosing Bellini Appliances.
Bellini prides itself on ‘affordable living’ making sure there is
no compromise in your favourite room … The Kitchen
All Bellini appliances carry a 3 year In Home warranty,
be sure to retain your installation and user manual and
receipt.
For all warranty and technical queries please contact
1300 373 199
GSM Retail Australia Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aus Or 0800 764 912 NZ www.belliniappliances.com.au
Model No. BGM604, BGM604-F Only In Builders Pack BP370EG FINELINE: 5103600 Aus 60cm 4 Burner Gas Cooktop
Content
Safety instructions----------------------------- 3
Installation----------------------------------------4
Product description-----------------------------9
Start using your appliance--------------------11
Maintenance ------------------------------------13
Warranty------------------------------------------24
GSM Retail Australia Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aus Or 0800 764 912 NZ www.belliniappliances.com.au
Model No. BGM604, BGM604-F Only In Builders Pack BP370EG FINELINE: 5103600 Aus 60cm 4 Burner Gas Cooktop
safety instructions
■ This instruction booklet must be kept with the appliance for any future reference.
If the appliance is sold or transferred to another person, ensure the booklet is passed on to
the new user.
■ The manufacturer declines any liability should these safety measures not be observed.
■ The following marks are made to be easily understood so that you can prevent any
accident caused by misuse in advance, and use the appliance more conveniently.
■
Danger/Warning Neglect of this mark may result in severe personal injury or
death.
Caution Neglect of this mark may result in minor personal injury or
property damage.
ʄ7KHIROORZLQJPDUNV DVIROORZ
Caution No Access
No Fire Tool Must Do
Danger
ʄ,IJDVVHHPVWROHDNWDNHWKHDFWLRQVDVIROORZ
- Do not turn on the light.
- Do not switch on/off any electrical appliance and do not touch any electric plug.
- Do not use a telephone.
1 Stop using the product and close the middle valve.
2 Open the window to ventilate.
3 Contact our service centre by using a phone outside.
* The fuel gas contains mercaptan, so that you can smell the gas leak (smell of rotten garlic
or egg) even where only 1/1000 of the gas is in the air.
are u in the Instruction Manual
Please take the time to read this Instruction Manual before installing or
using the appliance.
■ Read the following contents thoroughly and ensure you understand them
sed
V
.
***All Bellini Appliances are for domestic use only**
3
installation
Warning
■ This appliance shall be installed in
accordance with regulations in force
and only used in a well ventilated
space.
■ Prior to installation, ensure that the
gas and electrical supply complies
with the type stated on the rating
plate.
■ Where this appliance is installed in
marine craft or in caravans, it should not
be used as a space heater.
■ The gas pipe and electrical cable
must be installed in such a way that
they do not touch any parts or the
appliance.
■ This appliance should be installed by a qualified technician or installer.
■ The adjustment conditions for this appliance are stated on the label or data plate.
■ Remove all packaging before using the appliance.
■ After unpacking the appliance, make sure the product is not damaged and that the
connection cord is in perfect condition. Otherwise, contact the dealer before installing
the appliance.
■ The adjacent and all materials used in the installation must be able to
withstand a minimum temperature of 95˚C above the ambient temperature of the
room it is located in, whilst in use.
■ In the event of burner flames being accidentally extinguished, turn off the burner
control and do not attempt to re-ignite the burner for at least one minute.
■
The use of a gas cooking appliance results in the production of heat and moisture in the
room in which it is installed. Ensure that the kitchen is well ventilated: keep natural
ventilation holes open or install a
■ Prolonged intensive use of the appliance may call for additional ventilation, for
example opening of a window, or more effective ventilation, for example increasing
the level of mechanical ventilation where present.
Caution
cabinetry
range hood above the gas cook top.
-
4
child and people safety
■ Do not allow children to play near or with the appliance.
The appliance gets hot when it is in use.
Children should be kept away until it has cooled.
■ This appliance is designed to be operated by adults.
■ Children can also injure themselves by pulling pans or pots off the appliance.
■ This appliance is not intended for use by children or other persons whose physical,
sensory or mental capabilities or lack of experience and knowledge prevents them
from using the appliance safety without supervision or instruction by a responsible
person to ensure that they can use the appliance safety.
Warning
Caution
5
during use
■ Only use the appliance for preparing
food.
Warning
■
The use of a gas cooking appliance results
in the production of heat and moisture in
the room in which it is installed. Ensure
that the kitchen is well ventilated : keep
natural ventilation holes open or install
■ The heating and cooking surfaces of
the appliance become hot when they
are in use, take all due precautions.
■ Never leave the appliance unattended
when cooking.
■ Do not modify this appliance.
■ Do not use this appliance if it
in contact with water. Do not operate
this appliance with wet hands.
■ Do not use large cloths, tea towels or
similar as the ends could touch the
flames and catch fire.
■ Unstable or misshapen pans should
not be used on the appliance as they
can cause an accident by tipping or
spillage.
comes
Burner
panel is not designed to operate
from an external timer or separate
remote control system.
range hood.
6
during use
■ Do not use or store flammable
materials in the storage drawer
near this appliance.
■ Do not spray aerosols in the vicinity of
this appliance while it is in operaiton.
■ This appliance is intended for domestic cooking only. It is not designed for commercial or
industrial purposes.
■
Prolonged intensive use of the appliance may call for additional ventilation, for example
opening of a window, or increasing the level of mechanical ventilation where present.
■ Use heat-resistant pot holders or gloves when handling hot pots and pans.
■ Do not let pot holders come near open flames when lifting cookware.
■ Take care not to let pot holders or gloves get damp or wet, as this causes heat to transfer
through the material quicker with the risk of burning yourself.
■ Only ever use the burners after placing pots and pans on them. Do not heat up any empty
pots or pans.
■ Never use plastic or aluminium foil dishes on the appliance.
■ When using other electrical appliances, ensure the cable does not come into contact with
the appliance surfaces of the cooking appliance.
■ If you have any mechanical parts eg. an artifical heart in your body, consult a doctor before
using the appliance.
■
. Such cloths can catch fire
on a hot burner.
■ When using glass cookware, make sure it is designed for top plate cooking.
■ To minimise the possibility of burns, ignition of flammable materials and spillage, turn
cookware handles toward the side or center of the top plate without extending over
adjacent burners.
■ Always turn burner controls off before removing cookware.
■ Carefully watch foods being fried at a high flame setting.
■ Always heat fat slowly and watch as it heats.
■ Foods for frying should be as dry as possible. Frost on frozen foods or moisture on fresh
foods can cause hot fat to bubble up and over the sides of the pan.
■
Never try to move a pan of hot fat, especially a deep fat fryer. Wait until the fat is
cool.
■ Perishable food, plastic items and
aerosols may be affected by heat and
should not stored above or below the
appliance.
■ Ensure the control knobs are in the
‘ ’ position when not in use.
Caution
Do not use a tea towel or similar materials in place of a pot holder
completely
Do not use a tea towel or similar materials in place of a pot holder
■
If the surface
is made of glass-cracked, switch off the appliance to avoid defeat electr cutiono.
7
cleaning and service
environmental information
■ After installation, please dispose of the packaging
with due regard to safety and the environment.
■ When disposing of an old appliance, make it
unusable, by cutting off the cable.
&RUUHFW'LVSRVDORI7KLV3URGXFW
:DVWH(OHFWULFDO(OHFWURQLF(TXLSPHQW
■ This marking shown on the product or its literature, indicates that it should not be
disposed with other household wastes at the end of its working life. To prevent
possible harm to the environment or human health from uncontrolled waste disposal,
please separate this from other types of wastes and recycle it responsibly to promote
the sustainable reuse of material resources.
■ Household users should contact either the retailer where they purchased this product,
or their local government office, for details of where and how they can take this item
for environmentally safe recycling.
■ Business users should contact their supplier and check the terms and conditions of
the purchase contract. This product should not be mixed with other commercial
wastes for disposal.
■ Never use abrasive or caustic
cleaning agents.
Warning
■ Before attempting to clean the appliance, it should be disconnected from the mains
and cooled.
■ You should not use a steam jet or any other high pressure cleaning equipment to
clean the appliance.
■ This appliance should only be
repaired or serviced by an authorised
Service and only genuine
approved spare parts should
be used.
Caution
technician
8
description of the appliance
Di
m
Model
Pan Support
Wok pan Suppo
r
Top Plate
m
ension(W*D*H
)
Ignition device
Gas Connectio
n
Electric supply
Burner Feature
ΣQn
rt
)
n
, Se
m
m
i-rapid (2), Au
x
S
Conti
n
24
0
x
iliary (1)
N/A
S
tainless Steel
590*500*95
n
uous Ignition T
y
G1/2 thread
0
Vac,50Hz-60Hz
,
p
e
2W
Cast Iron
BGM604/BGM604-F
WO K
30.4 MJ/h
220-
9
