Belkin F1D201 Manuel utilisateur

Package Contents

Introduction 1

Introduction

This booklet will guide you through the basic steps needed to install the

2-Port Reverse KVM Switch.

2-Port Reverse

KVM Switch

Quick Installation

Guide

Speciﬁcations 2

Specifications

Part No. F1D201

Material Plastic enclosure

Net Weight 30.6 lbs. (13.9kg.)

Unit Dimensions 2.95 (W) x 2.76 (D) x 1.23 (H) in.

(75 x 70 x 31.3mm)

Max. Video Resolution 1600x1200

Keyboard Connection PS/2

Mouse Connection PS/2

Monitor Connection HDDB15 (VGA)

Warranty 2 years

Installation 3

Installation

Step 1 Power off your computer.

Step 2 Using the included KVM cable, connect the male VGA end to the VGA port on

your computer.

Step 3 Connect the PS/2 ends of the included KVM cable to the keyboard and mouse

ports, paying particular attention to which cable connects to which port. They

are not interchangeable.

Step 4 Connect your monitors to the back of the Reverse KVM Switch.

Installation 4

Step 5 Connect your keyboards and mice to the console ports to the back of the

Reverse KVM Switch.

Step 6 Turn on the connected monitors.

Step 7 Turn on the connected computer. The display LED will turn on User 1 or User 2,

depending on the last lighted position of the LEDs.

You are now ready to use your 2-Port Reverse KVM Switch.

Using your 2-Port Reverse KVM Switch 5

Using your 2-Port

Reverse KVM Switch

Switch Between Two Users

Press “Ctrl” twice (within three seconds) to switch between users.

Switch the Beeping Sound ON/OFF

Press the right “Shift” twice (within three seconds) to switch the beeping sound ON

or OFF.

Hot-Key Setting Mode

1To enter the hot-key setting mode, press “Scroll-Lock” twice (within three seconds).

2The LED lights under “Num Lock”, “Caps Lock”, and “Scroll Lock” at the top right

corner of the keyboard will be used as an indicator for the time-out setting.

Hot-Key Setting Mode 6

4Single Screen Display:

To turn on or off the display on the other console, press “L” while in the hot-key

setting mode.

5Release control to the other user:

While in the hot-key mode, press “SPACE” to give the usage to the other user.

6Exit the hot-key setting mode:

Press “ESC” to exit the hot-key setting mode.

Time-Out Period NUM LOCK CAPS LOCK SCROLL LOCK

30 sec. OFF OFF ON

1 min. ON OFF OFF

3 min. ON OFF ON

5 min. OFF ON OFF

10 min. OFF ON ON

20 min. ON ON OFF

3Adjusting time-out setting:

a. Under the hot-key settings, press “-” to decrease the time-out period.

b. Under the hot-key settings, press “+” to increase the time-out period.

c. Time-out setting table.

Belkin Tech Support

US: 800-223-5546, ext. 2263

310-898-1100, ext. 2263

UK: 0845 607 77 87

Australia: 1800 235 546

New Zealand: 0800 235 546

Singapore: 65 64857620

Europe: www.belkin.com/support

Belkin International, Inc.

501 West Walnut Street

Los Angeles, CA 90220, USA

310-898-1100

310-898-1111 fax

Belkin Ltd.

Express Business Park, Shipton Way

Rushden, NN10 6GL, United Kingdom

+44 (0) 1933 35 2000

+44 (0) 1933 31 2000 fax

Belkin Ltd.

4 Pioneer Avenue

Tuggerah Business Park

Tuggerah, NSW 2259, Australia

+61 (0) 2 4350 4600

+61 (0) 2 4350 4700 fax

Belkin B.V.

Boeing Avenue 333

1119 PH Schiphol-Rijk, The Netherlands

+31 (0) 20 654 7300

+31 (0) 20 654 7349 fax

trademarks of respective manufacturers listed.

8820-00071

2-Port Reverse KVM Switch

Start Here

Quick Installation Guide F1D201

2-Port Reverse KVM Switch
